Varytec Studio Par II CDM 150 User manual

User’s manual

Studio Par II CDM

150

2 / 9

Table of content

1. Safety instructions........................................................................................................................... 3

2. Color frame retaining clip................................................................................................................ 4

3. Cleaning the reflector...................................................................................................................... 4

4. Installing the lamp........................................................................................................................... 5

5. Lens identification........................................................................................................................... 6

6. Changing CDM PAR lenses ........................................................................................................... 6

6.1. Installing a lens ...................................................................................................................... 6

6.2. Removing a lens .................................................................................................................... 7

7. Technical data................................................................................................................................. 8

3 / 9

1. Safety instructions

FOR SAFE AND EFFICIENT OPERATION

Be careful with heat and extreme temperatureAvoid exposing it

to direct rays of the sun or near a heating appliance.

Not put it in a temperature bellow 41°F /5°C, or exceeding 95°F /35°C.

Keep away from humidity, water and dust

Do not place the set in a location with high humidity or lots of dust.

Containers with water should not be placed on the set.

Keep away from sources of hum and noise

Such as transformer motor, tuner, TV set and amplifier.

To avoid placing on un-stable location

Select a level and stable location to avoid vibration.

Do not use chemicals or volatile liquids for cleaning

Use a clean dry cloth to wipe off the dust, or a wet soft cloth for stubborn dirt.

If out of work, contact sales agency immediately

Any troubles arose, remove the power plug soon, and contact with an engineer for repairing,

do not open the cabinet by yourself, it might result a

danger of electric shock.

Take care with the power cable

Never pull the power cable to remove the plug from the receptacle, be sure

to hold the plug. When not using the player for an extended period of time

be sure to disconnect the plug from the receptacle.

4 / 9

2. Color frame retaining clip

The color frame holder is equipped with a spring-loaded retaining clip that prevents color frames and

accessories from falling out.

Warning! Hang the CDM PAR with the color frame retaining clip in the locked position

1. Release the retaining clip by pushing it sideways. The retaining clip opens.

2. Insert the color frame

3. press the retaining clip down until it locks.

Note: Use only color frames or top hats with 6.7 Inches inside diameter.

3. Cleaning the reflector

The following recommendations are offered when cleaning and inspecting lenses and reflectors.

Do not use glass and window cleaners on the reflector. Chemicals in these cleaners will ham the

reflective coatings.

Do not use paper towels or harsh materials to wipe the reflectors. These materials can scratch the

surface of the reflector.

Warning! Unplug the fixture before attempting to clean reflector.

1. Remove the lens so you can access the reflector from the front of the fixture. See removing a

lens in this manual.

2. Remove dust with a blast of oil free air, or wipe with a clean, soft, lint-free cotton cloth. If this is

sufficient to remove dust, go to step 5. otherwise continue with step 3.

3. Dampen a clean, soft, lint-free cotton cloth with a mild, soapy water solution and gently wipe

the reflector.

4. Remove any soapy water residue with a clean, soft, lint-free cotton cloth dampened with

water.

5. Reinstall a lens before using the fixture.

5 / 9

4. Installing the lamp

Always replace the lamp if it becomes damaged or deformed. Verify that the lamp you use is suitable

for the electronic power at your facility.

Caution! Operating lamps above or below their rated voltage reduces lamp life and can cause

premature lamp failure.

1. Disconnect the unit from power before installing the lamp.

Warning! Let lamp cool before changing.

2. Loosen the knurled bolt on the back of the lamp housing and pull the housing straight out from

the back of the fixture.

3. Remove the lamp from its box, holding it by the base.

Note: to avoid premature lamp failure, do not touch the lamp during installation, clean it

carefully with rubbing alcohol and a clean, lint-free cloth before operation.

4. Line up the flat sides of the lamp base with the brackets on either side of the socket. Figure 2

5. Push down on the lamp base until the lamp is firmly seated. Make sure that the lamp is fully

seated, with the bottom of the lamp heat sink flush to the lamp housing casting.

Caution: Improperly installed lamps cause premature lamp failure and socket

problems.

6. To reinstall the lamp housing, center it on the reflector and the bolt hole, then tighten the

knurled bolt to secure the lamp housing in place.

6 / 9

5. Lens identification

Lenses for the CDM PAR come in four versions. The type or beam spread can be identified by the

lens texture.

Very narrow spot Narrow Spot

Clear glass Stippie glass (slight diffuse texture)

15°round beam shape 19° round beam shape

Medium flood Wide flood

Fewer facets, sized 6 x 22mm Many facets, sized 6x12mm

21° x 34° oblong beam shape 30°x51° oblong beam shape

6. Changing CDM PAR lenses

Change lenses if they become cracked or badly scratched. Caution! Never operate the CDM PAR

without a lens in place.

6.1. Installing a lens

1. position the fixture with the front of the unit (the lens side) facing you, and tilted slightly.

(Figure 4)

2. Position the lens rotation ring with the spring clip at the top of the fixture, directlybelow the

retaining clip.

3. Hold the lens by the edge, and position it so the convex side faces the back of the fixture.

(Figure 3)

7 / 9

4. From the top of the fixture, slide the lens behind the lens catchers and position its base behind

the tabs on the bottom of the lens rotation ring.

5. gently push the top of the lens inward until it snaps behind the spring clip.

6.2. Removing a lens

Warning! Unplug the fixture before attempting to remove or install a lens.

1. Source CDM PAR lenses get hot while the unit is in operation. Let the fixture cool before

handling the lens.

2. Place the fixture on a flat, stable work surface. Do not install or remove lenses with the unit

hanging.

3. Position the lens rotation ring with the spring clip at the top of the unit, directly below the

retaining clip.

4. Tilt the front of the fixture down at least 45°

5. press the spring clip with your finger to release the lens (Figure 4)

6. allow the lens to drop forward from under the clip

7. when the lens drops, remove your finger, allowing the lens to slide forward until it rests on the

lens catchers (Fifure 5)

8. Carefully remove the lens from the fixture.

8 / 9

7. Technical data

Power supply

230-240V 50Hz

Power consumption

150W

Dimensions (L x W x H)

280 x 245 x 405

Weight

9,1kg

Fitting lamp

CDM-T lamps Base G12

Fuse

250V 4A

Max ambient temperature working

25°C

Max ambient temperature housing

70°C

Minimum distance

9 / 9

Importeur:

B & K Braun GmbH

Industriestraße 1

D-76307 Karlsbad

www.bkbraun.com

[email protected]om
