Vent-Axia QP Series Assembly instructions
Installation and Wiring Instructions
PLEASE READ ALL INSTRUCTIONS CAREFULLY BEFORE STARTING
INSTALLATION.
THESE INSTRUCTIONS SHOULD BE LEFT WITH THE END USER.
Acous
tic
Fans
Singl
In-lin Duct Fan Rang (QP)
QP100C
QP125C
QP150C
QP160C
QP200C
QP250C
QP315C
QP400C
QP500C
2
READ AND SAVE THESE INSTRUCTIONS
PLEASE READ ALL INSTRUCTIONS CAREFULLY BEFORE STARTING INSTALLATION.
INSTALLATION AND WIRING INSTRUCTIONS SHOULD BE LEFT WITH END USER.
Air moving equipment ma present mechanical, electrical or noise hazards. To minimize
risks associated with these potential hazards, it is essential that safet , installation,
operation and maintenance instructions are followed. Implementation of these
instructions should alwa s be undertaken b technicall competent personnel.
Potential mechanical hazards must be eliminated b guarding against access to the
rotating parts whilst the air moving equipment is operating. A range of guards are
available for this purpose from Vent-Axia.
Installation work, both mechanical and electrical, must be undertaken in accordance
with the safet and installation instructions before switching on the unit.
Maintenance work should not be attempted before first switching off and isolating the
fan and its control from the electrical suppl and ensuring that it cannot be accidentall
turned back on again. It is essential to ensure that rotating parts have come completel
to rest before maintenance work commences.
Air moving equipment ma generate unacceptable noise levels when in operation. It
ma be necessar to take appropriate action to reduce sound levels. A range of products
are available for this purpose from Vent-Axia.
This appliance is not intended for use b persons (including children) with reduced
ph sical, sensor or mental capabilities or lack of experience and knowledge unless the
have been given supervision or instruction concerning use of this appliance b a person
responsible for their safet .
Young children should be supervised to ensure that the do not pla with the appliance.
IMPORTANT
1. All electrical connections should be made b a properl qualified electrician. The
fan must be sited and connected in accordance with current I.E.E Wiring
Regulations, BS7671 (U.K.), or the appropriate standards in our countr .
2. DO NOT use this appliance when the following are generated or present: Excessive
grease or oil laden air, corrosive or flammable atmospheres.
3. When the fan is installed in a room containing a fuel burning appliance, the
installer must ensure that the air replacement is adequate for both the fan and
the fuel burning appliance.
4. If a fan is used to suppl air into a room, the installer must ensure that the fan
intake is located at least 600mm awa from an flue outlet.
5. Site awa from direct sources of heat. Ambient temperature range:-10oC to
+40oC.
6. When installing unit, take care not to damage electrical or other hidden utilities.
7. Check the details on the rating label for correct voltage, frequenc , speed, phase
insulation class and IP rating.
3
8. It is the responsibilit of the installer to ensure that all aspects of s stem design
are taken into consideration.
9. Due to the weight of units it is recommended that two people are involved in the
installation.
FAN MOUNTING
1. Short duct runs terminating close to the fan (i.e. within 1.5m) require suitable
guards.
2. The fan can be mounted in a variet of wa s and at an angle to suit the
application.
3. Plan the installation carefull , taking into consideration the safet points noted
above, before securel fixing the fan using appropriate screws, bolts, rubber
bushes, etc.
4. A range of accessories is available from Vent-Axia to assist installation including
flexible connectors, mounting feet, anti-vibration mounts and attenuators.
5. For horizontal installations onto a flat roof or flat ceiling, a fixing bracket is
provided with sizes 100 to 250.
6. If the fixing bracket is used, firstl bolt the bracket to the roof or ceiling. Latch
the QP into the 2 x bracket slots, as shown, then rotate and secure with 2 further
bolts (Fig. 1).
7. Tighten all bolts.
8. If the fixing bracket cannot be used, 4 x Ø10mm clearance holes are provided for
roof hanger rods.
9. With the larger 315, 400 and 500 fan sizes, parallel fixing brackets are provided
for both sides of the unit (Fig. 2), and because of the additional weight of these
sizes, extra fixing holes are provided for additional hanger rods.
Locate QP
into ceiling
bracket
Rotate QP
and secure
fixing
screws
Fig. 1: Location of
QP
unit in overhead fixing bracket
4
10.Suitable fixing means are provided b the installer for an other installation
orientation other than horizontal.
GENERAL WIRING INSTRUCTIONS
WARNING – THE FAN AND ANY ANCILLARY CONTROL EQUIPMENT MUST BE
ISOLATED FROM THE POWER SUPPLY DURING INSTALLATION AND/OR
MAINTENANCE. THE EQUIPMENT MUST BE EARTHED.
1. All electrical connections should be made b a properl qualified electrician.
2. All wiring and connections must be carried out in accordance with current
regulations.
3. To compl with safet standards, an all pole isolator switch with a contact gap of
at least 3mm must be fitted adjacent to the fan.
4. Remove the main product lid to expose the main terminal block and the thermal
protection block (TK) if fitted. The thermal protection device fitted is an automatic
resetting t pe which must alwa s be included in the circuit. For ducted applications
a manual reset is required, an ancillar circuit will be required with the TK switch
connected into the circuit. See page 6 for instructions.
5. Connect the power suppl from the local isolator (via an appropriate controls if
fitted) to the terminal block via the supplied cable gland (replace the grommet in
the unit casing with the supplied cable gland) using between 4.0mm and 7.0mm
diameter cable. Refer to the wiring diagrams and select the appropriate
connections for the fan, controller or other devices as being installed. If in doubt
please ask.
6. CAUTION: In order to avoid a hazard due to inadvertent resetting of the thermal
cut-out, this appliance must not be supplied through an external switching device,
such as a timer, or connected to a circuit that is regularl switched on and off b
the utilit .
7. Ensure that all earth connections have been made.
8. After making connections, replace the main product lid. Also ensure that all cable
gland nuts, grommets etc. have been used correctl .
Fig. 2: Support bracket used on larger
QP
unit.
Additional support
bracket fixing holes
provided for 315,
400 and 500 size
units.
5
NOTES ON RUNNING
B for Conn cting th pow r supply and running th Fan Ch ck…
Are all links and wiring complete as per wiring diagram?
Are all fixings secured?
Are all relevant guards fitted?
Are all Circuit protection devices fitted?
Are all Terminal box covers and sealing glands secured?
Are all Earth connections secured?
Check that no hazard exists for persons in the localit of the fan. Switch on the fan and
check that the fan rotation is correct as per the direction arrows on the fan plate/casing.
If not isolate power suppl and check wiring. Check that the current (amps) taken b
the fan does not exceed the current shown on the rating plate.
INSTALLER AND ELECTRICAL CONTRACTOR RESPONSIBILITY
Vent-Axia Ltd, as suppliers of the equipment cannot be responsible for the final
installation and electrical connection of the product on site. We have made reasonable
effort to offer guidance and assistance but the installer and electrical contractor on site
have a responsibilit for ensuring the equipment is safel and securel installed and
electricall /mechanicall safe in accordance with statutor requirements.
The fans are supplied as a component to be incorporated into a ventilation s stem. The
final complete s stem installation that includes the fans MUST meet the requirements
of:-
Low voltage Directive 72/23/CEE
Machiner Directive 89/392/CE
Electromagnetic Compatibilit Directive 89/336/CE
If the fan is installed in an area where there is possible danger to safet or health then
guards MUST be fitted.
Guards suitable for man applications are available from Vent-Axia Ltd.
Please remember that fans need maintenance, cleaning and inspection. Allow for
reasonable access for these operations to be carried out safel .
If in doubt, please ask.
ROUTINE INSPECTION/MAINTENANCE
THIS MUST BE UNDERTAKEN BY A COMPETENT PERSON.
ISOLATE UNIT FROM ELECTRICAL SUPPLY AND ENSURE THAT IT CANNOT BE
ACCIDENTALLY TURNED BACK ON.
1. We recommend that after three months the fan should be inspected and cleaned
to remove deposits on the impeller or motor. Thereafter, it should be checked and
cleaned periodicall as experience dictates, or at least twice a ear.
2. If a build-up of dirt/deposits is evident then this should be carefull cleaned off.
Please take care not to damage the fan or affect the balance of the impeller motor
assembl (balance weights ma be fitted to the impeller).
3. The fan motors are fitted with ‘sealed for life’ bearings and should not require
maintenance under normal circumstances.
6
Wiring Diagrams:
Important Not s:-
•For ducted applications the Thermal Protector (TK) must be connected into a
control circuit in order to ensure that the fan cannot restart before the fault
condition is cleared and the circuit manuall reset.
•To compl with the above statement, this product is intended for use with Vent-
Axia overload rela s or controls listed below.
V nt-Axia D.O.L. Start r/Ov rload and Sp d Controll r stock r f r nc
numb rs:
Product Start r Ov rload El ctronic
Controll r
El ctronic
Controll r
Auto
Transform r
Controll r
QP100C - - W10303102M
10303103A 10314103A
QP125C - - W10303102M
10303103A 10314103A
QP150C - - W10303102M
10303103A 10314103A
QP160C - - W10303102M
10303103A 10314103A
QP200C - - W10303102M
10303103A 10314103A
QP250C - - W10303102M
10303103A 10314103A
QP315C 444744 444700 - 10303103A 10314103A
QP400C 444744 444702 - 10303103A 10314103A
QP500C 444744 444702 - 10303106A 10314105A
Product Start r Ov rload Auto
Transform r
Controll r
D mand
Voltag
Controll r
D mand
Inv rt r
QP100C - - - 444164 444169
QP125C - - - 444164 444169
QP150C - - - 444164 444169
QP160C - - - 444164 444169
QP200C - - - 444164 444169
QP250C - - - 444164 444169
QP315C 444744 444700 - 444164 444169
QP400C 444744 444702 RTRE35 444164 444169
QP500C 444744 444702 RTRE60 444164 444169
7
Fig. 1
QP315C.
Connected to a D.O.L. starter
Fig. 2
QP100C, QP125C, QP150C, QP160C, QP200C, QP250C.
Suppl connections
*Not ; this diagram is not applicabl to QP315C!
8
Fig. 3
QP400C, QP500C.
Connected to a D.O.L. starter
Fig. 4
QP100C, QP125C, QP150C, QP160C, QP200C, QP250C.
Connected to an electronic controller
9
Fig. 5
QP315C.
Connected to a D.O.L. starter and electronic controller
Fig. 6
QP100C, QP125C, QP150C, QP160C, QP200C, QP250C.
Connected to an electronic controller
This manual suits for next models
9
Table of contents
Other Vent-Axia Fan manuals
Vent-Axia
Vent-Axia T Series Assembly Instructions
Vent-Axia
Vent-Axia Lo-Carbon Sylph 100CV Assembly instructions
Vent-Axia
Vent-Axia Lo-Carbon Silhouette Series Assembly instructions
Vent-Axia
Vent-Axia SUPRA 100 B Assembly instructions
Vent-Axia
Vent-Axia Lo-Carbon Responce Series Assembly instructions
Vent-Axia
Vent-Axia Silhouette SELV 12 Series User manual
Vent-Axia
Vent-Axia Lo-Carbon SOLO Plus SELV Assembly instructions
Vent-Axia
Vent-Axia RMV 200 User manual
Vent-Axia
Vent-Axia FAN7200 User manual
Vent-Axia
Vent-Axia Vent-A-Light Lo-Carbon Series Assembly instructions
Vent-Axia
Vent-Axia LuminAir Kit L User manual
Vent-Axia
Vent-Axia 427477A Assembly instructions
Vent-Axia
Vent-Axia T-Series Assembly Instructions
Vent-Axia
Vent-Axia SUPRA 100 T Assembly instructions
Vent-Axia
Vent-Axia ATQ 400-14C Assembly instructions
Vent-Axia
Vent-Axia VSC Series Assembly instructions
Vent-Axia
Vent-Axia Lo-Carbon VA100 LP Assembly instructions
Vent-Axia
Vent-Axia sentinel Kinetic MVHR series Guide
Vent-Axia
Vent-Axia MVDC-MSH UniFlex Assembly instructions
Vent-Axia
Vent-Axia SOLO Plus Assembly instructions
Popular Fan manuals by other brands
ELTA FANS
ELTA FANS H03VV-F installation guide
Hunter
Hunter 20714 Owner's guide and installation manual
Emerson
Emerson CARRERA VERANDA CF542ORB00 owner's manual
Hunter
Hunter Caraway Owner's guide and installation manual
Panasonic
Panasonic FV-15NLFS1 Service manual
Kompernass
Kompernass KH 1150 operating instructions
