Vent-Axia Silhouette 100B Assembly instructions

Installation and Wiring Instructions

Stock Ref. N°

45 40 55A (100B)

45 40 59A (150X)

45 40 56A (100T)

45 40 60A (150XT)

45 40 57A (100H)

45 40 61A (150XH)

45 40 58A (100TM)

PLEASE READ INSTRUCTIONS IN CONJUNCTION WITH ILLUSTRATIONS.

PLEASE SAVE THESE INSTRUCTIONS.

Silhouette

IPX4

220-240V~50Hz

Vent-

CE:

Installation and Wiring Instructions for the Silhouette Range of Extractor Fans.

IMPORTANT:

READ THESE INSTRUCTIONS

BEFORE COMMENCING THE

INSTALLATION

DO NOT install this product in areas where the following may be present or occur:

•Excessive oil or a grease laden atmosphere.

•Corrosive or flammable gases, liquids or vapours.

• Ambient temperatures higher than 40°C or less than –5°C.

• Possible obstructions which would hinder the access or removal of the Fan.

SAFETY AND GUIDANCE NOTES

A. All wiring to be in accordance with the current I.E.E. Regulations, or the appropriate

standards of your country and MUST be installed by a suitably qualified person.

B. The Fan should be provided with a local isolator switch capable of disconnecting all poles,

having a contact separation of at least 3mm.

C. Ensure that the mains supply (Voltage, Frequency, and Phase) complies with the rating

label.

D. The Fan should only be used in conjunction with the appropriate Vent-Axia products.

E. The fan should only be used in conjunction with fixed wiring.

F. When the Fan is used to remove air from a room containing a fuel-burning appliance,

ensure that the air replacement is adequate for both the fan and the fuel-burning appliance.

G. The Fan should not be used where it is liable to be subject to direct water spray for

prolonged periods of time.

H. Where ducted Fans are used to handle moisture-laden air, a condensation trap should be

fitted. Horizontal ducts should be arranged to slope slightly downwards away from the Fan.

I. This appliance is not intended for use by persons (including children) with reduced physical,

sensory or mental capabilities, or lack of experience and knowledge, unless they have

been given supervision or instruction concerning use of the appliance by a person

responsible for their safety.

J. Children should be supervised to ensure that they do not play with the appliance.

K. Stationary appliances not fitted with means for disconnection from the supply mains having

a contact separation in all poles that provide full disconnection under over voltage category

III, the instructions state that means for disconnection must be incorporated in the fixed

wiring in accordance with the wiring rules.

DESCRIPTION

The Silhouette 100mm fan is an axial extraction fan suitable for domestic bathrooms

and W.C’s. The Silhouette 150mm fan is an axial extraction fan suitable for domestic

kitchens and utility rooms. They are available as wall or panel mounted models with

shutter timer, humidity and PIR combinations.

ACCESSORIES (not supplied)

WALL FITTING KIT

A range of 100mm and 150mm wall kits are

available for installing into most walls using

telescopic liners supplied.

White Brown

100 254102 254100

140/150 140902A 140903A

Stock Reference

A. INSTALLATION

IMPORTANT: The fan should only be used in conjunction with fixed wiring.

PANEL/CEILING MOUNTING

1. For panel/ceiling mounting the fan should be installed into a closed duct system

of at least 1.2m long or protected by an exterior air grille that must comply with

the standard requirements of your country to prevent access to the fans

impeller.

2. Cut a 105mm diameter hole for 100mm fans or a 155mm diameter hole for

150mm fans.

3. Loosen the screw at the bottom of the grille and remove the front grille. Mark

the screw centres through the holes in the fan back plate. Drill, plug and screw

into position.

4. Replace the grille and tighten the retaining screw.

5. After installation, ensure impeller rotates freely and the shutters can open.

WALL MOUNTING

1. For wall mounting either cut a 115mm diameter hole for 100mm fans or a

170mm diameter hole for 150mm fans, through the wall and insert the wall

sleeve. Slope the sleeve slightly downwards away from the fan. Cut to length

and cement both ends into position flush with the wall faces.

2. Loosen the screw in the bottom of the grille and remove the front grille. Mark

the screw centres through the holes in the fan back plate. Drill, plug and screw

into position. Fix exterior grille into position with the louvres positioned

downwards. (Note:- The grille must comply with the standard

requirements of your country to prevent access to the fans impeller. The wall kit

used in this installation should provide a minimum ducting length of 60mm from

the fans back plate to the inside of the external grille).

3. Replace the grille and tighten the retaining screw.

4. After installation, ensure impeller rotates freely and the shutters can open.

B. WIRING.

WARNING: THE FAN AND ANCILLARY CONTROL EQUIPMENT MUST

BE ISOLATED FROM THE POWER SUPPLY DURING THE

INSTALLATION / OR MAINTENANCE.

IMPORTANT

•The fan should only be used in conjunction with fixed wiring.

•The cross - sectional area of supply cord used should be ranged from 1 -

1.5mm2.

•Cable entry can only be made from the rear of the fan.

•The extraction fan is suitable for connection to 220-240V 50Hz supply.

•The fan is a class ll double insulated product and MUST NOT be earthed.

1. Select and follow the appropriate wiring diagram. (Fig. 2,3 or 4)

2. Check all connections have been made correctly and ensure all terminal

connections and cable clamps are securely fastened.

3. Ensure the impeller rotates and is free from obstructions.

C. SETUP

WARNING: THE FAN AND ANCILLARY CONTROL EQUIPMENT MUST

BE ISOLATED FROM THE POWER SUPPLY DURING THE

INSTALLATION / OR MAINTENANCE.

SILHOUETTE 100B/150X

Single speed fan. Controlled by remote switch (e.g. light switch or auto sensor) Fig.2.

SILHOUETTE 100T/150XT

Single speed with overrun timer. The fan can be wired to a lighting circuit switch.

Fig.4. or wired for a basic on/off operation wire as Fig 3.

When switched ‘ON’, the fan will operate at full speed and will continue to run for a

pre-set time after the switch is turned ‘OFF’.

TIMER ADJUSTMENT

BEFORE ADJUSTING THE TIMER, SWITCH OFF THE MAINS SUPPLY.

TIMER SHOULD ONLY BE ADJUSTED BEFORE OR DURING

INSTALLATION.

1. Remove the fan grille. The controller is factory set at 15 minutes approx.

The overrun time period can be adjusted from 5-25 minutes by altering

the adjuster on the control PCB.

2. To REDUCE the operating time, use a small screwdriver to turn the

adjuster Fig.5. ANTI-CLOCKWISE.

3. To INCREASE the operating time, use a small screwdriver to turn the

adjuster Fig.5. CLOCKWISE.

4. Replace the fan grille.

SILHOUETTE 100H/150XH

The fan contains an integral humidity controller. In automatic mode the controller

switches the fan on at full speed when the room Relative Humidity (RH) reaches the

set-point. The fan will continue to run until the room RH falls below the set-point.

Fig 2 and 6.

HUMIDITY SET-POINT ADJUSTMENT

BEFORE ADJUSTING THE CONTROLLER, SWITCH OFF THE MAINS

SUPPLY. HUMIDISTAT SHOULD ONLY BE ADJUSTED BEFORE OR

DURING INSTALLATION.

1. Remove the fan grille. The controller is factory set to switch on at about

70% RH. The humidity set point can be adjusted from 65-95%RH by

altering the adjuster on the control PCB.

2. To LOWER the set-point use a small screwdriver to turn the adjuster

Fig.6. ANTI-CLOCKWISE. This makes the controller MORE sensitive.

3. To RAISE the set-point use a small screwdriver to turn the adjuster Fig.6.

CLOCKWISE. This makes the controller LESS sensitive.

4. Replace the fan grille.

NOTE! DO NOT TOUCH HUMIDITY SENSOR.

SILHOUETTE 100TM

Single speed with PIR (passive infra-red) detector and overrun timer. The fan starts

automatically when a movement is detected and will continue to operate for the set

overrun time period.

(See ‘Timer Adjustment’ section above) Fig. 2 and 5.

D. SERVICING AND MAINTENANCE.

WARNING: THE FAN AND ANCILLARY CONTROL EQUIPMENT MUST

BE ISOLATED FROM THE POWER SUPPLY DURING MAINTENANCE.

1. At intervals appropriate to the installation, the fan should be inspected and

cleaned to ensure there is no build up of dirt or other deposits.

2. Wipe the inlets and front face with a damp cloth until clean.

The fan has sealed for life bearings, which do not require lubrication.

Fig.1.

Fig.4

Fig.2

Fig.3

Timer model wired as a Basic version (link between L & LS enables fan to switch on or off when power is put onto the fan).

Fig.6.

Humidity

Adjustment

Fig.5.

Timer

Adjustment

abc

Head Office: Fleming Way, Crawley, West Sussex, RH10 9YX. Tel: 01293 526062 Fax: 01293 551188

UK NATIONAL CALL CENTRE, Newton Road, Crawley, West Sussex, RH10 9JA

SALES ENQUIRIES: Tel: 0844 8560590 Fax: 01293 565169

TECHNICAL SUPPORT: Tel: 0844 8560593 Fax: 01293 539209

For details of the warranty and returns procedure please refer to www.vent-axia.com or write to Vent-Axia Ltd, Fleming Way, Crawley, RH10 9YX

439014H 0111

Fan

FUSE

1 PHASE SUPPLY

(220-240V 50Hz). FUSE

SWITCHED

FUSED

SPUR

Fan

1 PHASE SUPPLY

(220-240V 50Hz). FUSE

SWITCHED

FUSED

SPUR

Fan

----

---

----------

-------

,//

-·----------

~·

-··

----

~To D

E:J

C)>-+---------

----1----

I @)) i

Lamp

3 POLE

ISOLATOR

SWITCH

--~--

---

~,,

___

_.)
