Triarch Indoor Lighting 29235 User manual

07.07

IF IN DOUBT ABOUT ELECTRICAL INSTALLATION,

CONSULT A LICENSED ELECTRICIAN!

ASSEMBLY INSTRUCTIONS FOR 29235

Knured nut Coupling

Finial

Leaves

Cap

Nipple

Fixture body

Tree with

loop

1. Before beginning the assembly, carefully unpack and identify all parts referring to the illustration.

2. Turn power to the installation point OFF.

3. Unravel the supply power and ground wires and pass the hole of tree with loop.

4. Unfold the arm of fixture body to proper position.

5. Make sure to remove the coupling, knurled and cage of fixture body before installing proper bulbs

(not provided) to each socket inside the cage referring to the markings and labels on fixture for

maximum wattage.

6. Thread tree with loop onto the protruding nipple at top of fixture body.

7. Thread the nipple into the coupling at the bottom of fixture body.

8. Locate cap and leaves carefully, and place them over the nipple, secure with finial.

9. Install proper bulbs (not provided) to the remaining sockets referring to the markings and labels

on fixture for maximum wattage.

10. Restore power to the installation point ON. Retain this sheet for future reference.
