Valor 739DVN Installation instructions
Direct Vent Gas Insert
Model 739DVN (Natural Gas)
Model 739DVP (Propane Fuel)
Installation and Owner’s Manual
DO NOT store or use gasoline or any other
flammable vapors or liquids in the vicinity
of this or any other appliance.
IF YOU SMELL GAS:
Do not try to light any appliance.
Open windows.
Do not touch electrical switches.
Do not use any phone in your building.
Extinguish any open flame.
Immediately call your gas supplier from
a neighbor’s phone. Follow the gas
supplier’s instructions.
If you cannot reach the gas supplier,
call the fire department.
-
-
-
-
-
-
-
PLEASE READ THESE INSTRUCTIONS
CAREFULLY BEFORE INSTALLING AND
OPERATING THE APPLIANCE.
WARNING: If the information in these
instructions is not followed exactly a fire
or explosion may result causing property
damage, personal injury or loss of life.
Installation and service must be performed
by a qualified installer, service agency or
the gas supplier.
WARNING: This product must be installed
by a licensed plumber or gas fitter when
installed within the Commonwealth of
Massachusetts. This appliance is suitable
for installation in a bedroom or bed-sitting
room.
Made in Canada by Miles Industries Ltd.
190-2255 Dollarton Highway, North Vancouver, BC, Canada V7H 3B1
www.milesfireplaces.com
4000072-14
©2007, Miles Industries Ltd. All rights reserved.
INSTALLER: Leave this manual with the appliance.
CONSUMER: Retain this manual for future reference.
FOR YOUR SAFETY
This appliance may be installed in an aftermarket permanently located, manufactured
(mobile) home, where not prohibited by local codes. This appliance is only for use with
the type of gas indicated on the rating plate. This appliance is not convertible for use
with other gases, unless a certified kit is used.
fire-parts.com
2
Table of Contents
Introduction ............................................................................................... 3
Appliance Dimensions ............................................................................. 4
Safety Information .................................................................................... 5
Specifications............................................................................................ 7
Planning..................................................................................................... 8
Clearances................................................................................................. 9
Venting ..................................................................................................... 11
Pack Contents ......................................................................................... 13
Appliance Preparation............................................................................ 15
Remote Control Preparation .................................................................. 16
Gas Supply .............................................................................................. 17
Panel Installation .................................................................................... 18
Log Installation ....................................................................................... 19
Burner & Pilot Operation........................................................................ 21
Window Refitting..................................................................................... 21
Trim Installation ...................................................................................... 22
Final Checks............................................................................................ 23
Operational Warnings............................................................................. 24
Lighting Instructions .............................................................................. 25
Maintenance ............................................................................................ 26
Programmable Remote Control............................................................. 28
Venting Options ...................................................................................... 30
Warranty................................................................................................... 31
The information contained in this installation manual is believed to be correct at the time of printing. Miles
Industries Ltd. reserves the right to change or modify any information or specifications without notice. Miles
Industries Ltd. grants no warranty, implied or stated, for the installation or maintenance of your heater, and
assumes no responsibility for any consequential damage(s).
fire-parts.com
3
Thank you for purchasing the Valor 739 Direct Vent insert. This high quality unit is specifically designed to
be used where installations are restricted by the size of the fireplace. It is our goal to satisfy every Valor
customer. This owner’s manual explains the steps required to safely assemble, install, operate, and maintain
your new appliance.
Options
The model 739 base unit is supplied equipped for use with either natural gas 739DVN or propane fuel
739DVP.
Appliance Styles
Standard metal front, black Kit #741SFB
Cast iron front, black Kit #742CFB
FenderFire Double Doors Front Kit #743FVI
FenderFire Single Door Front Kit #744FVI
Optional Outer Trims
3-sided Contour Trim Kit Kit #746
3-sided Deluxe Trim Kit Kit #747
4-sided Contour Trim Kit Kit #748
4-sided Deluxe Trim Kit Kit #749
Additional Optional Features
Circulating Fan Kit #755CFK
Variable speed and temperature control. It is designed to boost the natural convection process through the
appliance. It may be fitted before the fireplace is installed or retrofitted at a later date.
Natural Gas Conversion Kit #608NGK
For conversion from propane to natural gas. Intended primarily for post-installation conversion in areas
where natural gas was not available at the time of initial installation.
Venting Options
Direct Vent Installations
One or more of the accessories listed on page 30 must be used for each installation. See vent installation
section for details..
Introduction
fire-parts.com
4
See section on installation for details regarding clearances and mantel height allowances.
Appliance Dimensions
** See Page 9 for clearance information **
28-3/8”
R 1/12”
19-1/2”
2-5/8”
36-1/2”
26-5/8”
9-1/4”
Gas Line
7-3/8”
Electrical
20”
12-5/8”with Contour Outer Trim
12”with Deluxe Outer Trim
10”with Contour Outer Trim
9-3/8”with Deluxe Outer Trim
Appliance Dimensions
fire-parts.com
5
Safe installation and operation always require common sense. We are also required by
Canadian and ANSI safety standards to point out the following:
If this appliance is not properly installed, a house fire or explosion may result. For your
safety, follow the installation directions. Contact local building or fire officials about
restrictions and installation requirements in your area. Please read this entire manual
before you install and use your new appliance. Failure to follow instructions may result
in property damage, bodily injury or death.
Installation and repair should be done by
a qualified service person. The appliance
should be inspected before use and at
least annually by a professional service
person. More frequent cleaning may
be required due to excessive lint from
carpeting, bedding material, et cetera.
It is imperative that control
compartments, burners and circulating
air passageways of the appliance are kept
clean.
Due to high temperatures, the appliance
should be located out of traffic and away
from furniture and draperies.
Do not use this heater if any part has been
under water. Immediately call a qualified
service technician to inspect the heater
and to replace any part of the control
system and any gas control which has
been under water.
The appliance area must be kept free from
combustible materials, gasoline and other
flammable vapors and liquids.
Clothing or other flammable materials
should not be placed on or near the
appliance.
The flexible cord provided must be
connected to a line voltage electrical
supply.
Any safety screen or guard removed
for servicing of a room heater must be
replaced prior to operating the appliance.
Never vent the appliance into other rooms
or buildings. The appliance must be
vented only to the outside.
This appliance must not be connected to
a chimney flue serving a separate solid-
fuel burning appliance.
Children and adults should be alerted to
the hazards of high surface temperatures
and should stay away to avoid burns or
clothing ignition.
Young children should be carefully
supervised when they are in the same
room as the appliance.
Provision for adequate combustion and
ventilation air must be provided.
We recommend that our gas
hearth products be installed
and serviced by professionals
who are certified in the
United States by NFI (National
Fireplace Institute®).
Safety Information
WARNING
HOT GLASS WILL
CAUSE BURNS.
DO NOT TOUCH GLASS
UNTILCOOLED.
NEVERALLOW CHILDREN
TO TOUCH GLASS.
fire-parts.com
6
Safety Information
NOTE: Always allow adequate clearance around air openings into the combustion chamber and
maintain accessibility clearances for servicing and proper operation.
2.1 General Safety (Home Owner)
Cleaning. To clean the appliance, make sure it
is off and cold. Then remove the logs and use a
vacuum to clean the burner and air openings in
the bottom and back of the appliance. Replace the
logs.
Fire Extinguisher. Every home should have at
least one fire extinguisher. An approved Class
A-B-C extinguisher should be mounted on the wall
near an exit and close to the appliance, but not so
close that accessibility to the extinguisher could
be blocked by a fire. Your local Fire Department
can advise you concerning the most appropriate
location.
Smoke Detectors & Carbon Monoxide
Detectors. Install at least one smoke detector on
each floor of your home to ensure your safety. It
should be located away from the gas appliance
and close to the sleeping areas. Follow the smoke
detector manufacturer’s placement installation
and maintenance instructions. Your local Fire
Department may provide assistance in selecting
smoke detectors and carbon monoxide detectors.
It is strongly recommended, for your family’s
protection, that a carbon monoxide detector be
placed in all homes that utilize gas in any form.
2.2 Safety for the Installer
Wear gloves and safety glasses for protection.
Exercise extreme caution when using ladders
or when on rooftops.
Be aware of electric wiring locations in walls
and ceilings.
Use a back support when doing any heavy
lifting.
2.3 Vent Safety
Venting must be installed according to local codes
and good venting practices.
2.4 Electrical Code
These appliances, when installed, must be
electrically grounded in accordance with local
codes or, in the absence of local codes, with the
National Electrical Code, ANSI/NFPA 70 or the
Canadian Electrical Code, CSA C22.1.
•
•
•
•
3.1 Planning Your Installation
Please note the following key points regarding the
location of your appliance:
A sufficient gas pressure is required to supply the
unit with a minimum inlet pressure.
Allow adequate accessibility clearances for
servicing and proper operation.
Allow adequate clearance to combustibles and
around air openings for combustion.
A suitable power outlet is required to provide
power when fitted with a fan.
3.2 Listing and Codes
The Valor model 739 is listed and certified for
installation in the U.S.A. and Canada under the
following standards:
ANSI Z21.88-2005 / CSA 2.33-2005 Vented Gas
Fireplace Heaters.
CAN/CGA-2.17-M91, Gas-Fired Appliances for
Use at High Altitudes.
3.3 Installation Codes
This appliance must be installed in accordance with
local codes if any or, in the absence of local codes,
follow the National Fuel Gas Code, ANSI Z223.1 or
Natural Gas and Propane Installation Code, CAN
1-B149.
3.4 High Altitude Installation
When installing this appliance over 4,500 ft. (1,372
m) above sea level in Canada, the appliance must
be properly de-rated and installed according to local
codes; in the absence of local codes, it must be
installed in accordance with CAN/CGA-B149. In the
US, for installations above 2,000 ft., the appliance
must be installed in accordance with the current
National Fuel Gas Code, ANSI Z223.1/ NFPA 54.
•
•
•
•
•
•
fire-parts.com
7
Specifications
Note: Always check appliance label for correct information
MODEL 739 Natural Gas (NG) Propane (LPG)
Manifold pressure 3.95 in. w.c. (0.98 kPa) 9.5 in. w.c. (2.37 kPa)
Min. supply pressure for
purpose of input adjustment 5.0 in. w.c. (1.25 kPa) 11.0 in. w.c. (2.75 kPa)
Max. supply pressure for
purpose of input adjustment 10.5 in. w.c. (2.6 kPa) 14.0 in. w.c. (3.5 kPa)
Orifice size Bray CAT 82–650 Bray CAT 92–260
Maximum input rating 24,000 BTU/hr 24,000 BTU/hr
High altitude (US) 0–2,000 ft. (0–610 m) US 0–2,000 ft. (0–610 m) US
High altitude (Canada) 0–4,500 ft. (0–1,372 m) Can 0–4,500 ft. (0–1,372 m) Can
Electrical rating 120 V.A.C. System 120 V.A.C. System
Circulating fan Variable Speed Variable Speed
Vent system 3” approved flex 3” approved flex
Log set Ceramic (6–Piece) Ceramic (6–Piece)
fire-parts.com
8
Planning
NOTE: THIS APPLIANCE MAY ONLY BE INSTALLED IN A SOLID-FUEL BURNING FIREPLACE WITH A
WORKING FLUE AND CONSTRUCTED OF NON-COMBUSTIBLE MATERIAL.
5.1 Forward Planning
We recommend the following steps for installation.
Familiarize yourself with this manual.
Check the minimum install dimensions and vent installation.
Check your local install codes.
Check that you have all the parts and components necessary to complete the installation.
Check that the gas and electrical supplies are ready.
Prepare opening (clean chase, level base, etc.).
Install vent.
Install base unit and connect vent.
Install optional fan.
Connect gas and electrical supplies.
Install operational components and prepare for first test fire.
Check operation of unit.
Fit surround (optional) and front kit.
Take time to explain the operation of the appliance to the customer (most call backs are caused because
the customer does not understand the operation of the unit).
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
12.
13.
14.
fire-parts.com
9
Clearances
X
Y
6.1 Existing Fireplace (Masonry or Factory-Built)
The model 739 is intended for installation into masonry or listed factory-built fireplaces. Masonry fireplaces
must be built according to the requirements of the standards for chimneys, fireplaces, vents and solid-fuel
burning appliances, NFPA 211 (Latest Edition) or the applicable national, provincial, state or local codes. The
section 6.2 shows the minimum install dimensions for the model 739.
Note: The model 739 is certified without requiring a hearth projection,
although local codes may require a minimum hearth projection.
Check that masonry step does not interfere with
install dimensions or vent pipe.
If mantel is combustible see section 6.2 for
allowable clearances.
Minimum width of fireplace opening at front = 28”
X = 12-5/8” for Contoured Outer Trims
X = 12 ” for Deluxe Outer Trims
Y = 20”
5” 5”
Distance from unit (engine) to combustible wall
fire-parts.com
10
Clearances
6.2 Combustible Mantel Clearance
Figure below shows minimum clearances to combustible mantles.
Note: Measure taken from underside of mantel to finished floor surface that the unit is sitting on.
6.3 Finishing Materials
Combustible materials: Material such as wood, compressed paper, plant fibers, plastics or any material
capable of igniting and burning, whether flame-proofed or not, plastered or un-plastered.
Non-Combustible Material: Material such as steel, iron brick, tile, concrete or materials that bear the UL
mark for zero (0) fire rating.
14”(355 mm)
8”(203 mm)
4”(102 mm)
1”(25 mm)
38”
(965 mm)
35”
(889 mm)
32”
(813 mm)
28”
(711 mm)
fire-parts.com
This manual suits for next models
1
Table of contents
Other Valor Indoor Fireplace manuals
Valor
Valor Heartbeat Oxysafe 426 Release note
Valor
Valor 500FS Instructions for use
Valor
Valor BRAVA 348 Instructions for use
Valor
Valor RetroFire RF24DN Installation instructions
Valor
Valor Portrait Senator Installation and operation manual
Valor
Valor 639 User manual
Valor
Valor LEGEND 739JLN Logs Operating instructions
Valor
Valor 417 User guide
Valor
Valor Legend 937AN Instruction Manual
Valor
Valor regency 328 Release note
Valor
Valor 736TN User manual
Valor
Valor 1500INO (NG) Operating instructions
Valor
Valor HORIZON 535 User manual
Valor
Valor 738BVN Installation instructions
Valor
Valor 530 Direct Vent User manual
Valor
Valor intimate User manual
Valor
Valor FIA BR650 VA User manual
Valor
Valor RetroFire RF24DJN Planning guide
Valor
Valor DZ1GEC Quick start guide
Valor
Valor medway User manual
Popular Indoor Fireplace manuals by other brands
Brigantia
Brigantia 35-DVRS31N-2 User's installation, operation and maintenance manual
Nordpeis
Nordpeis Bergen Installation and user manual
Superior
Superior BCT2536TMN Installation and operation instructions
Quadra-Fire
Quadra-Fire 5100I-GD-B owner's manual
Renaissance
Renaissance RUMFORD 1000 user manual
Lacunza
Lacunza IV-800 Instruction book
Baxi
Baxi 940 Installer and owner guide
Dru
Dru Maestro 60/2 Tall RCH installation manual
Diamond Fireglass
Diamond Fireglass SS-O22 General assembly, installation, and operation instructions
HearthStone
HearthStone Windsor Bay 8830 Owner's manual and installation guide
Napoleon
Napoleon ASCENT B42 quick start guide
Enviro
Enviro E33GI owner's manual
Smeg
Smeg L30 FABE Installation & user's instructions
KEDDY
KEDDY K700 Installation instructions care and firing instructions
Godin
Godin 3451 manual
Jøtul
Jøtul Jotul GI 535 DV IPI New Harbor Installation and operation instructions
Austro Flamm
Austro Flamm Heidi Back 2.0 945048 operating manual
Desa
Desa CCFPDFT Owner's operating & installation manual
