1. Safety & Warnings
In order to maintain safe use of the appliance, please read the following operating instructions
and follow the guidelines contained therein.
1.1 Definitions
Operator – a person who has been trained in the use of the appliance. The operator is
responsible for the correct operation of the appliance and for observing the necessary service
intervals for individual parts.
User/patient – a person who uses a hydro massage bed. He or she is not responsible for
the correct function of the appliance or for its maintenance.
Electrician – a person with the appropriate professional training, knowledge, experience
and familiarity with current legislation that enables them to identify and avoid the dangers of
working with electricity.
Personnel – a qualified third-party personnel who is trained and authorised by the
manufacturer to carry out installation and maintenance work on the specific equipment
Synchronisation – the state of the appliance used to calibrate the appliance’s sensors and
motors. While in this state, the appliance verifies the correct functioning of the component
control systems.
TECHNICAL SUPPORT
www.vacuactiv.com/technical-support/ 5Copyright 2023 Vacu Activ
2. Description of the appliance
The appliance is used for full-body massage and for massaging specific parts of the body. Its
large screen makes it easy and intuitive to select a programme tailored to the client’s needs.
Each programme allows you to increase or decrease the strength and the speed of the mas-
sage. Massage can be given to adults with various body weights.
The appliance features system operation and temperature control of the water used for mas-
sage. The water is heated by an efficient heater with a total output of 3 kW and an overheat
protection. In addition, the appliance has a bathtub level sensor. When the bathtub is filled, a
relevant message is displayed on the touchscreen.
Therapy should be carried out by trained specialised personnel. The product is not intended for
home use.
1.2 Transport and installation of the appliance
The appliance can be transported on a recyclable pallet. The appliance is delivered and
transported by a qualified technician or by the dealer in your region or country.
The operator is responsible for supplying power to the appliance in accordance with the
requirements and regulations applicable to the country or region.
The appliance shall not be installed outdoors. Indoors, the ambient temperature should
oscillate between -15 and +60 degrees Celsius.
The tank should be vented during filling or two days after the tank has been filled to its
capacity. Remember to open the vent plug the first time you fill the tank with water. Failure to
do so may result in damage to the mattress, which will not be covered by the warranty.
If there are any leaks, contact customer support.
TECHNICAL SUPPORT
www.vacuactiv.com/technical-support/
Copyright 2023 Vacu Activ
6
3. Electrical specifications of the appliance
Power supply voltage 230V AC 50Hz
Maximum output 3300 W
Rated current 14 A
Water heater output 3000 W
Water pump output 2600 W
Current drawn by the water pumps 11.7 A
Nozzle travel motor power supply 24 V DC
Nozzle travel motors output 50 W
Nozzle travel motor current 7 A
Securing the installation RCD 16 Amp type B or C
TECHNICAL SUPPORT
www.vacuactiv.com/technical-support/ 7Copyright 2023 Vacu Activ
4. Connecting a touchscreen
Then, turn the locking knob 90 degrees to
lock the screen and protect it from damage.
To connect the operating screen, unpack the
cardboard box containing the screen.
Next, mount the screen in the mounting brack-
et.
The next step involves connecting the monitor’s
power supply and the communication port. It’s
important to connect the communication port
to a connector labelled “USB” and not “Serial
port”. Incorrect connection will result in faulty
operation of the appliance.
Once the screen is correctly connected, an ap-
plication will be launched on the screen and the
device will initiate the synchronisation process if
it was previously filled with water.
TECHNICAL SUPPORT
www.vacuactiv.com/technical-support/
Copyright 2023 Vacu Activ
8
5. Filling the appliance with water and
draining it
The appliance is filled via the plumbing system. Filling is achieved with the filling valve. The
water level is determined by an inductive sensor mounted on the appliance housing. When the
level is suitable, the touchscreen displays a message. This must be approved.
The appliance details are shown below.
Water tank capacity 380 litres
Feed connection ½″
Drain connection ½″
Line working pressure 1.5 MPa (15 bar)
Bed filling time 40 mins
Bed draining time 2 hours
To fill the appliance with water, turn the side pieces of the appliance. There is a ½″ filling valve
at the top. The connected hose must be of the same diameter as the valve and no section of it
should be kinked or bent.
Upon connecting the water hose from the water mains, turn the drain valve from the closed
position to the open position.
The procedure for filling the appliance with and draining it is outlined below.
TECHNICAL SUPPORT
www.vacuactiv.com/technical-support/ 9Copyright 2023 Vacu Activ
STEP 1
Loosen the oxygen therapy cover. To do this, use an Allen key.
STEP 2
Loosen the screws securing the housing to the appliance frame.
TECHNICAL SUPPORT
www.vacuactiv.com/technical-support/
Copyright 2023 Vacu Activ
10
STEP 3
Loosen the fixing screws from the front of the appliance. Use an Allen key.
STEP 4
Carefully lift the appliance housing and pull it away from the frame. Disconnect the LED supply
connectors and the communication leads for the touchscreen.
