Verbatim Verbatim KW7002 User manual

Combo Peripherals

Expand your horizons with Kouwell

www.verbatim.com.au

Interface Cards- Combo

KW7002- Kouwell PCI FireWire/USB 2.0 Combo Card

• Chipset: IEEE1394-VIA/USB-NEC

• IEEE 1394a:

-Two external and one internal ports

- Compliant with IEEE 1394-1394a (Data Rate 100/200/400 Mbps)

• USB 2.0:

-Two external and one internal ports

- Compliant with USB speciﬁcation Rev 2.0 (Data Rate 1.5/12/480 Mbps)

• Hot swapping & plug’n’play

• Compatible with Windows 98SE, ME, 2000, XP

KW7004- Kouwell Cardbus FireWire/USB 2.0 Combo Card

• IEEE 1394a:

-Two IEEE 1394a ports (one 6 pin and one 4 pin)

- Compliant with IEEE 1394-1995, 1394a (Data Rate 100/200/400 Mbps)

• USB 2.0:

-Two USB 2.0 ports

- Compliant with USB 2.0 (Data Rate 1.5/12/480 Mbps)

• Supports 32 bit CarBus interface

• Compatible with Windows 98SE, ME, 2000, XP

LAPTOP

USERS

KW7003- Kouwell PCI FireWire & PC Card/Cardbus Card

• CardBus- RICOH/IEEE1394-T1

• Dual Cardbus slot

- Supports PCMCIA 16 bit/Cardbus 32 bit spec. under Windows XP OS

- Supports standard Cardbus 32 bit spec under Windows 95/98/ME/2000

•Triple external IEEE 1394a ports

- Compliant with IEEE 1394-1995, 1394a (Data Rate 100/200/400 Mbps)

- One port in front panel; two ports in rear bracket

• Compatible with Windows 98SE, ME, 2000, XP

4+2PORTS

DUAL

CARDBUS

SLOT

Multifunction Bays & Hubs

KW7102- Kouwell 3.5” FireWire/USB 2.0 Combo Hub

• IEEE 1394a:

- Four external and two internal IEEE 1394a ports

- Compliant with IEEE 1394-1995, 1394a (DataRate 100/200/400 Mbps)

• USB 2.0:

- Four external and one internal USB 2.0 ports

- Compliant with USB 2.0 (Data Rate 1.5/12/480 Mbps)

• Hot-Swapping and Plug’n’Play

• Compatible with Windows 98SE, 2000, ME, XP

FRONT

BAY

Combo Peripherals

Expand your horizons with Kouwell

www.verbatim.com.au

KWF8205- Kouwell 7-in-1 Multifunction 3.5” Bay

• Compliant for internal or external use- Can be installed into a computer drive

bay or used externally

• Card Reader:

- Compliant with USB speciﬁcation Revision 2.0 (Data Rate 1.5/12/480 Mbps)

- Supports flash memory card types: CF (Type I & II), MD, SD, MMC, SM,

MS, MS Pro

• USB 2.0 Hub:

-Three downstream ports

• Hot-Swapping and Plug’n’Play

• Compatible with Windows 98SE, ME, 2000, XP

KWF7209- Kouwell 9-in-1 Multifunction 5.25” Bay

• Card Reader:

- Compliant with USB speciﬁcation Revision 2.0 (Data Rate 1.5/12/480 Mbps)

- Supports ﬂash memory card types: CF (Type I & II), MD, SM, SD, MMC,

MS, MS Pro

• USB 2.0 Hub:

-Two USB 2.0 ports at 1.5/12/480 Mbps

• IEEE 1394 Repeater:

-Two 1394a ports at 100/200/400 Mbps

• Audio Socket:

- External audio port: MIC/Line In/Line Out

• Compatible with Windows 98SE, ME, 2000, XP

Verbatim is the exclusive distributor of Kouwell products throughout Australia

and New Zealand. For more information on these products,

visit www.verbatim.com.au

9-in-1

7-in-1

Multifunction Bays & Hubs (cont.,)

This manual suits for next models
