VIBIA Halley User manual
Halley
Design by Jordi Vilardell & Meritxell Vidal
ASSEMBLY INSTRUCTIONS
SUPPLIED MATERIAL
TECHNICAL SPECIFICATIONS
Class I. Product with an additional protection cable (grounds).
Dust-tight product. Protected against water spray.
Product that CAN be in contact with normally-flammable
materials (wood or others).
-If the steel cable or the power cord of this lamp is damaged, it must be replaced only by the manufacturer or their technical service or by a person capacitated to this effect to avoid
any risk.
-We recommend reading the manual before installaing the lamp. Keep this instructions for future reference.
Caution
Before assembling and installing this product, carefully read the following:
-At least two people are needed to install and desinstall the lamp.
1.
4160
1
Carry bag 1 un.
2
Base 1 un.
3
Profiles set (A), (B) y (C). 1 un.
2.
3.
A
B
C
4160.
Net Weight 12 Kg
1 x LED STRIP 24V 21,6W
ASSEMBLY INSTRUCTIONS
Maintenance
-Use a slightly-wet cotton cloth for cleaning.
-In case of malfunction or damage, please contact the retailer who sold the lamp.
1.
Remove the top (A) and side (B and C) profiles from the
carry bag and lay them out. Place the base (D) where you
want to install the lamp. Keep in mind that the distance
between the center of the base and the fixation point must
be 2.23 mt. Approx.
2. Connect the top profile (A) to the side one (B) making
sure the release button (F) is in place (G).
NOTE: When assemblying the lamp, gently pull the cable
on the lower part of the side profile (see Detail X).
3. Connect the top profile (A) to the short one (C) making
sure the button is in place, just like Step 2.
4. Connect the side profile (B) to the base (D) with the cable
facing the fabric handle (H).
Keep the button (I) pressed when connecting the profile,
push downwards until a click is heard and the profile is in
place (J).
5. Fix the clamp (E) to a table or to the rail . The distance of
the clamp from the ground must be 0.75 mt. approx.
The piece (K) can be installed in two position depending on
the thickness of the table or rail.
Fix everything in place by tightening the nut (L).
6. Once installed, the lamp can rotate 360º, as shown in
Detail Y.
360
DETAIL Y
3
6
4
5
A
B
F
G
2
B
G
A
C
D
B
I
H
J
8 cm.
Max.
C
E
L
K
DETAIL X
8 - 13,5 cm.
Max.
C
E
K
L
B
A
E
D
C
0,75 mt.
Aprox.
2
nd
3
rd
5
th
4
th
2,23 mt.
1
“Click”
