Vintec VWCM149FAB User manual

Quickstart Guide

Before turning your cabinet on

SPACER

Install spacer at the back of the cabinet.

LEVEL

Level your wine cabinet before loading. Un-levelled cabinets

can be noisy, and doors may not close or seal properly.

FILL

Fill the cabinet with bottles before you turn it on. If you don’t

have enough bottles, spread them evenly throughout the cabinet.

TEMPERATURE

Check desired temperature setting (43°F-46°F or 6°C-8°C for serving white, 54°

F-57°F or 12°C-14°C for all cellaring, and 61°F-64°F or 16°C-18C° for serving red).

after transport to allow refrigerant gases to settle.

DO NOT SWITCH ON FOR

AT LEAST 24 HOURS

FOR ALL MODELS:

DO NOT place a door in front of

cabinets or put them in a closed

conned space (eg. small rooms such

as pantries, closets or under staircases)

DO NOT place cabinets near heat

sources such as ovens

DO NOT place cabinets outdoors

DO NOT expose cabinets to moisture

or rain

DO NOT put cabinets in direct sunlight

Installation and ventilation

WARNING: You MUST

refer to model-specic

ventilation requirements

listed in the user

manual or on the Vintec

website when installing

your cabinet.

See user manual for

model-specic dimensions

FREQUENT FAN CYCLE

This ensures slow and even distribution of cool air

throughout the cabinet, limiting temperature variations.

SPACER/STOPPER

Ensures adequate ventilation behind unit.

WATER ON THE DOOR OR FLOOR

In hot/humid climates and particularly on hot days, humidity

in the ambient air can condense on the cabinet’s cold glass door.

ICE FORMING

If the door seal is compromised or left slightly ajar the compressor

will keep running which may cause ice formation on the back wall.

Have you noticed:

Storing and stacking

Different shapes and sizes

When quoting capacity, Vintec refers to all standard

bottle shapes shown below.

Wine producers use a wide range of different

bottles. The unique design of Vintec shelves allow

for storing and stacking of most dimensions and

proportions.

Wine varietal bottle shapes

Stacking for accessibilityStacking for cellaring

Shelf top viewShelf top view

DRINKING

CELLARING

DRINKING

CASE 1

1 1

CASE 5

CASE 2

CASE 4

CASE 3

CASE 4

CASE 2

CASE 5

CASE 1

Shelf front viewShelf front view

Stack bottles you wish to cellar at the back

of shelves, and wines for consumption at the

front.

Keep bottles from the same case together

in vertical stacks for safe and easy access

to all your different wines.

Getting started

The MODE button toggles through the

temperature zones.

S: Single zone temperature mode sets the upper and

lower zones to a single temperature.

M: In Multi-Temp mode the cabinet creates a

temperature gradient, allowing you to arrange wines

from top-to-bottom at the appropriate serving

temperatures for each bottle in your collection.

CE: Cellaring mode sets the entire wine cellar to a

preset 54° F (shows “CE” in upper and lower temp).

The LIGHT button toggles lights ON and OFF.

Press and hold to toggle for 5 seconds to

change lighting settings when open and closed.

1A: Bright when open. Dim when closed.

2A:Bright when open. Off when closed.

3A:Always On.

4A: Dim when open. Bright when closed.

The perfect serving temperature for wines

43° to 46° F:

Sauvignon Blanc & Champagne

50° to 54° F:

Chardonnay

57° to 59° F:

Pinot Noir & Merlot

62° to 64° F:

Cabernet Sauvignon & Syrah

54° F:

Recommended

temperature for cellaring

all wine varietals

FILTER: The lter icon will illuminate when lter needs to be changed. Simultaneously press and

hold Mode and Lower Zone “∨” buttons for 5 seconds to turn off alert. Consult the Use & Care

Guide for more information.

FILTER

Display

Red

Varietals

64ºF

63ºF

62ºF

61ºF

60ºF

65ºF

Champagnes &

Whites

53ºF

51ºF

49ºF

47ºF

45ºF

55ºF

Champagnes,

Whites & Reds

61ºF

57ºF

53ºF

49ºF

45ºF

65ºF

Store at Serving Temperature

Cellaring

Mode

54ºF

Multi-Temp provides exibility to store all your varietals at a perfect serving

temperature. In Multi-Temp mode, the cabinet creates a vertical temperature

gradient, allowing you to arrange wines from top-to-bottom at the appropriate

serving temperatures for each bottle in your collection. Refer to the diagrams

to understand how the Multi-Temp feature distributes the temperature gradient

based on settings.

Multi-Temp

* Conditions apply to member benets – see vintecclub.com for details.

Welcome,

And Thank You for choosing

a VINTEC Wine Cabinet to store,

display and share your treasured

collection. You’ve made a great

choice.

As a sign of our appreciation, we’d like to

invite you to become a member of the

VINTEC CLUB. A vibrant Wine Community

and Exclusive Club for owners of VINTEC

Wine Cabinets.

VINTEC CLUB members are entitled to very

special wine industry services and benefits,

including intimate dinners and tastings in the

company of Celebrated Winemakers and

Chefs from around the world.

We have created the VINTEC CLUB for

our discerning and valued customers who

invariably love wine, and it will be our

pleasure to welcome you as a member.

Your Vintec Club Concierge.

MEMBER BENEFITS:

• Invitations to VINTEC CLUB Private

Tastings, exclusive to members

• One additional year warranty* if

registration occurs within 60 days

from purchase

• Premium access to our proprietary

OENO Virtual Cellar Management

App

• Access to Member-Only Content

PLUS ACCESS TO:

Exclusive

Wine

Offers

Expert

Advice

Library

Personal

Concierge

Service
