TRENDnet TE100-SK1plus Owner's manual

FEATURES 10/100Mbps PCI Fast Ethernet Card

 Realtec RTL8139 based chipset

 10/100Mbps auto-sensing

 Supports half- and full-duplex operation

 Single UTP/STP RJ-45 connector (CAT 3, 4, 5 UTP/STP cables for 10Mbps operation

and CAT 5 UTP/STP cable for 100Mbps operation)

 32-bit PCI Bus master mode

 Plug and Play (PnP)

 Compatible with all popular network operating systems

 5-years warranty

5-port 100Base-TX Fast Ethernet Hub

 Supports five 100Base-TX UTP/STP RJ-45 ports per hub

 MDI-II uplink port (shared with port 1) allows connection to another 100Base-TX

Class II hub/switch without using the crossover cable

 Connects with UTP/STP Category 5 cables

 Status LED indicators for easy viewing and troubleshooting

 Auto-partitioning function isolates network failure

 Sturdy all metal housing

 5-years warranty

SOFTWARE SUPPORT

 Windows NT  NDIS Driver

 Windows 95/98/98Me/2000  DEC PATHWORKS

 Windows for Workgroups 3.11  Banyan

 Novell NetWare  SCO UNIX

 LAN Manager  Packet Driver

 IBM LAN Server  FTP PC/TCP

 IBM LAN Support  NCSA TCP/IP

 IBM TCP/IP  LINUX

TRENDnet’s 100Mbps

Fast Ethernet Starter Kit

TRENDnet’s TE100-SK1plus 100Mbps Fast Etherne

Starter Kit is a complete networking solution for connect-

ing two personal computers to share files, printers, hard

drives, and other peripherals. The kit comes with two

10/100Mbps PCI cards, a 5-port 100Base-TX hub, two 20

feet CAT 5 cables, and an easy-to-use installation guide.

Designed especially for home and small office use, this

reliable kit lets you cruise in 100Mbps speed and allows

expansion of your future networks.

TE100-SK1

plu

TOP REASONS THE TE100-SK1

plus

IS A LASTING TREND

Upgradeable: Add nodes as needed.

Expandable: Add a server or workstation, Internet station, and network printer without changing the hub.

Flexible: Hub is small enough to be installed anywhere it is needed.

Cost Effective: With lifetime warranty, purchase only the parts you need.

TE100-SK1plus 5-port 100Mbps Fast Ethernet Network Starter Kit

TE-SK1plus 5-port 10Mbps Network Starter Kit

TE100-SK2 4-port 10/100Mbps Dual-Speed Network Starter Kit

TE100-SK3plus 5-port 10/100Mbps Switched Fast Ethernet Network Kit

To order please call: 888-326-6061

3135 Kashiwa Street • Torrance, CA 90505 • (310) 891-1100 • Fax: (310) 891-1111

Sales: sales@trendware.com • Support: [email protected]

TE100-SK1

plu

100Mbps Fast Ethernet Starter Kit

PRODUCT

INFORMATION

Network Solution for TE100-SK1plus
