Verykool S815 User manual
1
VERYKOOL® 2011 Copyright
All Rights Reserved
Reproduction, transfer, distribution or storage of
part or all of the contents in this document in any
form is illegal without the prior written permission
as VERYKOOL.
Statement
Some contents of this manual maybe different
from the mobile phone when you using. Please
refer to the mobile phone. VERYKOOL reserves
the right to revise this document or withdraw it at
any time without prior notice.
2
Contents
1.1 Phone and fittings........................... 4
1.2 Available network and service ....... 4
1.3 Keys and Parts ................................ 5
1.4 Screen icons.................................... 8
2. INSTALL AND CHARGE .........10
2.1 Install USIM and Memory card ..... 10
2.2 Insert & Remove battery............... 10
2.3 Charge the battery..........................11
2.4 Switch the device on & off............ 13
3. FUNCTIONS ............................14
3.1 Calls................................................ 14
3.2 Messages....................................... 15
3.3 Contacts......................................... 20
3.4 Call record ..................................... 23
3.5 Camera........................................... 24
3
3.6 Entertainment ................................ 25
3.7 Music.............................................. 31
3.8 File manager.................................. 33
3.9 Profiles........................................... 33
3.10 Settings........................................ 35
3.11 Tools............................................. 41
3.12 Bluetooth ..................................... 42
3.13 Browser........................................ 44
3.14 SIM Tool Kit.................................. 45
4. FAQS .......................................46
5. SAFETY INFORMATION.........49
4
1. UNDERSTAND YOUR PHONE
1.1 Phone and fittings
Unpack the phone package and confirm that all the
accessories of the phone are complete.
Phone
Charger
Lithium battery
Earpiece
Data line
User manual
Certificate of quality
After-sales service manual
For any missing parts or missing pages of the User
Manual, please contact the local distributor.
1.2 Available network and service
The device described in this guide is approved for using
on:
5
UMTS band: 850MHz, 900MHz, 1900MHz and 2100MHz
GSM bands: 850MHz, 900MHz, 1800MHz and 1900MHz
Tips:
Contact with your service provider for more detail
information about the networks.
To use the device you must have service from your
service provider. Some of them require special network
features which are not available on all networks. And
others may require that you make specific arrangements
with your service provider before you can use the
network services. Using network service involves
transmission of data, check with your service provider for
more detail information about fees in your home network
and when roaming on other networks.
1.3 Keys and Parts
1.3.1 Getting know your phone
6
1. USB/Charge connector
2. Earpiece jet
3. Volume up key
4. Volume down key
5. OK key
6. Left soft key (LSK)
7. Dial key
8. Contacts key
9. Menu key
10. Right soft key (RSK)
11. Power key/End key: Press and hold to Power on/off
7
the device.
12. Keyboard: Your device has a full keyboard. You can
find the most common punctuations the keyboard.
Alternatively, you can enter the punctuation marks by
using some key combinations.
13. Camera lens
14. Speaker
1.3.2 Text input setting
You can change Input mode and Default input mode
when you write text.
1. Select Option>input mode, and then select the input
method you want or press key to change input
method directly
2. Select Option>Default input method, and then you
can set a special input method as your default input
method.
3. Press key and then you can enter the
corresponding symbol on the full keyboard, also you can
Press key to select the symbol you want.
8
4. key is to achieve switching between ABC and
abc.
1.4 Screen icons
In Standby mode, you may view icons on the above of
screens as follows:
Icon Description
GSM network signal strength
UMTS network signal strength
Battery capability
Insert a Memory card
Connect with an USB cable
Missed voice calls
Missed video calls
Unread MMS; flash when the storage is full
Unread SMS; flash when the storage is full
Current mode is General
Current mode is Meeting
9
Current mode is Silent
Current mode is Car
Current mode is Outdoor
Current mode is Customize
The phone is locked
Bluetooth is opened
Plug in an earpiece
Set an alarm and turn on
Set an event and open
Play music in background
Play FM in background
Turn on voice call diverting
Turn on video call diverting
Turn on voice and video call diverting
