Uniden WDECT3315 User manual

WDECT3315

WDECT3315+1

Series Owner’s Manual

OWNER’S MANUAL

[ i ]

INSTALLATION & SAFETY

•This symbol

indicates important

operating

and servicing

instructions.

•The earcap of this

telephone may

attract and retain

small metallic

objects.

AVOID -

connecting

more than

phones as ringing

may be impaired

AVOID -

multi power boards.

CHARGE -

the new phone

for 15 - 20 hrs.

AVOID -

Moisture

Don’t -

overload the

power outlet.

AVOID -

moisture

AVOID -

Television

sets and other

electronic

appliances AVOID -

Microwave ovens

AVOID -

Computers

AVOID -

other cordless

telephones

Note: Ringing will not be impaired by

adding extra cordless handsets.

For detailed installing method, please

refer Set-Up Guide.

Choosing the best location for your phone.

When choosing a location for your phone there are a number of appliances the

phone should not be near, and areas you should avoid.

CHOOSE -

a central location

[ ii ]

CONTENTS

INSTALLATION & SAFETY i

CONTENTS ii

GETTING STARTED 1

Controls and Functions 1

Welcome 2

Features 3

Terminology 3

Mounting the Base Unit on a Wall 4

Battery Maintenance 5

Installing the Beltclip 6

Headset Installation 7

Display and Icons 7

About the Menu Options 8

Setting up the Menu 11

BASICS 18

Making and Receiving Calls 18

Keypad Lock 19

Placing a Call on Hold 19

Redialing a Call 20

Adjusting the Handset Ringer,

Earpiece and Speaker Volume 21

Mute Microphone 22

Tone Dialing Switch-Over (Australia Only) 22

Traveling Out-of-Range 22

Clarity Booster 23

Privacy Mode 23

Find Handset 24

Flash and Call Waiting 24

Using One Touch Voice Mail Access 25

PHONEBOOK 26

Phonebook 26

Storing Phone Numbers, Names,

Distinctive Rings, and Speed Dial 26

Steps for Entering Names and Special Characters 28

Viewing the Phonebook 30

Making Calls Using the Phonebook 31

Speed Dialing 31

Editing or Erasing a Stored Name,

Phone Number, Distinctive Ring, and Speed Dial 32

Chain Dialing 33

CALLER ID 34

Caller ID 34

Viewing the Caller ID List 35

Deleting a Caller ID Message 36

Using the Caller ID Message List 37

EXPANDING YOUR PHONE 38

Expanding your Phone 38

Using Two Way Communication between the

Handsets Anywhere without the Base (Directlink) 40

Room Monitor 40

3-Way Conferencing 41

Intercom/Call Transfer Feature 41

Replacing the Base 42

ADDITIONAL INFORMATION 43

Changing the Digital Security Code 43

Note on Power Sources 44

TROUBLESHOOTING 45

INDEX 47

WARRANTY 48

GETTING STARTED

[ 1 ]

CONTROLS AND FUNCTIONS

1. Handset Antenna

2. Headset Jack Cover

3. Beltclip Hole

4. Hands-Free Speaker

5. Handset Battery Compartment

6. New Message LED

7. Handset Earpiece

8. LCD Display

9. /del Key

10. /vol/ / Key

a. ringer volume control

b. scroll keys for display

screen

11.

tone

Key

12. redial/pause Key

13. speaker Key

14. Key

15. Key

16. Key

17. Key

18. Key

19. phonebook Key

20. /transfer/int’com Key

21. Handset Microphone

22. Handset Charging Contacts

[ 2 ]

Congratulations on your purchase of the Uniden Multi-Handset Cordless System telephone. This unit is different from

conventional cordless telephones. When the base unit is connected to AC power and a telephone line, it can support up

to 4 handsets. Using extra handsets, you can establish a 3-way conference call (2 handsets and an outside line), while two

other handsets are making an intercom call. You can now place a fully featured cordless handset anywhere in your home

or office where AC power is available to connect the handset chargers.

Note: The illustrations in this manual are intended as a guide and may differ from actual unit.

27 28

23. Base Antenna

24. Base Charging Contacts

25. charge LED

26. Key

27. TEL LINE Jack

28. DC IN 9V Jack

29. Charging Contacts

30. charge LED

31. DC IN 9V Jack

WELCOME

CHARGER BASE

for WDECT3315+1 only

Main Base

[ 3 ]

Throughout this manual, terms such as Standby and Talk Mode are used. Below is the terminology

explanation.

Standby Mode - The handset is not in use, is off the cradle, and or speaker has not been

pressed. A dial tone is not present.

Talk Mode - The handset is not in the cradle and or speaker has been pressed enabling a

dial tone. “Talk” appears on the display.

DirectLink - Two way communication between the handsets anywhere without the base.

TERMINOLOGY

Great features of this cordless phone include:

• Designed and Engineered in Japan

• Wide Band Digital Technology

• Multi (4) Handset Capable

• Digital Duplex Speakerphone on Handset

Advanced Alpha Display Caller ID Features:

• Alpha Memory Dialing

• POP ID - Caller Name Identification*

• 20 Individual Caller Tone Allocation*

• 100 Caller ID * Memories with Phonebook

• 3 Line Backlit Full Dot Matrix LCD Display with Clock

• Maxi-Sound - Extra Loud Handset Volume Control

• Intercom/Announce Call Transfer

• Handset Conferencing (2 Handsets + Outside Call)

• Two-Way Communication between Handsets Anywhere without the Base

• And More!

FEATURES

* Caller ID, POP ID and Individual Caller Tone Allocation (Distinctive Ring) features work only if you subscribe

to the service provided by your local telephone company. There is usually a fee for this service.

# Range may vary depending on environmental and/or topographical conditions.

[ 4 ]

MOUNTING THE BASE UNIT ON A WALL

You can mount your base directly to the wall. Before doing this, consider the following:

• Avoid electrical cables, pipes, or other items behind the mounting location that could cause a hazard

when inserting screws into the wall.

• Mount your phone within distance of a working phone jack.

• Make sure the wall material is capable of supporting the weight of the base and handset.

• Use screws with anchoring devices suitable for the wall material where the base unit will be placed.

1) Insert two mounting screws into the wall (with their appropriate anchoring device),

85mm apart. Allow about 3mm between the wall and screwheads for mounting

the phone.

2) Plug the AC adapter into the DC IN 9V jack on the telephone and then into

a Standard AC wall outlet.

3) Plug the telephone cord into the TEL LINE jack on the telephone and then

into the telephone socket on the wall.

4) Align the mounting slots on the base with the mounting posts

on the wall.

5) Then push in and down until the phone is firmly seated.

This phone also can be mounted on any standard telephone wall

plate (for Australia).

3mm

85mm

35mm

[ 5 ]

BATTERY MAINTENANCE

Cleaning the battery charging contacts

To maintain a good charge, it is important to clean the

charging contacts on the handset once a month. Use a dry

cloth or pencil eraser to clean.

Battery use time (per charge)

Fully charged

• Up to 7 hours continuous use.

• Up to 10 days when the handset is in the standby mode (up to 15 hours when in DirectLink mode)

Recharge your phone on a regular basis by returning the handset to the charger after each phone call.

Low battery alert

When the batteries are very low and need to be charged, the phone is programmed to eliminate

functions in order to save power.

The batteries need to be charged when:

- The empty battery icon appears.

- “Low Battery” appears in the display.

If the phone is in the standby mode, none of keys will operate. If you are on a

call, complete your conversation as quickly as possible, and return the

handset to the cradle.

Low Battery

[ 6 ]

INSTALLING THE BELTCLIP

To attach the beltclip

Insert the beltclip into the holes on each side of the handset. Press down until

it clicks into place.

To remove the beltclip

Pull either side of the beltclip to release the tabs from the holes.

Battery replacement and handling

When the operating time becomes short, even after a battery is recharged, please replace

the battery. With normal usage, your battery should last about one year. Please contact

your place of purchase or the Uniden Parts Department for a replacement battery.

Caution

• Use only the specified Uniden battery pack (BT-446).

• Do not remove the batteries from the handset to charge them.

• Never throw the battery into a fire, disassemble them, or heat them.

• Do not remove or damage the battery casing.

To avoid the risk of personal injury or property damage from fire or electrical shock, only

use the Uniden battery model and Uniden adapter model specifically designated for this

product.
