Uniden DECT1820 User manual

OWNER'S MANUAL

DECT1820

EXTRA HANDSET

OWNER'S

MANUAL

Welcome

Checking the Package Contents

Congratulations on your purchase of the Uniden DECT1820

optional handset and charger. This expansion handset is

compatible with models in the following series: DECT1825,

DECT1825+1, DECT1855 and DECT1855+1

(Model numbers may vary.)

Each model within this series will support up to six handsets. You

can place a fully featured cordless handset anywhere in your home

as long as AC power is available to connect the handset's charging

cradle.

The DECT1820 expansion handset will not operate unless it has

been registered to your main base. Refer to the owner's manual

supplied with your main base model for detailed instructions on

operating your new expansion handset.

Make sure you have received the following items in the package.

If any of these items are missing or damaged, contact

your retailer.

• Cordless Handset

• Charging Cradle

• AC Adapter

(INPUT:240V AC 50Hz)

(OUTPUT:6V DC 200 mA)

• 2 x AAA size Rechargeable Batteries (1.2V 650mAh)

• This Owner ’s Manual

• Other Printed Material

IMPORTANT

[1]

Installing Your Expansion Handset

Follow these three easy steps to get your new handset ready to

use:

Connect the charger.

Install the batteries and charge your new handset for 15-20

hours.

Connect the AC adapter to the

jack and to a standard 240V AC wall

outlet.

Set the charger on a desk or tabletop.

•

• Place the charger close to the AC outlet so that you can

unplug the AC adapter easily.

Step 1:Connect the Charger

DC IN

Use only the supplied AC

adapter. Do not use other

AC adapter.

[2]

Step 2:Install the Batteries and charge your new

handset for 15-20 hours

Remove the battery compartment cover. Press down on the

semi-circle indent and slide the cover off.

Charge the battery for 15-20 hours before using. To charge the

batteries, place the handset on the charger.

While charging, the symbol scrolls and when the battery is fully

charged, all the bars of the battery symbol will be filled when the

phone is off the cradle.

If the symbol does not appear, reposition the handset in the

charger, ensuring that the charging points contact.

•Use only the Uniden batteries supplied with your phone.

•Recharge your handset on a regular basis by returning

the handset to the charger after each phone call.

Step 3:Register the Handset

YOU NEED TO REGISTER THE DECT1820 TO THE MAIN BASE

BEFORE USE!

For Main Base Models DECT1825, DECT1825+1, DECT1855 and

DECT1855+1, When you register a new handset to your base, you

will be asked to enter the base PIN code.

The pre-set PIN code is 0000. If you wish you can change this

code, see owner's manual for detailed instruction.

Before registering, make sure that you have the base and handset

in front of you. Also, make sure all handsets and the base are in

standby mode.

[3]

On the DECT1820 handset you want to register:

On your original base:

On the DECT1820 handset:

1. Press to access the main menu.

2. Press up or down key until is displayed and

press .

Press up or down key to display and press

.Press up or down key to select your base number and press .

Press and hold for approx. 3 seconds until you hear

the registration tone. You are now in ‘registration mode’.

If the base already has the maximum number of handsets (6)

registered to it you will need to de-register one of the existing

handsets before you can register the new handset.

See section below for de-registering handsets.

Enter the base PIN code. Pre-set base PIN code is 0000. You will

hear a confirmation tone when registration is complete.

When in standby mode, the new handset number will be displayed.

The handset will automatically be allocated with the next available

handset number.

If registration is unsuccessful, the display will show

and you will need to follow the registration

procedure again.

"Add.Settings"

"Register"

Not

Registered

find handset

menu/ok

[4]

If you have more than one handset registered to your base you can

de-register a handset or the bases registered to use. Before de-

registering, make sure all handsets and the base are in standby

mode.

Press to access the main menu.

Press up or down key until is displayed and

press

Press up or down key to display and press .

Press up or down key to select or and press

Press up or down key to display the handset or base you want

to de-register and press .

Press up or down key to select and press .

If the handset has been registered to the base successfully, you

will hear a confirmation tone.

Press to exit and return to standby.

Your phone is GAP compatible, which means you can

(Digitally enhanced cordless telephone) GAP

compatible bases.

You can register a DECT1820 handset to up to 4 bases,

e.g. one at work and one at home, and switch between

them.

Add. Settings

Deregister

Handset Base

Yes

To Register your handset to another manufacturer's

base. Follow the procedure for registering shown in the

other manufacturer's user guide.

•

[5]

menu/ok

end

Using Your Expansion Handset

Now that your new handset is registered, it can perform all the

same functions as the handsets originally included with your phone.

With your new handset, you can

• Transfer calls between handsets

• Use two handsets as 2-way radios in DirectLink (Walkie-Talkie)

mode

• Hold conference calls

• Access the integrated answering device or voice mail using

Handset

See the owner's manual that came with your main base for

complete instructions on operating your new expanded phone.

[6]

Battery Information

Low battery alert

Cleaning the battery charging contacts

Caution:

If the symbol is displayed on the handset, "Charge Battery"

appears and you hear the low battery tone, you will need to

recharge your handset. We recommend that you place the handset

back on the charger between use to ensure that it is always fully

charged.

To maintain a good charge, clean the

charging contacts on the

handset once a month. Dampen a cloth

with plain water. Gently rub

the damp cloth over the charging contacts

until all visible dirt is

removed. Dry the contacts thoroughly

before returning the handset

to the cradle.

Do not use paint thinner,

benzene, alcohol, or other chemical

products. Doing so may discolor the

surface of the telephone and damage the

finish.

[7]

talk

rdl

rdl rdl

rdl

menu/ok

end

Quick Guide

Function Button press

Make a call

Preparatory call

Adjust earpiece volume

End a call

Receive a call

Redial

Privacy

, enter number.

Enter number, .

During a call, or .

Phone rings, .

then or to display number,

During a call, and select ,

repeat the same step to select

" " to resume a call

Mute

Un Mute

[8]

then , select , ,enter

name, , enter number, .

Select , , then select , .

then or , .

then or to

Press or to then

Press or to select

Press or to select the melody, .

then or to select internal

handset number, or

Store phonebook

Dial phonebook number

Handset ringer melody

Make internal call

New Entry

Tone Save

Audio Settings

Ringer Type

External,

Internal, Paging, Alarm,

Appointment

number

talk

rdl

menu/ok

menu/ok menu/ok

menu/ok

menu/ok menu/ok

menu/ok

int'com

menu/ok

[9]
