Vega VEGAPULS WL 61 User manual
Mounting instructions
Rinsing connection
for VEGAPULS WL 61, 61, 64, 67 and 69
Document ID: 49552
2
Contents
Rinsing connection • for VEGAPULS WL 61, 61, 64, 67 and 69
49552-EN-200717
Contents
1 For your safety ......................................................................................................................... 3
1.1 Authorised personnel ....................................................................................................... 3
1.2 Appropriate use................................................................................................................ 3
1.3 Warning about incorrect use............................................................................................. 3
1.4 General safety instructions............................................................................................... 3
2 Product description ................................................................................................................. 4
2.1 Conguration.................................................................................................................... 4
2.2 Principle of operation........................................................................................................ 4
3 Mounting................................................................................................................................... 7
3.1 Mounting preparations ..................................................................................................... 7
3.2 Mountingstepscompressionange,adapterangeASME3"......................................... 7
3.3 Mountingsteppsadapterangesfrom4"/DN100............................................................ 7
4 Supplement .............................................................................................................................. 9
4.1 Technical data .................................................................................................................. 9
4.2 Dimensions .................................................................................................................... 10
4.3 Industrial property rights................................................................................................. 11
4.4 Trademark ...................................................................................................................... 11
Safety instructions for Ex areas
PleasenotetheEx-specicsafetyinformationforinstallationandop-
eration in Ex areas. These safety instructions are part of the operating
instructions and come with the Ex-approved instruments.
Editing status: 2020-07-17
3
1 For your safety
Rinsing connection • for VEGAPULS WL 61, 61, 64, 67 and 69
49552-EN-200717
1 For your safety
1.1 Authorised personnel
All operations described in this operating instructions manual must be
carriedoutonlybytrainedqualiedpersonnelauthorisedbytheplant
operator.
During work on and with the device, the required personal protective
equipment must always be worn.
1.2 Appropriate use
The rinsing connection is an accessory part for VEGAPULS WL 61,
61, 64, 67 and 69 radar sensors.
Youcannddetailedinformationabouttheareaofapplicationin
chapter"Product description".
1.3 Warning about incorrect use
Inappropriate or incorrect use of the instrument can give rise to
application-specichazards,e.g.vesseloverllordamagetosystem
components through incorrect mounting or adjustment.
1.4 General safety instructions
The safety information in the operating instructions manual of the
respective sensor must be noted.
4
2 Product description
Rinsing connection • for VEGAPULS WL 61, 61, 64, 67 and 69
49552-EN-200717
2 Product description
2.1 Conguration
The scope of delivery encompasses:
• Rinsing connection
• Reuxvalve(optional)
• Mountingscrews(versionforadapterange)
• Documentation
– These mounting instructions
The rinsing connection is available in two versions:
• Fordeviceswithcompressionangeoradapterange3"
• Fordeviceswithadapterangefrom4"/DN100
A B
1
2
33
Fig. 1: Conguration and versions, rinsing connection
A For compression ange or adapter ange 3"
B For adapter ange from 4"/DN 100
1 O-ring seal
2 Air nozzles
3 Reux valve
2.2 Principle of operation
The rinsing connection is suitable for VEGAPULS WL 61, 61, 67 and
69radarsensorswiththefollowingprocessttings:
• CombicompressionangeDN80,ASME3",JISDN8010Kas
wellasadapterangeASME3"
• AdapterangefromDN100,ASME4",JISDN10010K
Note:
TheinstrumentangemustbeofmaterialPP-GF30(colourblack).
Scope of delivery
Versions
Area of application
5
2 Product description
Rinsing connection • for VEGAPULS WL 61, 61, 64, 67 and 69
49552-EN-200717
1
2
3
Fig. 2: Rinsing connection with radar sensor with compression ange or adapter
ange ASME 3"
1 Compression ange or adapter ange ASME 3"
2 Reux valve
3 Rinsing connection
3
21
Fig. 3: Rinsing connection with radar sensor with adapter ange in other sizes
1 Rinsing connection
2 Reux valve
3 Adapter ange
Bulk solids applications
The rinsing connection is used to blow compressed air into the
antenna area of the radar sensor.This protects the surfaces of the
antennasystemagainstdustorcondensation.Youcannddetailed
specicationsontheairvolume/pressureinchapter"Technical data".
Liquid applications
The rinsing connection is used for cyclic injection of clean water or
someothersuitablecleaninguidintotheantennaareaoftheradar
sensor. This protects the surface of the antenna system against
buildupordeposits.Continuousinjectionofuidisnotrecommended.
Theoptionalreuxvalvekeepsprocessairoutofthesystem.
Functional principle
Reuxvalve
6
2 Product description
Rinsing connection • for VEGAPULS WL 61, 61, 64, 67 and 69
49552-EN-200717
InExapplications,thereuxvalveisabsolutelyrequired.
Sensorwithcompressionange
Therinsingconnectionisinstalledbetweensensorandvesselange.
The sealing to the sensor is carried out with the supplied O-ring seal-
ing,tothevesselangethroughtheatsealingfromcustomerside.
Sensorwithadapterange
Therinsingconnectionisinstalledbetweenadapterringandange.
Thesealingeachtothesensorandsensorangeiscarriedoutviaa
suppliedO-ringsealing.Thesealingoftheadapterangetotheves-
selangeiscarriedoutthroughtheatsealingfromcustomerside.
Mounting
7
3 Mounting
Rinsing connection • for VEGAPULS WL 61, 61, 64, 67 and 69
49552-EN-200717
3 Mounting
3.1 Mounting preparations
Required tools:
• Torxwrench,sizeT25
3.2 Mountingstepscompressionange,adapter
angeASME3"
Proceed as follows:
1. Applyatseal(providedbythecustomer)totheprocessange
2. Placerinsingconnection(withthesmoothlowersurface)ontothe
processange
1
2
3
4
5
6
Fig. 4: Mounting of the rinsing connection with compression ange and adapter
ange ASME 3"
1 Compression or adapter ange ASME 3"
2 O-ring seal
3 Rinsing connection
4 Reux valve
5 Process seal (provided by customer)
6 Process ange
3. Insert O-ring seal into the groove on the upper side of the rinsing
connection
4. Screwreuxvalve(optional)intotherinsingconnection
5. SetsensorwithcompressionoradapterangeASME3"torins-
ing connection
6. Tightenangescrewsevenly,e.g.crosswiseintwoorthree
passes.Tighteningtorque,seechapter"Technical data".
3.3 Mountingsteppsadapterangesfrom4"/
DN 100
Proceed as follows:
1. Loosen mounting screws of the adapter ring, detach adapter ring
Tool
8
3 Mounting
Rinsing connection • for VEGAPULS WL 61, 61, 64, 67 and 69
49552-EN-200717
2. Place rinsing connection with its smooth lower surface onto the
adapterange,makingsurethattheO-ringsealisnotdisplaced.
1
2
3
4
5
6
7
Fig. 5: Mounting of the rinsing connection with adapter ange
1 Adapter ring
2 Mounting screws
3 O-ring seal
4 Rinsing connection
5 Reux valve
6 O-ring seal
7 Adapter ange
3. Insert O-ring seal into the groove on the upper side of the rinsing
connection
4. Screwreuxvalve(optional)intotherinsingconnection
5. Insertthesupplied(longer)mountingscrewsintotheadapterring
6. Tighten mounting screws evenly, e.g. crosswise in two or three
passes.Tighteningtorque,seechapter"Technical data".
9
4 Supplement
Rinsing connection • for VEGAPULS WL 61, 61, 64, 67 and 69
49552-EN-200717
4 Supplement
4.1 Technical data
Materials,weights,torque
Materials
ƲRinsing connection PPGFK
ƲO-ring seal FKM,(SHSFPM70C3GLT),EPDM(COGAP310)
Ʋ Reuxvalve 316Ti
Ʋ Sealing,reuxvalve FKM,(SHSFPM70C3GLT),EPDM(COGAP310)
Weights, rinsing connection
Ʋ Forcompressionange approx.300g(0.661lbs)
Ʋ Foradapterange approx.350g(0.772lbs)
Torques
Ʋ Flangescrews,compressionange
DN80
5Nm(3.689lbfft)
ƲMounting screws, adapter ring 2.5Nm(1.844lbfft)
Ʋ Flangescrews,adapterangeDN100 7Nm(5.163lbfft)
Data on rinsing air connection
Max. permissible pressure 6bar(87.02psig)
Airvolume,dependingonpressure(recommendedrange)
Pressure Air volume
Withoutreuxvalve Withreuxvalve
0.2bar(2.9psig) 3.3 m3/h -
0.4bar(5.8psig) 5 m3/h -
0.6bar(8.7psig) 6 m3/h 1 m3/h
0.8bar(11.6psig) - 2.1 m3/h
1bar(14.5psig) - 3 m3/h
1.2bar(17.4psig) - 3.5 m3/h
1.4bar(20.3psig) - 4.2 m3/h
1.6bar(23.2psig) - 4.4 m3/h
1.8bar(20.3psig) -4.8m3/h
2bar(23.2psig) - 5.1 m3/h
Thread G⅛
Reuxvalve-unmounted(asoptionwithnon-Exversion,includedinthescopeofdeliverywithEx
version)
ƲThread G⅛
ƲFor connection G⅛
ƲOpening pressure 0.5bar(7.25psig)
10
4 Supplement
Rinsing connection • for VEGAPULS WL 61, 61, 64, 67 and 69
49552-EN-200717
Process conditions
Vessel pressure -0.1…2bar(-1.45…29.00psig)/-10…200kPa
Process temperature -40…80°C(-40…176°F)
4.2 Dimensions
Rinsing connection
26 mm
(1.02")
28,5 mm
(1.12")
ø 143 mm
(5.63")
ø 95 mm
(3.74")
ø 123 mm
(4.84")
ø 75 mm
(2.95")
1 2
Fig. 6: Dimensions, rinsing connection
1 For compression ange, adapter ange ASME 3"
2 For adapter anges from 4"/DN 100
