TRENDnet TEW-703PIL User manual
FEATURES
• Compatible with low prole desktop computers
• Wi-Fi compliant with IEEE 802.11n standard
• Backwards compatible with IEEE 802.11g and IEEE 802.11b devices
• Supports Ad-Hoc (Peer-to-Peer b/g only) or Infrastructure (AP-Client) mode
• High-speed data rates up to 150Mbps using an IEEE 802.11n connection
• Dynamic Data Rate Scaling from 150Mbps to 1Mbps
• Maximum reliability, throughput and connectivity with Automatic Data Rate Switching
• Supports advanced wireless encryption up to WPA/WPA2-RADIUS
• Easy user setup and diagnostic utilities
• Coverage of up to 50 meters indoor and 150 meters outdoor *
• 3-year limited warranty
*Maximum wireless signal rates are referenced from IEEE 802.11 theoretical specications. Actual data throughput and
coverage will vary depending on interference, network trafc, building materials and other conditions.
TEW-703PIL
rev: 10.19.2011
150Mbps Low Profile Wireless N PCI Adapter
TEW-703PIL (V1.0R)
The 150Mbps Low Prole Wireless N PCI Adapter, model TEW-703PIL, con-
nects a low prole desktop computer to a high speed wireless n network.
This adapter installs quickly to a free PCI slot on a Window’s based low prole
desktop computer. An LED conveys wireless connection status. Advanced wire-
less encryption protects your valuable data. A detachable antenna gives users
the ability to change the connected antenna. Stream media, download les, and
play games on a desktop computer over a wireless connection.
150Mbps Low Profile Wireless N PCI Adapter
TEW-703PIL (V1.0R)
SPECIFICATIONS
HARDWARE
Interface • 32-Bit PCI 2.1 Bus
• Compatible with low prole desktop computers
Standards • IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
LED Indicator • Link/ Activity
Power Consumption • Receive mode: 350mA (max.)
• Transmit mode: 400mA (max.)
Supported OS • Windows 7 (32/64-bit), Vista (32/64-bit), XP (32/64-bit)
Dimensions • 120 x 44 mm (4.7 x 1.75 in.)
Weight • 55 g (1.8 oz)
Temperature • Operating: 0° ~ 40° C (32° ~ 104° F)
• Storage: -10° ~ 70° C (14° ~ 158° F)
Humidity • 95% max. (non-condensing)
Certications • CE, FCC
WIRELESS
Modulation • DBPSK/DQPSK/CCK/OFDM (BPSK/QPSK/16-QAM/64-QAM)
Antenna • 1 x 2dBi dipole detachable antenna with Reverse SMA connector
Frequency • 2.412 ~ 2.484 GHz
Data Rate (auto fallback) • 802.11b: up to 11Mbps
• 802.11g: up to 54Mbps
• 802.11n: up to 150Mbps
Output Power • 802.11b: 15dBm (typical)
• 802.11g: 14dBm (typical)
• 802.11n : 12dBm (typical)
Receiving Sensitivity • 802.11b: -84dBm (typical) at 11Mbps
• 802.11g: -65dBm (typical) at 54Mbps
• 802.11n: -61dBm (typical) at 150Mbps
Encryption • 64/128-bit WEP (Hex & ASCII), WPA/WPA2 (TKIP/AES), WPA-PSK/WPA2-PSK
Channels • 1~11 (FCC), 1~13 (ETSI)
TEW-703PIL
rev: 10.19.2011
150Mbps Low Profile Wireless N PCI Adapter
TEW-703PIL (V1.0R)
CONTACT INFORMATION
20675 Manhattan Place,Torrance, CA 90501 USA
Tel: 1-310-961-5500
Fax: 1-310-961-5511
Web: www.trendnet.com
Email: [email protected]
1-888-326-6061
PACKAGE CONTENTS
TEW-703PIL
CD-ROM (Utility & User’s Guide)
Multi-Language Quick Installation Guide
RELATED PRODUCTS
TEW-648UB 150Mbps Mini Wireless N USB Adapter
TEW-711BR 150Mbps Wireless N Home Router
TEW-648UBM 150Mbps Micro Wireless N USB Adapter
TRENDnet is a registered trademark. Other Brands and product names are trademarks of their respective holders. Information provided in this document pertain to TRENDnet products and is subject to change at any time,
without notice. For the most recent product information please visit http://www.trendnet.com Copyright ©TRENDnet.All Rights Reserved.
