NNOOTTEE::YYoouurraauutthhoorriizzeeddTTrruueeddeeaalleerr
mmaayypprroovviiddeeaaddddiittiioonnaallssuuppppoorrtt..
AALLTTEERRNNAATTIIVVEEMMEETTHHOODD
1. Stand beside the treadmill, attach the safety
key on the control panel and follow operating
instructions for running the treadmill at 3
mph. (Section 2.5)
2. If the belt is off-center to the right, turn the
left roller adjustment bolt counter clock-wise
1/4 turn. If the belt is off-center to the left,
turn the left roller adjustment bolt 1/4 turn
clockwise. (Figure 1 Detail 1) Observe belt:
if more correction is needed, turn the adjust-
ment bolt 1/4 turn and check again. Repeat
as needed.
3. Let the machine run for several minutes to
check the alignment. (Belt alignment does
not need to be perfect).
TREADBELT TENSION:
To assure maximum life of the treadbelt, roller
and drive motor, make sure the treadbelt
tension is set correctly. (Your treadbelt has
been properly tensioned at the factory.)
Turn both rear roller adjustment bolts
(Detail 1) counter-clockwise until treadbelt
just begins slipping when walking on it, then
turn both rear roller adjustment bolts clock-
wise in equal quarter turn increments until
treadbelt stops slipping. NOTE: Be sure to
run on treadbelt to ensure that the treadbelt
does not slip while under load.
SAFETY FEATURES
PPAADDDDEEDDHHAANNDDRRAAIILL
The padded hand rail and side rails are
mounted to the rear of the control console.
The bars provide a convenient support to
use throughout your workout.
OONN//OOFFFFSSWWIITTCCHH
The on/off switch is located to the right of the
power cord on the front of the machine. It
completely removes AC power from your
treadmill. [[IIttiissrreeccoommmmeennddeeddtthhaattyyoouuuusseetthhiiss
sswwiittcchhttoottuurrnntthheemmaacchhiinneeooffffaafftteerreeaacchhwwoorrkk--
oouutt..]]
CCIIRRCCUUIITTBBRREEAAKKEERR
Your TRUE treadmill is protected from
overload by a 15 amp circuit breaker that can
be reset in the event of a power overload. It is
located to the left of the power cord.
SSAAFFEETTYYKKEEYYAANNDDLLAANNYYAARRDD
You can protect yourself from injuries resulting
from unexpected loss of balance by attaching
the lanyard to your clothing at about waist
height when you use your treadmill. WWhheenntthhee
ssaaffeettyykkeeyyiissddeettaacchheedd,,yyoouurrttrreeaaddmmiillllwwiillllnnoott
ooppeerraattee..SSttoorriinnggtthheessaaffeettyykkeeyyiinnaasseeccuurreedd
llooccaattiioonnwwhhiilleeyyoouurrttrreeaaddmmiilllliissnnoottiinnuusseewwiillll
pprreevveennttcchhiillddrreennaannddootthheerruunnaauutthhoorriizzeedd
uusseerrssffrroommooppeerraattiinnggyyoouurrttrreeaaddmmiillll..
RREEAARRRROOLLLLEERRSSHHIIEELLDDSS
Steel guards over the ends of the rear roller
prevent towels and other items from getting
caught in the running belt.
FFUULLLLYYEENNCCLLOOSSEEDDMMOOTTOORR
The motor and flywheel are fully enclosed in a
protective metal compartment.
LLOOWWPPRROOFFIILLEEFFRRAAMMEE
To enhance safety, TRUE treadmills are
designed to be as low to the ground as possi-
ble.
Treadbelt Tension & Safety Features
1-5
Figure 1
