Vitek VTC-EBV49-24 User manual

BLACKYELLOWMAGENTACYAN

(888) VITEK-70 | WWW.VITEKCCTV.COM

28492 Constellation Road Valencia, CA 91355

VTC-EBV49/24 4-9mm Varifocal Color Bullet

Camera w/540TVL

•1/3" CCD with 540TV Lines Resolution

•Built-in 4-9mm Varifocal Auto Iris lens

•Attractive and Compact Design

•Superior Backlight function

•Cable Feed-thru for Vandal Resistant Outdoor

Installation

•24 Volt AC Operation

FEATURES

BLACKYELLOWMAGENTACYAN

(888) VITEK-70 | WWW.VITEKCCTV.COM

28492 Constellation Road Valencia, CA 91355

VTC-EBV49/24 4-9mm Varifocal Color Bullet

Camera w/540TVL

Detailed Specifications

Image Pick-Up Device

TV System

Effective Pixels

Scanning System

Sync System

Resolution

Minimum Illumination

S/N Ratio

Gamma Characteristic

Video Output

Electronic Iris

Power Supply

Power Consumption

Lens (Included)

Operational Temp.

Dimension (W x H x D)

Weight

1/3” Super HAD High Resolution Color CCD

NTSC

768H × 494V (380K pixels)

2:1 INTERLACE

Internal / Line Lock

540TV Lines

0.1 Lux

More Than 50dB

Internal / Line Lock selectable

Composite: 1.0 Vp-p / 75 Ohm

1/60 ~ 1/100,000sec

AC 24V

120mA

Varifocal 4mm-9mm

14 Deg. ~ 122 Deg F (-10 Deg -+ 50 Deg C)

2.76" x 3.31" x 7.48" (70mm x 84mm x 190mm)

17.64 oz. (500g)
