Transcend JetFlash 220 User manual

User’s Manual

Fingerprint Security USB Flash Drive

JetFlash

220

(Version: 4.0)

Table of Contents

Introduction................................................................................ 3

Features.................................................................................................................3

System Requirements............................................................................................3

General Use...........................................................................................................4

Backing Up Data....................................................................................................4

Connecting to a Computer........................................................ 5

Disconnecting from a Computer.............................................. 6

Setting Up the Software............................................................ 7

JetFlash 220 Secure Login ..................................................... 10

JetFlash 220 Software Application......................................... 12

System Settings....................................................................... 13

Disk Repartition....................................................................... 15

Preferences.............................................................................. 17

Language.................................................................................. 18

Troubleshooting ...................................................................... 19

Specifications.......................................................................... 20

Two-year Limited Warranty..................................................... 21

Introduction

Congratulations on purchasing Transcend’s JetFlash

220. The JetFlash 220 is a unique ultra-portable

USB 2.0 Flash Drive that plugs directly into your desktop, or notebook computer and incorporates

cutting-edge Fingerprint Recognition Technology. Now you can securely store confidential files, folders,

documents, photos, music and e-work with the utmost confidence. This Software User’s Manual will help

you get the most from your new device, please read it in detail before using the JetFlash 220.

Features

•

Fully compatible with High-speed USB 2.0

•

Advanced fingerprint recognition technology

•

Easy Plug and Play operation

•

Repartition tool for adjusting the size of the Private and Public portions of the drive

•

USB powered. No external power or battery needed

•

LED data transfer / fingerprint authorization indicator

•

Driverless installation

System Requirements

1. A desktop or notebook computer with a working USB port.

2. The JetFlash 220 can only be used in a computer running the following Operating Systems (OS):

•

Windows



XP (32bit/64bit)

•

Windows

Vista



(32bit/64bit)

•

Windows



7 (32bit/64bit)

Important Reminders

These usage and safety guidelines are IMPORTANT! Please follow them carefully.

Figure 1. JetFlash 220

WARNING! The fingerprint sensor on the JetFlash 220 is delicate and should be handled with care

to prevent physical damage. Avoid squeezing or scratching your JetFlash 220 with hard or sharp

objects. Always close the protective cover when not in use or during transport.

General Use

•

Each time you plug the JetFlash 220 into your computer it will install a new Virtual CD-ROM

Drive labeled “JetFlash 220” that contains the fingerprint security application and its

associated files. Do NOT attempt to edit, delete, or modify any of the data on this disk.

•

Always follow the procedures in the “Disconnecting from a Computer” section before

removing your JetFlash 220 from a computer.

Backing Up Data

•

Transcend does NOT take any responsibility for data loss or damage during

operation. If you decide to store data on your JetFlash 220, we strongly advise that you

regularly backup the data to a computer or other storage medium.

•

To ensure High-Speed USB 2.0 data transfer rates when using your JetFlash 220 with a

computer, please make sure the computer has all relevant USB drivers installed. If you are

unsure how to check this, please consult the computer or motherboard User’s Manual for

USB driver information.

Connecting to a Computer

Plug the JetFlash 220 directly into an available USB port on your desktop or notebook computer.

Figure 2. Connecting to a computer

When the JetFlash 220 is successfully connected to a computer the drive’s LED will light up. A Removable

Disk drive with a newly assigned drive letter representing the JetFlash 220 and a “JetFlash220” virtual

CD-ROM drive containing the fingerprint software program will appear in the My Computer window. In

addition, a Removable Hardware icon and Fingerprint Application Suite icon will appear on the

Windows System Tray.

Figure 3. F, G& H: are example drive letters, the letters in your "My Computer" window may differ

In your computer browser (My Computer), open the JetFlash 220 virtual CD-ROM drive and double-click

the JetFlash220.exe application. If this is your first time using the JetFlash 220, please see Setting Up the

Software below.

Scan your fingerprint or enter your password when the Fingerprint Verification window appears.

Once you are successfullylogged in, youwill have access to the JetFlash 220’s private storage capacity, and

can copy data to the flash drive by simply dragging and dropping files or folders onto the Removable Disk

drive letter that represents the JetFlash 220.

Do NOT attempt to edit, delete, or modify any data on the JetFlash220 virtual CD-ROM drive

Disconnecting from a Computer

When you are finished using the JetFlash 220

click on the “Fingerprint Application Suite” icon

on the Windows System Tray and select the “Quit” option.

Figure 4. Quit

NEVER disconnect the JetFlash 220 from a Computer when its LED is flashing.

Select the Removable Hardware icon on the system tray.

The Safely Remove Hardware pop-up window will appear. Select it to continue.

Figure 5. Safely Remove Hardware

A message window will appear stating, “The ‘USB Mass Storage Device’ device can now be safely

removed from the system.”

Figure 6. Safe to Remove Hardware

WARNING! To prevent data loss, always use this procedure before removing the JetFlash

220 from a Windows

computer.

Setting Up the Software

Plug the JetFlash 220 directly into an available USB port on your desktop or notebook computer.

In your computer browser (My Computer), open the JetFlash 220 virtual CD-ROM drive and double-click

the JetFlash220.exe application.

Input a ”User Name” and a ”Password” and then confirm your password. User Names and Passwords

are case sensitive and can be any combination of letters and numbers (no spaces). Click the ”Next”

button to continue.

Figure 7. Enter a user name and password

Use your mouse to select one of the 10 available fingers.

Figure 8. Select a finger

Setting up the fingerprint software requires sliding the selected finger or thumb along the JetFlash 220’s

built-in scanner three times to register your fingerprint information. Please be patient when you are

performing this procedure, as it may take a few attempts to register your fingerprint profile.

Figure 9. Three successful scans must be completed to confirm finger enrollment

The”Fingerprint successfully registered” message will appear after completing three accurate scans.

Figure 10. Fingerprint successfully registered.

After finger enrollment, you have to set the Verification Method. Authentication Method as below:

1. Fingerprint: Confirm user identity using only fingerprint verification.

2. Password: Confirm user identity using only text-based password verification.

3. Both: Both a fingerprint scan and password input will be required to verify user identity. After

successful fingerprint verification, you will also need to input the correct password associated with that

fingerprint.

4. Either: With this setting, users will be prompted for fingerprint verification first, then if fingerprint

authentication fails five times, text-based password verification will be used instead.

Figure 11. Set the Verification Method.

Finally, please customize the size of the Private and Public areas on the JetFlash 220 by sliding the

adjustment bar to the left or right. After you have divided the JetFlash 220’s Private and Public areas

into your desired sizes, click on the “Format” button to begin repartitioning the drive.

Figure 12. Set Disk repartition.

JetFlash 220 Secure Login

To access protected data or change any of the fingerprint account settings on your JetFlash 220, you will

need to login via the Fingerprint Verification window. This screen will automatically appear when you run

the JetFlash 220 Fingerprint Application software (located on the JetFlash 220 virtual CD-ROM drive) to

access the JetFlash 220’s Private partition, and will also appear whenever you make changes to the

Fingerprint Application settings.

When the Fingerprint Verification window appears, scan your fingerprint or enter your secret password

to access protected data or change the JetFlash 220’s settings.

Figure 13. Fingerprint Verification Login

An incorrectly scanned or unrecognized fingerprint scan will cause an ”Error”message to be displayed.

Figure 14. Verification Failed
