Varytec Prestige II User manual

User manual

Prestige II

2 / 10

Table of contents

Safety instructions............................................................................................................................ 3

1.1.

FOR SAFE AND EFFICIENT OPERATION............................................................................ 3

Technical Information....................................................................................................................... 4

DMX Mode ....................................................................................................................................... 4

3.1.

DMX chart 4 CH mode ............................................................................................................ 4

3.2.

DMX Chart 256 CH mode........................................................................................................ 5

Control of the Menu.......................................................................................................................... 6

4.1.

Menu structure......................................................................................................................... 6

4.2.

Description of the Menu........................................................................................................... 7

Master Slave configuration............................................................................................................... 8

Sound to Light..................................................................................................................................8

Technical Data ................................................................................................................................. 9

7.1.

Power daisy chain ................................................................................................................... 9

3 / 10

1. Safety instructions

•This device is suitable for indoor use only.

•All modifications to the device will void the warranty.

•Repairs are to carry out by skilled personnel only.

•Use only fuses of the same type and original parts as spare parts.

•Protect the unit from rain and humidity to avoid fire and electric shocks.

•Make sure to unplug the power supply before opening the housing.

1.1.FOR SAFE AND EFFICIENT OPERATION

Be careful with heat and extreme temperature

Avoid exposing it to direct rays of the sun or near a heating appliance.

Not put it in a temperature bellow 32°F /0°C, or ex ceeding 104°F /40°C.

Keep away from humidity, water and dust

Do not place the set in a location with high humidity or lots of dust.

Containers with water should not be placed on the set.

Keep away from sources of hum and noise

Such as transformer motor, tuner, TV set and amplifier.

To avoid placing on un-stable location

Select a level and stable location to avoid vibration.

Do not use chemicals or volatile liquids for cleaning

Use a clean dry cloth to wipe off the dust, or a wet soft cloth for stubborn dirt.

If out of work, contact sales agency immediately

Any troubles arose, remove the power plug soon, and contact with an engineer for repairing,

do not open the cabinet by yourself, it might result a danger of electric shock.

Take care with the power cable

Never pull the power cable to remove the plug from the receptacle, be sure

to hold the plug. When not using the device for an extended period of time, be sure to

disconnect the plug from the receptacle

4 / 10

Important: Damages caused by the disregard of this user manual are not subject to

warranty. The dealer will not accept liability for any resulting defects or

problems. Make sure the electrical connection is carried out by qualified

personnel. All electrical and mechanical connections have to be carried out

according to the European safety standards.

2. Technical Information

- RGBW LED

- DMX Mode (4Ch or 256Ch)

- Sound to light mode via internal mic

- 12 internal programs

- Digital display for addressing and functions

- Power and DMX can be daisy chained

3. DMX Mode

To use the DMX Mode you have to adjust the address first, as described a few articles below. The

item needs 4 channels or 256 Channels, which you can adjust by using your faders of your DMX

console. You can adjust as follows:

3.1.DMX chart 4 CH mode

CH1

CH2

CH3

CH4

Mode Pattern

Ch1= 10 - 99

Chase

Ch1= 100 – 239

Color

Ch1= 10 – 99

Chase Speed

Ch1= 100 - 239

Strobe

0 – 9

Off

10-99

Pattern

100 – 239

Chase

240 – 255

Sound Mo.

000 – 020

021 – 041

042 – 065

066 – 087

088 – 108

109 – 129

130 – 150

151 – 172

173 – 193

194 – 214

215 – 235

236 - 255

Pattern 1

Pattern 2

Pattern 3

Pattern 4

Pattern 5

Pattern 6

Pattern 7

Pattern 8

Pattern 9

Pattern 10

Pattern 11

Pattern 12

000 – 020

021 – 041

042 – 065

066 – 087

088 – 108

109 – 129

130 – 150

151 – 172

173 – 193

194 – 214

215 – 235

236 - 255

Chase 1

Chase 2

Chase 3

Chase 4

Chase 5

Chase 6

Chase 7

Chase 8

Chase 9

Chase 10

Chase 11

Chase 12

000-017 R

018-034 G

035 – 051 B

052 – 068 W

069 – 085 R+G

086 – 102 R+B

103 – 119 R+W

120 – 136 G+B

137 – 153 G+W

154 – 170 B+W

171 – 187 R+G+B

188 – 204 R+B+W

205 – 221 R+G+W

222 – 238 G+B+W

239 – 255 R+G+B+W

0 – 255

Speed

slow

fast

0 – 9

Off

10– 255

From

Slow

fast

5 / 10

3.2.DMX Chart 256 CH mode

Here you can control every LED single on its own:

Ch1

Ch2

Ch3

Ch4

...

Ch253

Ch254

Ch255

Ch256

Red Green Blue White Red Green Blue White

0 – 127

Off

128-255

0 – 127

Off

128-255

0 – 127

Off

128-255

0 – 127

Off

128-255

0 – 127

Off

128-255

0 – 127

Off

128-255

0 – 127

Off

128-255

0 – 127

Off

128-255

If you use cables longer then 100m you should put in a terminator at the last item in your daisy chain!

Use DMX cables with a 120Ohms shield only! All Plugs should use XLR connectors!

The connectors configuration is as follows:

If you want to produce a DMX terminator on your own, you have to insert a Terminator at the plug.

This should have a size of 120Ohms and 1/4W. It has to be inserted between Pin 2 (Data -) and Pin 3

(Data +).

6 / 10

4. Control of the Menu

4.1.Menu structure

DMX 512 address setting

Master Mode

Slave Mode Normal

Slave Mode Lightshow

4 Channel mode

256 channel mode

Choose your automatic show from 1 to 12

Blackout Modus ON

Blackout Modus OFF

LED ON

LED OFF

Normal View

Inverted view

Selftest of the item

Running time of the item in h

Software Version

Addr

001

512

SLNd

NaSt

SL 1

5L 2

CHND

4 CH

256 C

SHNO

bLNd

YeS

Led

oFF

dISP

dSIP

FhrS

ver

TeST

7 / 10

4.2.Description of the Menu

System Menu: When confirming your setting press ENTER and then hold MENU for at

least 2-3 seconds, or you can wait 1 minute for automatic setup. To exit without making

any adjustments press the MENU button.

Addr DMX address setting

1. Push the UP/DOWN buttons until the display shows Addr.

2. Push ENTER

3. 1 appears in the display blinking. With the UP/DOWN buttons you can no adjust the DMX

address from 1 to 512

4. Push ENTER to confirm

SLNd Master Slave Settings

1. Push the UP/DOWN buttons until the display shows SLNd.

2. Push ENTER

3. Use the UP/DOWN buttons to choose from MASt, SL1 and SL2.

4. Push ENTER to confirm

CHNd channel adjust

1. Push the UP/DOWN buttons until the display shows CHNd.

2. Push ENTER

3. Use the UP/DOWN buttons to choose from CH4 or CH256.

4. Push ENTER to confirm

SHNd choose your showl

1. Push the UP/DOWN buttons until the display shows SHNd.

2. Push ENTER

3. Use the UP/DOWN buttons to chosse from the autiomatic shows 1 to 12.

4. Push ENTER to confirm

5. Attention! This mode works only in master mode!

bLNd Blackout or Stand By Mode

1. Push the UP/DOWN buttons until the display shows bLNd.

2. Push ENTER

3. Use the UP/DOWN buttons to choose from on and oFF

4. Push ENTER to confirm

8 / 10

Led LEDs On and OFF

1. Push the UP/DOWN buttons until the display shows Led.

2. Push ENTER

3. Use the UP/DOWN buttons to choose from on and oFF

4. Push ENTER to confirm

dISP inversion of the Display

1. Push the UP/DOWN buttons until the display shows dISP.

2. Push ENTER

3. Use the UP/DOWN buttons to choose from dISP and dSIP, in this case dSIP means the

display is inverted and turned 180°

4. Push ENTER to confirm

TeST Selftest program

1. Push the UP/DOWN buttons until the display shows TeST.

2. Push ENTER

3. Now the item runs through a selftest program.

FhrS shows the running time of the item

4. Push the UP/DOWN buttons until the display shows SLNd.

5. Push ENTER

6. Now the display shows the running time of the item.

Ver Software Version

1. Push the UP/DOWN buttons until the display shows SLNd.

2. Push ENTER

3. Now the display shows the actual software version

5. Master Slave configuration

If you want to daisy chain and control more than one item you can use the Master Slave Mode. To do

so you have to daisy chain your items as you would do when you want to set up a dmx chain. You can

use max 16 items for this mode. The first item in line is the master and the other items will react

according to him. The master item can be set up to the desired program or mode and the others will

follow. The slave items should be set up as follows.

1. Push the Menu button as often until you see SLNd in the display. Push Enter to confirm.

2. No choose the desired Slave mode and confirm again with ENTER.

3. The slave item will now react according to the master.

6. Sound to Light

- Set up the sound to light mode to ON as described above.

- Now the item will react according to the sensitivity you set up at the mic.

- This option can be used with the master slave mode as well.

9 / 10

7. Technical Data

Voltage: 100V ~ 240V 50/60Hz

Power consumption: 29W max.

Fuse: 1A (120 & 230V)

Lightsource

256 LEDs (64 Red, 64 Green, 64 Blue, and 64 White)

Beam Angle: 50°

Weight: 4,5kg

Measures: 400 x 315 x 255 mm

Modes: DMX (4Ch or 256Ch)

Automatic Mode

Sound To Light Mode

Master Slave Mode

7.1.Power daisy chain

At this item there is a power in and out. By using this you can daisy chain up to 20 of these items max.

You have to use the IEC extensions to connect the items. Make sure never to use more than 20 items

in a power chain that you don’t overload the wires and items!

10 / 10

Importer:

B & K Braun GmbH

Industriestraße 1

D-76307 Karlsbad

www.bkbraun.com
