Turbonet TURBOFON E4 User manual
TN502A1
QUICK START GUIDE & REGULATORY
TURBONET
Product Overv ew:
Scanner
Function Key
(KEY_LEFT UP
)
Function Key
(Scan/KEY_RIGHT)
Touc Screen
LED Indicators
Function Key
(Scan/KEY_LEFT DOWN)
Power Key
Volume Keys
Menu Keys
(Return/Home/Data)
Buckle for Handstrap
USB Type
-
C
Pogo Connectors
For c arging
NFC detect area
Battery Latc
Camera
LED Flas
Sett ng up your phone
Install ng M cro SD / NanoSIM Card
1. Open t e battery: remove rubber stopper on t e top
2. Insert t e Micro SD into slot.
3. Insert Nano SIM into SIM slot.
Battery Installat on
1. Insert t e battery, bottom side first.
2. Press down t e top of battery and make sure t e latc is on t e left/rig t side
3. Make sure t e latc is on t e left/rig t side and ear a slig t “click” sound
MicroSD card
NanoSIM card
Note: Please make sure t e battery s ould be located in
bot left & rig t - side for t e battery door closing
properly
CAUTION:
- If t e battery is incorrectly replaced, t ere is a danger of
explosion.
- Replace only wit t e same or equivalent type
recommended by t e manufacturer.
- Discard used batteries according to t e manufacturer's instructions.
Remove the Battery
Press bot left & rig t latc at t e same time t en removing t e battery.
Charg ng the Battery
C arge t e battery via one of t e following accessories certified wit TN502A1:
1. Use a Type-C USB cable connected toget er wit a Power Adaptor Jack
2. Use Single Cradle connected wit DC Power adaptor and Plug (Turbonet Model
Name: DS12310)
*Not ce: Type-C USB s for data transm ss on, not for charg ng. Us ng Type-C USB can
only charge for phone, not val d for battery charg ng.
Charg ng nd cator
1. Main Device: TN502A1
2. Cradle: DS12310
LED indicates t e status of cradle power connection and battery power
CAUTION:
1. Please make sure t e device being fully c arged w en using TN502A1 at first time.
2. C arge batteries in temperatures from 0°C to 40°C. T e device or cradle always
Solid Red: Power connected and low battery power
Solid Green: Power connected and a battery is fully
c arged.
Blinking
Red: Low Power
Solid Red: Battery is c arging
Solid Green: Battery is fully c arged
performs battery c arging in a safe and intelligent manner. At ig er temperatures
(e.g. approximately +37°C) t e device or cradle may for small periods of time
alternately enable and disable battery c arging to keep t e battery at acceptable
temperatures. T e device and cradle indicates w en c arging is disabled due to
abnormal temperatures via its LED.
Us ng Your Phone
Tur ng ON/OFF Your Phone
1. To turn on t e p one, press and old t e power button
2. To turn off t e p one, press t e power button and select
“Power off” in t e dialog box.
Note:
Device turns to t e ot er modes as below by olding power button key.
Suspend Mode
Press and release t e power button to place t e device in suspend mode. T e display will be off and go
into a low power state to conserve battery power.
Reboot
Press and old t e power button, and select “Reboot” in t e dialog to restart t e device.
Data Capture
Scan a Bar Code wit Imager
Go to “Sett ng” “Funct onal Keys” Select ”SCAN” for function
keys used for scanning.
Go to “BarCodeScanDemo” apk Select “ ” for scanner settingPress
function keys to scan barcodes.
CAUTION: CLASS 2 LASER WHEN OPEN. DO NOT STARE INTO BEAM OR
VIEW WITH OPTICAL INSTRUMENTS. COMPLIES WITH 21CFR1040.10 AND
1040.11 EXCEPT FOR DEVIATIONS PURSUANT TO LASER NOTICE NO. 50,
DATED JUNE 24, 2007 AND IEC/EN 60825-1:2014
Photo & V deos
1. Go to Home Screen select “Camera” Tap camera icon or screen to take a
picture/switc to video icon and tap for video recording.
2. Using t e rear camera to take p otos and capture video.
Note: a. Ensure device memory or extend Micro SD card is space is available.
b. Hig ly suggest to use camera app w ic is included in Android OS already. Using 3
rd
party
application may cause any bug.
Install ng Apps
Download applications from Google Play Store.
Go to Home Screen select “Google Play” icon
GPS Informat on
Acquiring satellite signals may take a few minutes.
Wit out a clear view, acquisition takes longer and possible unable to catc t e position
quickly.
Turn off GPS application if no use.
Regulatory Informat on
Caut on: Only use TURBONET approved accessor es.
1. Wireless Device Country Approval
Regulatory markings, subject to certification, are applied to t e device signifying t e
radio(s) are approved for use in t e European countries under CE coverage.
For 2.4GHz or 5GHz products : Europe includes Austria, Belgium, Bulgaria, Czec Republic,
Cyprus, Denmark, Estonia, Finland, France, Germany, Greece, Hungary, Iceland, Ireland,
Italy, Latvia, Liec tenstein, Lit uania, Luxembourg, Malta, Net erland, Norway, Poland,
Portugal, Romania, Slovak Republic, Slovenia, Spain, Sweden, Switzerland and t e United
Kingdom.
Caution: Operation of t e device wit out regulatory approval is illegal.
2. Country Roaming
T is device incorporates t e international roaming feature w ic will ensure t e product
operates on t e correct c annels for t e particular country of use.
3. Ad-Hoc Operation ( 5GHz Band )
Ad-Hoc operation is limited to C annels 36- 48 ( 5150 – 5250 MHz) . Use of t is band is
restricted to indoor use only, any ot er use will make t e operation of t is device illegal.
Federal Commun cat on Comm ss on Interference Statement
T is device complies wit Part 15 of t e FCC Rules. Operation is subject to t e following
two conditions: (1) T is device may not cause armful interference, and (2) t is device
must accept any interference received, including interference t at may cause undesired
operation.
T is equipment as been tested and found to comply wit t e limits for a Class B digital
device, pursuant to Part 15 of t e FCC Rules. T ese limits are designed to provide
reasonable protection against armful interference in a residential installation. T is
equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance wit t e instructions, may cause armful interference to radio
communications. However, t ere is no guarantee t at interference will not occur in a
particular installation. If t is equipment does cause armful interference to radio or
television reception, w ic can be determined by turning t e equipment off and on, t e
user is encouraged to try to correct t e interference by one of t e following measures:
- Reorient or relocate t e receiving antenna.
- Increase t e separation between t e equipment and receiver.
- Connect t e equipment into an outlet on a circuit different from t at
to w ic t e receiver is connected.
- Consult t e dealer or an experienced radio/TV tec nician for elp.
FCC Caution: Any c anges or modifications not expressly approved by t e party
responsible for compliance could void t e user's aut ority to operate t is equipment.
T is transmitter must not be co-located or operating in conjunction wit any ot er
antenna or transmitter.
Operations in t e 5.15-5.25GHz band are restricted to indoor usage only.
Radiation Exposure Statement:
T e product comply wit t e FCC portable RF exposure limit set fort for an uncontrolled
environment and are safe for intended operation as described in t is manual. T e furt er
RF exposure reduction can be ac ieved if t e product can be kept as far as possible from
t e user body or set t e device to lower output power if suc function is available.
Note: T e country code selection is for non-US model only and is not available to all US
model. Per FCC regulation, all WiFi product marketed in US must fixed to US operation
c annels only.
Body-worn Operation
T is device was tested for typical body-worn operations. To comply wit RF exposure
requirements, a minimum separation distance of 15 mm must be maintained between
t e user’s body and t e andset, including t e antenna. T ird-party belt-clips, olsters,
and similar accessories used by t is device s ould not contain any metallic components.
Body-worn accessories t at do not meet t ese requirements may not comply wit RF
exposure requirements and s ould be avoided.
HAC
T is p one as been tested and rated for use wit earing aids for some of t e wireless
tec nologies t at it uses. However, t ere may be some newer wireless tec nologies used
in t is p one t at ave not been tested yet for use wit earing aids. It is important to
try t e different features of t is p one t oroug ly and in different locations, using your
earing aid or coc lear implant, to determine if you ear any interfering noise. Consult
your service provider or t e manufacturer of t is p one for information on earing aid
compatibility. If you ave questions about return or exc ange policies, consult your
service
To determine t e compatibility of a WD and a particular earing aid, simply add t e
numerical part of t e earing aid category (e.g. M2/T2=2) wit t e numerical part of t e
WD emission rating (e.g., M3=3) to arrive at t e system classification for t is particular
combination of WD and earing aid. A sum of 5 would indicate t at t e WD and earing
aid would provide normal use, and a sum of 6 or greater would indicate t at t e WD and
earing aid would provide excellent performance. A category sum of less t an 4 would
likely result in a performance t at is judged unacceptable by t e earing aid user.
WHAT IS HEARING AID COMPATIBILITY?
T e Federal Communications Commission as implemented rules and a rating system
designed to enable people w o wear earing aids to more effectively use t ese wireless
telecommunications devices. T e standard for compatibility of digital wireless p ones
wit earing aids is set fort in American National Standard Institute (ANSI) standard
C63.19. T ere are two sets of ANSI standards wit ratings from one to four (four being
t e best rating): an “M” rating for reduced interference making it easier to ear
conversations on t e p one w en using t e earing aid microp one, and a “T” rating
t at enables t e p one to be used wit earing aids operating in t e telecoil mode t us
reducing unwanted background noise.
HOW WILL I KNOW WHICH WIRELESS PHONES ARE HEARING AID COMPATIBLE?
T e Hearing Aid Compatibility rating is displayed on t e wireless p one box.
A p one is considered Hearing Aid Compatible for acoustic coupling (microp one mode)
if it as an “M3” or “M4” rating. A digital wireless p one is considered Hearing Aid
Compatible for inductive coupling (telecoil mode) if it as a “T3” or “T4” rating.
T e tested M-Rating and T-Rating for t is device (FCC ID: H8NTN502A1) are M3 and T3.
HOW WILL I KNOW IF MY HEARING AID WILL WORK WITH A PARTICULAR DIGITAL
WIRELESS PHONE?
You’ll want to try a number of wireless p ones so t at you can decide w ic works t e
best wit your earing aids. You may also want to talk wit your earing aid professional
