Standard Microwave Oven

wolfappliance.com

BUILT-IN TRIM KITS

•27" E series.

•30" E series.

•30" L series.

Optional trim kits are available through an

authorized Wolf dealer. For local dealer infor-

mation, visit the find a showroom section of

our website, wolfappliance.com.

FEATURES

•Built-in or freestanding option for design

versatility.

•Built-in trim kits available to match Wolf

L and E series ovens.

•Large-capacity interior.

•Easy-to-operate control panel and

programmable power options.

•Sensor cooking to monitor and adjust

settings.

•Warming feature for gentle heating.

•Turntable is removable for easy

cleaning.

•Interactive display with timer up to

99 minutes.

•English, French and Spanish language

options.

•Menu label and food guide.

•Interior light and window in door.

•One-touch door open pad.

•Safety door latches will not allow oven

to operate unless door is closed.

MODEL OPTIONS

STANDARD MICROWAVE

Model MS24

SPECIFICATIONS

PRODUCT

Dimensions 24"W x 133/8"H x 191/8"D

Weight 50 lb

OVEN INTERIOR

Capacity 2.0 cu ft

Dimensions 173/8"W x 101/2"H x 185/8"D

ELECTRICAL

Power 1200 W

Supply 120 VAC, 60 Hz

Service 15 amp circuit

Power Cord 4 ft

If the microwave oven is built in, a trim kit is

required for proper ventilation.

Specifications are subject to change without

notice. Visit wolfappliance.com/specs for the

most up-to-date information.

Dimensions may vary ±1/8"(3). Dimensions in

parentheses are millimeters unless otherwise

specified.

OPENINg WIDTh

TRIM W

27" Trim 251/4" (641)

30" Trim 271/2" (699)

Standard Microwave Oven

wolfappliance.com

DIMENSIONS

INSTALLATION WITh TRIM

©Wolf Appliance, Inc. all rights reserved. 12/2013

E SERIES TRIM

133/8"

(340)

FREE-

STANDING

24" (610)

FREESTANDING

181/4"

(464)

WITH

TRIM

18" (457)

BEHIND TRIM

*11/4"(32) for contemporary E series trim only.

1" (25) OR

11/4" (32)*

L SERIES TRIM

24" (610)

FREESTANDING

133/8"

(340)

FREE-

STANDING

181/4"

(464)

L SERIES

TRIM

175/8" (448)

BEHIND TRIM

13/8"

(35)

E SERIES TRIM

133/8"

(340)

FREE-

STANDING

24" (610)

FREESTANDING

181/4"

(464)

WITH

TRIM

18" (457)

BEHIND TRIM

*11/4"(32) for contemporary E series trim only.

1" (25) OR

11/4" (32)*

L SERIES TRIM

24" (610)

FREESTANDING

133/8"

(340)

FREE-

STANDING

181/4"

(464)

L SERIES

TRIM

175/8" (448)

BEHIND TRIM

13/8"

(35)

E SERIES TRIM

133/8"

(340)

FREE-

STANDING

24" (610)

FREESTANDING

181/4"

(464)

WITH

TRIM

18" (457)

BEHIND TRIM

*1

1

/4"(32) for contemporary E series trim only.

1" (25) OR

11/4" (32)*

L SERIES TRIM

24" (610)

FREESTANDING

133/8"

(340)

FREE-

STANDING

181/4"

(464)

L SERIES

TRIM

175/8" (448)

BEHIND TRIM

13/8"

(35)

E

FRONT VIEW

SIDE

VIEW

20" (508)

OPENING

DEPTH

NOTE: Dashed line represents profile of unit.

W

OPENING WIDTH

TOP VIEW

17" (432)

OPENING

HEIGHT

BASE SUPPORT

297/8"(759) FOR 30" TRIM

267/8"(683) FOR 27" TRIM

297/8"(759) FOR 30" TRIM

L SERIES TRIM

OVERALL WIDTH

E SERIES TRIM

OVERALL WIDTH
