Tricity Bendix DH 102 D User manual
Dishwasher
DH 102
INSTRUCTION BOOK
2
Description of the appliance
1. Water hardness adjustment
2. Levelling spacers
3. Upper basket stop
4. Salt container
5. Large filter
6. Detergent dispenser
7. Control panel
8. Rating plate
9. Rinse aid dispenser
10. Central filter
11. Lower spra arm
12. Upper spra arm
13. Upper basket
14. Worktop
1
2
3
4
5
6
7
8
9
10
11
12
13
14
IN68
3
The control panel
1. MAIN ON indicator light
2. On/Off push button
3. Programme guide
4. Door handle
5. Programme marker
6. Programme selector dial
7. Programme sequence indicator
As the programme progresses, the programme
selector dial turns, to show the phase in the wash
programme the appliance has reached.
Prewash / Rinse and Hold
Wash
Cold rinse
Hot rinse
Dr ing
4
Washing programmes
Programme Degree of soil
and
type of load
Required
push button
tarting
position of the
programme
selector
Recommended
quantity of
detergent
Wash Prewash
Normal soil
Crocker and cutler
Light soil
Crocker and cutler
Light soil
Crocker , cutler and
part crocker
An .
Partial load (to be
completed later in the
da ).
Cycle description
*POWER
WA H
NORMAL
WA H
** ECO WA H
RIN E
& HOLD
Cold prewash
Main wash up to 65°C
1 cold rinse
1 hot rinse
Dr ing
Main wash up to 65°C
1 cold rinse
1 hot rinse
Dr ing
Main wash up to 65°C
1 cold rinse
1 hot rinse
1 cold rinse (to avoid
food scraps from
sticking together).
*Testing programme for EN 50242 (see "Hints for Test Centres").
** This is a special programme for quick washing a full load of lightl soiled dishes, glasses and crocker (except pots) so
that ou ma re-use them promptl .
25 g 5 g
30 g /
30 g /
//
1
On/Off
On/Off
On/Off
On/Off
2
3
4
5
1. Check the filters
Ensure the are clean and properl positioned
See "Maintenance and cleaning" section.
2. Check that there is rinse aid and
salt
See "Before Use" section.
3. Load the dishes
Remove an scraps of food.
Pull the lower basket out and arrange the
saucepans, plates and cutler in it.
Pull the upper basket out and arrange the plates,
saucers, glasses and cups etc. in it.
Slide the baskets back into the machine.
4. Ensure that the spray arms can
rotate freely.
5. Measure out detergent
Add the required amount of detergent into the
dispenser according to the "Washing programmes"
chart.
Close the detergent dispenser lid.
6. Close the dishwasher door
7. et the programme
Turn the programme selector dial clockwise until
the number of the programme ou wish to select
corresponds with the programme marker on the
control panel.
8. tart the programme
Depress the On/Off push button.
The MAINS ON indicator light will come on and the
machine will start.
If ou wish to interrupt the washing programme at
an time open the door and press this button
again.
9. At the end of the washing
programme
At the end of the programme the dishwasher will
automaticall stop.
10. witch off the dishwasher
Switch off the dishwasher b pressing the On/Off
push button.
Wait 15/20 minutes before opening the
dishwasher’s door; in this way you will avoid
burning yourself when removing the dishes
and avoid also the damage of the nearby
furniture caused by the escape of steam.
Empt the lower basket first and then the upper
one; this will avoid water dripping from the upper
basket onto the dishes in the lower one.
When the washing programme has finished, it
is recommended that the dishwasher is
unplugged and the water tap turned off.
In general it is not advisable to open the door
while the machine is working; if the door is
opened however, a safety device ensures that
the machine stops.
Important!
Care must be taken if the door is opened during
the hot phase or immediately after a
programme has finished, as steam may escape.
Operating sequence
6
Loading your appliance
Before placing dishes in the machine, remove an scraps of
food, to avoid clogging the filters and consequentl reducing
the performance.
Do not load very small items which can fall
through the baskets.
The lower basket
The lower basket is designed to take saucepans, lids,
plates, salad bowls, cutler etc.
Serving dishes and large lids should be arranged around the
edge of the basket, ensuring that the upper spra arm can
turn freel .
The cutlery basket
Long bladed knives stored in an upright position
are a potential hazard.
Long and/or sharp items of cutlery such as
carving knives must be positioned horizontally in
the upper basket.
Take care when loading or unloading sharp items
such as knives.
Cutler should be placed in the removable cutler basket
with the handles facing downwards.
If the handles protrude from the bottom of the basket,
obstructing the lower spra arm, load the cutler with the
handles facing upwards.
Mix spoons with other cutler to prevent them from sticking
together.
Arrange spoons, dessert spoons, knives and other small
items of cutler in the rack on the side of the cutler basket.
UI49
UI19
UI40
Using your appliance
7
The upper basket
The upper basket is designed for plates (dessert plates,
saucers, dinner plates of up to 25 cm in diameter), salad
bowls, cups and glasses.
Arrange items so that water can reach all surfaces.
Light items (plastic bowls etc.) should be loaded in the
upper basket and arranged so the do not move.
In case that plates are loaded in the upper
basket:
load them starting from the rear positions of the basket;
tilting them slightly forwards and avoiding the front
positions near the door.
Before closing the door, ensure that the spray
arms can rotate freely.
Adjusting the height of the upper
basket
If washing ver large plates (over 27 cm and up to 32 cm
in diameter) ou can load them in the lower basket after
moving the upper basket to the higher position.
To move to the higher position proceed as follows:
1. Move the front runner stops (A) of the upper basket
outwards and slide the basket out.
2. Refit the basket in the higher position and replace the
stops (A) in their original position.
When the top basket is in the higher position it
will only take plates up to 20 cm in diameter
and you will not be able to use the cup rack.
After loading your machine always close the
door, as an open door can be a hazard.
US64
A
RC01
US71
Dimensions Width 60 cm
Height with worktop 85 cm
Height without worktop 82 cm
Max depth 61 cm
Max depth with open door 115.2 cm
Electrical connection Voltage 220/240 V - 50 Hz
Motor rating during wash 200 W
Power of heating element 2100 W
Overall power 2300 W
Water suppl pressure Minimum 50 kPa (0.5 bar)
Maximum 800 kPa (8 bar)
Capacit 12 place settings
Technical specifications
8
Hints for test centres
Before starting an test it is necessar to fill completel with salt the salt container and with rinse aid the rinse aid dispenser
Test standard: EN 50242
Reference programme: NORMAL WASH
Load: 12 standard place settings
Rinse aid selector: position 5
Detergent dosage: 25 g in the dispenser
5 g on the dispenser lid
Arrangement
upper basket Arrangement
lower basket
9
Fitting under a counter
(kitchen worktop or sink)
B removing the machine’s worktop, ou can install it
under a close fitting sink unit or a pre-existing top,
providing the dimensions of the recess correspond to
those shown in the picture.
Proceed as follows:
- Remove the machine’s worktop b unscrewing the two
rear retaining screws, pull from the front and slide out
the rear slots, lifting the worktop.
Insert the machine after adjusting height and levelling with
the adjustable feet. When inserting the machine, ensure
that the water inlet and drain hoses are not kinked or
squashed.
Levelling
Good levelling is essential for correct closure and sealing
of the door.
When the appliance is correctl levelled, the door will not
catch on the levelling spacers on either side of the
cabinet.
If the door does not close correctl , loosen or tighten the
adjustable feet until the machine is perfectl level.
820
570 - 600
600
IN05
IN06
IN07
152976 36/0
Tricity Bendix, 55-77 High Street, Slough, Berkshire, SL1 1DZ
Customer care telephone number...
08705 950 950
©Electrolux Household Appliances Limited 2001
From the Electrolux Group. The world’s No.1 choice.
The Electrolux Group is the world’s largest producer of powered appliances for kitchen,
cleaning and outdoor use. More than 55 million Electrolux Group products (such as
refrigerators, cookers, vacuum cleaners, chain saws and lawn mowers) are sold each year
to a value of approx. 14 billion USD in more than 150 countries around the world.
UK
0 07/01
