WeBoost Eqo User manual

Install

Guide

HOW DOES EQO WORK?

eqo receives a cell signal from the tower, ampliﬁes it, and sends it over coax

cable to the antenna. The antenna broadcasts the ampliﬁed signal making it

available to devices inthe home.

Get ready

for a great signal.

Follow these easy steps and EQO wil be boosting

your signal in no time. EQO technology - the solution

for a strong, reliable cell signal.

For more information refer to our Full Install Guide at:

https://cellphonesignalbooster.us

PACKAGE CONTENTS

EQO

Booster

EQO

Antenna

Coax

Cable

Power

Supply

Coax Cable

6 ft.

Power Cable

Coax Cable

-90dB

For optimal signal boost, place the EQO booster in the

room of your home that has the strongest cell signal.

Please refer to our Full Install Guide for more options on how

to properly install your booster: https://cellphonesignalbooster.us

Congratulations! Once your booster is running, please allow some time for your

phone to adjust to your new signal.

Read more about it here at https://cellphonesignalbooster.us

Quick Install

Guide

Step 2

Step 3

Step 5

HOW TO MEASURE YOUR CELL SIGNAL

Connect the supplied Coax Cable and

Power Supply on the side of the Booster.

Place the Antenna where you need to boost your

signal. It should face the same direction as the

Booster and stand at least 6 feet away from it.

Connect the Power Supply to a surge protected

AC power strip with at least 1000 Joule rating.

Step 1

Place your Booster in the area with the

strongest cell phone signal. The LED light

should be facing into the room.

Step 4

Connect the other end of the Coax Cable to

the Antenna.

https://cellphonesignalbooster.us/blog/ﬁeld-test-mode-an-

overview-enabling-it-on-your-phone/

Place your phone in test mode so thenumerical signal strength

can be read. For help in ﬁnding the test mode for your phone

please go to:

-80dB

Please register your product. Contact our U.S. Based

Customer Support

https://cellphonesignalbooster.us

800-501-3153

MON - FRI: 10:30 AM to 5:30 PM CST T

FOR ADDITIONAL INFORMATION PLEASE REFER TO OUR FULL INSTALL GUIDE

You are

almost there. ANY

QUESTIONS?

IMPORTANT NOTICE: Connect your EQO Booster

AC Power Supply to a surge protected AC power

strip with at least a 1000 Joule rating. Failure to

do this will void your warranty in the event of a

power surge or lightning strike.

This device may be operated ONLY in a ﬁxed location for in-building

use. The signal booster unit is designed for use in an indoor,

temperature controlled environment ( > 150 degrees Fahrenheit)

WHAT COLOR IS YOUR LIGHT?

Booster is operating

seamlessly

Booster is too close to

an external signal. Try

changing its location.

Booster is too close to

the Antenna. Try

increasing the distance.
