Vornado QUBE50 User manual
model
QUBE50
vornado.com
WHOLE ROOM AIR PURIFIER
OWNER’S GUIDE
READ AND SAVE
THESE INSTRUCTIONS
2English
vornado.com
800.234.0604
we expect
this product
to be PERFECT
if it’s not
WE will make
it right.
English 3
Important Safety Instructions ..................................................4
Product Information ................................................................7
True HEPA Filtration.................................................................8
Automatic Filter Rell Program ...............................................8
Control Panel ...........................................................................9
User Tips ...............................................................................11
Leg Installation ......................................................................11
Filter Replacement.................................................................12
Cleaning and Maintenance ....................................................13
Troubleshooting .....................................................................14
Warranty.................................................................................15
CONTENTS
4English
READ AND SAVE THESE INSTRUCTIONS
IMPORTANT SAFETY INSTRUCTIONS
This owner’s guide and any additional inserts are considered part of
the product. They contain important information about safety, use and
disposal. Before using the product, please familiarize yourself with all
operating and safety instructions. Please keep all documents for future
reference and pass these documents on, together with the product,
to any future owner. See our website to view, download and print the
most current version of this owner’s guide.
INTENDED USE: This product is intended to purify the air in indoor
living spaces only in the United States and Canada. This product is not
intended for commercial or industrial use. The manufacturer assumes
no responsibility for damage or injury due to unauthorized use or
product modication. Failure to follow these directions will void the
product warranty. This product is intended to be used on the oor and
not on an elevated surface such as a table or desktop.
WARNING: Risk to Children and Impaired Persons
- Supervision is required during the installation, operation, cleaning
and maintenance of this product by children under age 12 and
anyone with reduced physical, sensory or mental capabilities.
Children should be supervised to ensure that they do not play with
the appliance, its parts and packaging material.
INSTALLATION WARNING—To reduce risk of re, electrical shock
and injury to persons, observe the following:
- Place this product away from curtains, draperies, tablecloths and
other fabrics, since they may be drawn into the product, damage
the motor and/or cause a re.
- No part of this product (the appliance, power cord, plug, packaging,
etc.) should be placed near furnaces, replaces, stoves or other high
temperature heat sources. Do not use this product in a window, on
an uneven or unstable surface, or near water.
- The appliance, power supply, power cord and plug cannot come
into contact with water. Do not use this product on wet surfaces.
Do not use this product in a bathtub or shower or position product
where it may fall into a bathtub, laundry, swimming pool or other
water container. Do not use this product outdoors or expose it to
weather or elements.
- Do not run cord under carpeting. Do not cover cord with throw
rugs, runners, or similar coverings. Do not route under furniture or
appliances. Arrange cord away from trafc area and where it will not
be tripped over.
- The cord should not hang over edges of counters or be placed
where it can be crimped or closed in doors. Place appliance near
an easily accessible outlet so the product can be unplugged quickly
during an emergency.
SAFE USE WARNING—To reduce risk of re, electrical shock and
injury to persons, observe the following:
- WARNING: To reduce likelihood of circuit overload, re and electric
shock, do not operate with a solid state speed device, such as a
dimmer control switch.
- Do not operate unit if the unit has been dropped or damaged. Do
not use this product if it has a damaged power cord or plug. To
avoid risk of electrical shock, do not attempt to repair or replace
parts. Only original replacement parts may be used. If the power
cord is damaged, it must be replaced by the manufacturer, its
service agent, or similarly qualied persons in order to avoid a
hazard. Contact Vornado Consumer Service at 1-800-234-0604
English 5
instructions about replacement and repair.
- Risk of re. Your appliance may be equipped with a detachable
power supply or a cord/plug with a safety device such as a fuse. Use
only the power cord and plug provided.
- Before plugging power cord into electrical outlet, be sure that
all electrical information on the rating label, including voltage, is
compatible with your outlet’s power supply.
- Never use the cord as a handle or otherwise yank, strain or stretch
the power cord.
- While the product is plugged in, do not insert or allow foreign
objects to enter any input or output opening as this may cause risk
of electric shock or re, or damage the product.
- A loose t between wall outlet (receptacle) and plug may cause
overheating and distortion of the plug. Discontinue use of the
product in this outlet. Contact a qualied electrician to replace
loose or worn outlets.
- This appliance has a polarized plug (one blade is wider than the
other.) To reduce the risk of electrical shock, this plug is intended to
t in a polarized outlet only one way. If the plug does not t fully in
the outlet, reverse the plug. If it still does not t, contact a qualied
electrician. Do not attempt to defeat this safety feature.
- Before moving, repositioning, servicing, cleaning and when not in
use, use the product controls to turn off the power and then unplug.
To disconnect from outlet, grasp and pull only the plug. Also, power
off and unplug if the product will be left unattended for an extended
period of time or during electrical storms.
SERVICING WARNING—To reduce risk of re, electrical shock
and injury to persons, observe the following:
- Clean your product regularly, only as is instructed in this manual.
Prior to cleaning, turn off the power on your product and unplug. Do
not use gasoline, thinners, solvents, ammonias or other chemicals
for cleaning. Refer to the CLEANING instructions provided.
- Do not open appliance housing while product is plugged in. To
avoid risk of shock, all service and/or repairs must be done by a
Vornado Authorized Service Center.
CONSUMER ADVISEMENT
This device complies with Part 15 of the FCC Rules. Operation is
subject to the following two conditions: this device may not cause
harmful interference, and this device must accept any interference
received, including interference that may cause undesired operation.
NOTE: This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one or
more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that
to which the receiver is connected.
- Contact Vornado Consumer Service or dealer or an experienced
radio/TV technician for help.
6English
DISPOSAL WARNING
To reduce waste and environmental harm, observe the following:
PACKAGE RECYCLING: The packaging protects the
appliance from transport damage. The packaging materials
are selected from the point of view of their environmental
friendliness and disposal technology and are therefor
recyclable. Dispose of all packaging materials in an
environmentally responsible manner.
SAVE THESE INSTRUCTIONS
English 7
CONTROL PANEL
OUTLET GRILL
LEGS (4)
LEG SCREWS (8)
POWER CORD
FILTER FRAME
FILTER FRAME SUPPORT TABS (3)
3-IN-1 FILTER CARTRIDGE
Hepa, Carbon, Prelter
1
7
8
6
4
5
3
2
PRODUCT INFORMATION
1
2
33
46
7
8
8
8English
VORNADO WHOLE ROOM AIR PURIFIERS
FEATURE PRECISION TRUE HEPA
CALIBRATION
Without properly calibrated airow,
products with a True HEPA Filter will
not achieve their full ltration potential.
Gaps, poorly sealed lter housings,
and excessive air velocity all reduce the
effectiveness of the product. Independent
testing labratory veries that the precise calibration of a Vornado
Air Purier allows it to perform at True HEPA standards.
AUTOMATIC FILTER
REFILL PROGRAM
A convenient and hassle-free way to recieve regular shipments
of Vornado Filters, direct to your door. Eliminate the hassle
of remembering to reorder. Maintain the high efciency
of your Vornado Purier by regularly replacing used Filters
with fresh new ones. How it works: You select a plan and
Vornado will send replacement Filters at the recommended
maintenance interval. To sign up, visit vornado.com, email
at anytime.
TRUE HEPA FILTRATION
3-IN-1 FILTRATION
Carbon ltration captures odors and prolongs HEPA lter life.
The honeycomb design and use of carbon pellets enables the
lter to adsorb more household odors and harmful gases than
a traditional carbon lter. HEPA ltration captures 99.97% of
particles 0.3 microns or larger, to effectively clean large volumes
of air. The Pre-lter removes larger particles such as hair, pet
dander, and mold spores.
Part # MD1-0039
English 9
CONTROL PANEL
FILTER REPLACEMENT LIGHT
FILTER REPLACEMENT
POWER ON/OFF
FAN SPEED
FAN SPEED LIGHTS
QUICK CLEAN,
HIGH, MEDIUM,
LOW
10 English
CONTROL PANEL
POWER
Function ON and OFF by pressing the Power Button.
FAN SPEED
4 fan speed settings to meet any need. Select Quick Clean, High,
Medium or Low by pressing the Fan Speed button. The Quick Clean
ltration setting can be used to rapidly lter the air when airborne
particle levels are high.
Note: Dust and allergens are most airborne when persons and pets are
active in the room. For best results, set the unit on Quick Clean during
these times for high demand cleaning and circulation. Set the unit to a
lower setting for quieter operation when activity is reduced.
FILTER REPLACEMENT
Equipped with Filter Replacement indicator light to show when
it is recommended to change the lter. Please refer to FILTER
REPLACEMENT for instructions. This feature is controlled by time
of use. The light will illuminate after 4,500 hours of run time has
accumulated.
Note: User environments will differ. The lter replacement time is
based on average use situations. If you are using the air cleaner in a
more demanding environment, you may need to change your lter
more frequently. In less polluted environments the lter life may
extend beyond the notication.
Table of contents
Other Vornado Air Cleaner manuals
Vornado
Vornado 500 Series User manual
Vornado
Vornado 15 User manual
Vornado
Vornado CYLO50 User manual
Vornado
Vornado PCO200 User manual
Vornado
Vornado PCO300 User manual
Vornado
Vornado AC300 User manual
Vornado
Vornado PCO300 User manual
Vornado
Vornado AC300 User manual
Vornado
Vornado AC550 User manual
Vornado
Vornado Purio User guide
Vornado
Vornado AC550 User manual
Vornado
Vornado AQS500 Air User manual
Vornado
Vornado AC350-EU User manual
Vornado
Vornado PCO375DC User manual
Vornado
Vornado AC350 User manual
Vornado
Vornado AC500 User manual
Vornado
Vornado CYLO51 User manual
Vornado
Vornado AC350 User manual
Vornado
Vornado VornadoAQS 35C User manual
Vornado
Vornado AC300-EU User manual
