Turtle Beach Ear Force XO One User manual
USER GUIDE
XBOX ONE STEREO GAMING HEADSET
For: Xbox One I Mobile Gaming*
Designed for
ONE
Congratulations on your purchase of the Turtle Beach Ear Force XO One Headset from Turtle Beach. You’ll enjoy
powerful gaming audio and chat on the Xbox One as well as for mobile gaming. Turtle Beach brings over 35 years of
expertise to transforming your listening experience. Welcome to Turtle Beach!
Package Contents P4
About the Ear Force XO One Headset P5
Parts and Controls P6
Setup and Connections: Xbox One Consoles P7
Setup and Connections: Mobile Sources P9
Specications P10
TroubleshootingTips P11
ImportantSafetyInformation P12
Compliance/Conformity P13
Warranty P16
Table of Contents
4
Go to Table of Contents
Package Contents
ED
B
C
A
XO ONE Headset
Mobile Adapter Cable Removable Mic Boom Turtle Beach Sticker
For our Knowledgebase and Technical Support please visit
turtlebeach.com/support
Ear Force Headset Audio Controller
5
Go to Table of Contents
Boost your gaming experience with the all-new Ear Force® XO ONE Stereo Gaming Headset from Turtle Beach.
Designed to deliver high-quality Xbox One game and chat audio straight to your ears, you’ll hear every detail of
yourfavoritegames,moviesandmorethroughpowerful,50mmspeakers.TheincludedEarForceHeadsetAudio
ControllerplacesgameandchatcontrolsrightatyourngertipsplusvariableMicMonitorandBassBoost.And
with its lightweight, comfortable design, XO ONE is ready for marathon game sessions and features a removable
mic boom to use with your favorite mobile devices.
FEATURES
About the Ear Force XO ONE Headset
Be immersed.
Included Audio Controller features multi-step Bass Boost and Variable
Mic Monitoring plus Game-Chat Mix and Mic Mute.
Loud and clear.
Full-range50mmspeakersdelivercrisphighsandthumpinglows.
Be social.
High-quality, removable mic for chat on Xbox Live and Skype™.
Be mobile.
Disconnect from the Audio Controller to use the XO ONE with your
mobile devices.
Lightweight & Comfortable
Breathable mesh cushions and an adjustable headband for hours of
gaming.
Built to Last
Renowned Turtle Beach durability and build quality.
6
Go to Table of Contents
Parts and Controls
Game/Chat Balance Buttons
Mic Button
Short Press = Mute / Unmute
Long Press = Toggle Mic Monitor Off / Low / High
Master Volume Control
Press up/down to increase/decrease
overall game and chat volume.
Bass Boost:
Press = Off / Low / High
Ear Force® Headset Audio Controller
7
Go to Table of Contents
Setup and Connections: Xbox One Consoles
1.Insertthemicrophoneboomintothejackontheleft
earcup of the headset. Use the keyed plug to line up the
Mic Boom in the correct orientation. Press the mic boom in
until you hear a gentle click.
2.InserttheEarForceHeadsetAudioControllerinto
the Xbox One Controller.
TheHeadsetAudioControllerwasdesignedtot
tightly into the Xbox One controller. You may need to
apply gentle upward pressure to the bottom of the
audio adapter while
inserting into the controller. If it does not connect
easily, do not force it. Make sure the Audio Controller
is well aligned (do not angle the Audio Controller)
and try again.
3. Connect the cable from the XO One Headset into the Ear
Force Headset Audio Controller.
NOTE: Forreliablesound,conrmthatallconnectionsare
rmlyinserted.
Use the two long pins to
properly align the adapter
Controller not included.
B
D
A
8
Go to Table of Contents
Setup and Connections: Xbox One Consoles
4. Connect the Xbox One Controller to the Xbox
One Console using the Micro USB Update Cable
5. Follow the on-screen prompts to update your
controller.
6. Take this time to update additional controllers if
necessary.
If your adapter is not functioning correctly after these steps, try updating your controller again. To do this go to
Settings >> System >> Update Controller. This will repeat the original process.
Your controller needs an update
Home
FEATURED
An update is available for a recently connected Xbox One controller. Would you like to update it?
Update controller Cancel
Controller updated
The connected controller has been updated.
Do you want to update another controller?
Update another Exit
9
Go to Table of Contents
Setup and Connection: Mobile Sources
Connect your headset directly into the Headset Jack on the Mobile Device
NOTE: Forreliablesound,conrmthatallconnectionsarermlyinserted.
Connecting to Mobile Devices
D
A
10
Go to Table of Contents
Specications
-Speakers:50mmwithNeodymiumMagnets
-FrequencyResponse:20Hz—20kHz
- Earpad Material: Fabric (Black) with Foam Cushioning
- Earcup Design: Over-Ear (Closed)
- Microphone Design: Removable Omni-Directional Microphone
-HeadphoneCableLength:3feet(0.91m)with4-Pole3.5mm
