USX-MOUNT XMM006-2-15 User manual
XMM006-2-15
INSTRUCTION MANUAL
For 26-55" TV
If you have any questions along the way, just give us a call
1-800-460-0956 or message to us. We’re ready to help!
TM
CA-B0
Before getting started, let’s check below lists to make sure it is just right for you!
2
3
4
5
2
Does your TV
(including accessories)
weigh MORE than
77
lbs. (35
k
g)?
What is your
wall made of?
Do you have
all the tools
needed?
(NOT INCLUDE)
Tape
Measure
CAUTION
Pencil Screw
driver
Electric
Drill
No? Perfect – you may continue.
Yes? This mount is NOT compatible.
Drywall with
wood studs? CAUTION:
CAUTION: DO NOT exceed the maximum weight
indicated. This mounting system is intended for use only
with the maximum weights indicated. Use with products
heavier than the maximum weights indicated may result
in collapse of the mount and its accessories, causing
possible injury.
Solid concrete
?
1/2 in.
(13 mm)
Socket
Wrench
Stud
Finder
5/32 in.
(4.0 mm)
Wood
Drill Bit
● This product is designed for use in wood stud, solid concrete walls - DO NOT install into drywall alone
● The wall must be capable of supporting five times the weight of the TV and mount itself
● Do not use this product for any purpose not explicitly specified by manufacturer
● Manufacturer is not responsible for damage or injury caused by incorrect assembly or use
Unsure?
Call Customer Service:
1-800-460-0956
3/8 in.
(10 mm)
Masonry
Drill Bit
Hammer
1
Check your TV
VESA is within
Min and Max size
No? This mount is NOT compatible.
Yes? Perfect !
MAX:400mm/15.74"
(MIN:75mm/2.95")
MAX:400mm/15.74"
(MIN:75mm/2.95")
DO NOT
install into
drywall alone
77
L
BS
(35
k
g)
CAUTION: PLEASE READ ENTIRE MANUAL PRIOR TO USE AND SAVE THESE INSTRUCTIONS
!
!
Per
fect!
Per
fect!
Wood Stud Install
Concrete Install
TV INTERFACE
3-D
WALL PLATE
FULLY ASSEMBLED MOUNT
SIDE VIEW - RETRACTED
TOP VIEW - EXTENDED
3
+5°
-15°
Dimensions
71mm
[2.81in]
444mm
[17.48in]
444mm
[17.48in]
481mm
[18.95in]
90mm
[3.54in]
245mm
[9.65in]
219mm
[8.64in]
400mm
[15.75in]
400mm
[15.75in]
WARNING: This product contains small items that could be a choking hazard if swallowed. Before starting assembly, verify all parts
are included and undamaged. If any parts are missing or damaged, do not return the damaged item to your dealer; contact
Customer Service.
Never use damaged parts!
NOTE: Not all hardware included will be used.
Parts and Hardware for STEP 1
4
Allen Key
M6x
8
mm Bolt
M4x12mm
M6x12mm
M4x30mm
M6x35mm
Spacers
TV Screws
x4 x4
x4 x4
M8x
45
mm
M6x17mm
M8x22mm
M4 M6
10mm
2.5mm
Washers
x4
x4
x4 x4
x
8
x
4
x4
a
b
f
e
d
gh
ij
k
l
0706
02 03
x4
x4 x1
x1
TV plate
Extended arms
M8x25mm
x4
c
Parts and Hardware
!
Parts and Hardware for STEP 2
5
Lag Bolt M7x55mm
Wa
ll
P
l
a
te
M6x
10
mm Bolt
Contact us at telephone
1-800-460-0956
(USA)
or message to us
to have these additional pieces
shipped directly to you.
Concrete Wall
Anchor
3pcs
05
x1
04
x2
01
x3
Concrete wall anchor (NOT INCLUDED)
Velcro x3
Level x1
6
1-1
Choose Configuration
If your TV VESA size is above 200*200mm, you need to assemble extended arms onto TV plate
using bolts and Alley key per below option 3 - option 6 shown.
①
②
③
④①
75X75
②
100X100
③
100X200
④
200X100
⑤
200X200
⑤
①
②
③
④
⑤
①
②
③
④
⑤
①
②
③
④
⑤
⑥ ⑥
⑥ ⑥
150X150
⑥
Option 1
Option 2
200X300
400X200
⑧
⑦
⑨
⑧
⑦
⑧
⑦
⑧
⑦
⑧
⑦
200X400
⑨
⑩⑨⑩
⑨
⑩⑨⑩
300X200
⑩
Option 3
Option 4
STEP 1 Attach TV Plate to TV
06 07
02
03
7
02
03
02
03
06
06
06
06
07
400X400
400X300
11
1 3
300X300
1 2
11
1 2
1 3
Option 5 Option 6
11
11 11
1 3
1 3 1 3
1 2
1 2 1 2
8
M8
M6
M4
1-2
Select TV Screws
Tips: If you need to combine
M6/M8(
c/e
/f) screw
s
with
2.5mm spacer
s
(
i
),
you have to remove the inner circle.
9
Yes,
choose suitable screws, washers and spacers.
1-4
Attach the TV Plate
No!
No,
choose suitable screws and washers.
VESA≤200X200mm
200X200mm<VESA≤400X400mm
1-3
Need Spacer?
b
a
c
k
l
e
d
f
k
l
i
h
j
g
CAUTION: Avoid potential personal injury or property damage!
● Drywall covering the wall, must not exceed 5/8 in. (16 mm)
● Minimum
wood stud
size: common 2 x 4 in. (51 x 102 mm) nominal 1½ x 3½ in. (38 x 89 mm)
● Stud center must be verified
1. Locate your studs. Verify and mark the center of the stud by finding the stud edges using a thin nail,
or an edge to edge stud finder.
2. Position the wall plate at your desired height and line up the holes with your stud center line. Level
the wall plate and mark the hole locations.
Centre line
10
Wa
ll
pla
te
STEP 2A Attach Wall Plate to Wall Wood Stud Option
!
05
05
Level
