Timberk TGH 4200 SM1 User manual

Instruction manual

Руководство по эксплуатации

Газовый

керамический

обогреватель

Модели/Models: TGH 4200 SM1

Gas

ceramic

heater

Производитель вправе менять внешний вид прибора и цветовую гамму при-

бора без специального уведомления.

Руководство по эксплуатации включает в себя гарантийный талон

www.timberk.com • gas heater

Dear Customer!

Thank you for good choice and purchase of the TIMBERK

household ceramic gas-fired heater. It will serve long.

The TIMBERK household ceramic gas-fired heater is designed

for room heating and creation of comfortable atmosphere

in cold season. The heater can be installed only in vertical

position in well ventilated rooms. This heating appliance is

handy and simple in installation, efficient and economic in use

thanks to minimum losses, high heat output, and maximum

comfortable distribution of heat flow.

Please carefully read the Operation Manual before using the heater.

This Operation Manual contains the important information on your safety,

as well as some recommendations on proper use of the appliance and its

maintenance.

Keep the Operation Manual along with the warranty certificate, sales

receipt, and, if possible, cardboard package and packing material.

The purchased heater may somewhat differ from one described in the

Manual, but this does not affect the methods of use and operation.

Important precautions and instructions given in this manual do not include all

possible modes and situations, which can be encountered. It is necessary

to understand that common sense, cautiousness, and carefulness are the

factors, which cannot be «integrated» to any product.

These factors should be considered by the person, who is interested in

proper operation of the device. The manufacturer is not responsible for

damage of the appliance or its components during transportation, as a

result of incorrect installation, as a result of voltage surges, as well as in the

event of changes or modifications in any part of the appliance.

tion of harm to health of the user and other people, as well as in infliction of

damage to their property.

1. Read all instructions before using the heater.

2. The heater warms during operation up to very high temperature. To

avoid burns, do not touch hot surfaces of the appliance by hand and other

body parts.

3. The appliance should be placed far from flammable and easily deform-

able objects.

4. Make sure that the appliance body and heating plates get cold before

demounting and placing the appliance to the package for long storage.

5. When the appliance is not used for a long time, keep it in dry cool place

in the factory cardboard package.

6. WARNING! DO NOT COVER THE APPLIANCE, when it works. Do not

dry clothes and any other fabrics/materials on the appliance. This may lead

to its overheating, ignition, breakdown, or infliction of a significant damage

to you and/or your property.

7. WARNING! Fabrics, clothes, and other flammable materials may ignite, if

they are placed near the face plate of the working appliance.

8. The appliance should be always attended, especially if there are children

thereabout. Carefully watch that children do not touch the appliance by

hand.

9. Use an appropriate gas pressure controller (reducer) set at 29-30 mbar.

10. Never disconnect the reducer or hose, when the gas cylinder check

valve is open.

11. It is prohibited to store/operate the gas-fired heater and replace the gas

cylinder in rooms, where other open flame sources are present.

12. Exclude overheating of the gas cylinder.

13. Do not place the heater closer than 1 m to other sources of heat and

thermal radiation.

14. Do not store gas cylinders (empty or filled) in the room, where the gas-

fired heater is operated.

IMPORTANT!

The manufacturer considers this type of failure a non-

guaranteed event.

1. IMPORTANT INFORMATION

2. PRECAUTIONS

During use of the gas-fired heater, it is necessary to observe some precau-

tions. Improper operation with disregard of precautions may result in inflic-

www.timberk.com • gas heater 3

15. Upon startup, the duration of pressing the gas valve button should not

exceed 40 seconds.

16. Never use the appliance in the situation, when it may contact water.

17. When the appliance is switched on and it works, do not touch its sur-

face and control unit surface by wet hand and any body parts.

18. It is prohibited to install and use the appliance in bathrooms, showers,

or near swimming pools, where water jets and drops may directly get onto

the appliance surface, when it is switched on.

19. Never try to repair the heater yourself. This may inflict harm to your

health and affect the warranty service of the appliance.

20. Do not use the heater in open spaces outdoors for a long time.

21. Do not lay the heater power cord under carpets and do not press it with

furniture. Lay the power cord so that nobody can stumble over it.

22. Do not insert fingers and exclude penetration of foreign objects to any

vents, air intakes, or outlets, since this may result in burn, other injuries, or

damage of the heater.

23. To prevent possible fire, do not block the air intakes and outlets any-

how. Do not hang or dry things on the heater! Use the heater only on even

dry surface.

24. The heater works with open flame and contains hot/sparking com-

ponents inside. Do not use the heater in places of handling or storage of

gasoline, paint, or any other flammable liquids.

25. Use the heater only as described in this Manual. Any other use not

recommended by the manufacturer may lead to fire, electric shock, or in-

juries of people.

26. Never clean the heater, when it works. Do not submerge the heater

into water.

27. Technical characteristics of gas, which will be used for Timberk gas

heaters must be absolutely the same, as rating labels & instruction manual

contain. It’s important.

28. It is prohibited to install the appliance immediately under an electric

socket or under a wired electric cable, when the output heat flows get to

them. This may result in their overheating causing an emergency situation.

29. Install and operate the appliance in strictly vertical position. It is prohib-

ited to operate the appliance in horizontal or inclined positions.

30. The appliance is not designed for use by people (including children)

with limited physical, sensory, or mental capabilities and having insufficient

experience/knowledge, if they are not supervised and instructed on use of

the device by a person responsible for their safety. It is necessary to watch

that children do not play with the heater.

3. WORKING PARAMETERS

Operation principle

Gas is fed via a custom-made nozzle to small ceramic burner cells, where

it is ignited. As a result, the burner ceramic parts incandesce up to high

temperatures with simultaneous air heating via immediate open flame and

heating of surrounding objects via thermal (infrared) radiation from hot ce-

ramic parts.

Main features

1. Combination of thermal radiation and heat generation via open gas com-

bustion makes the heater a cost-effective source of thermal power.

2. Quick self-repayment thanks to high efficiency and speed of reaching

set temperature.

3. Simplicity of installation, reliability in operation, and easiness of mainte-

nance.

4. Simple and effective capabilities of temperature control and gas saving

thanks to three-mode selection of heating power - a burner with gradual

start and three power levels.

5. Piezo-ignition of flame.

6. Gas shutoff upon flame-out - an integrated flame detector.

7. The ODS protection circuit (oxygen detector) switches the heater off, if

oxygen content in air decreases to 18%.

8. The integrated tipping sensor switches the heater off, if it is inclined from

the vertical position, for example, if the appliance is accidentally overturned

or inclined.

9. Wheel base for movement of the appliance and for installation of the

heater in any convenient place.

10. Integrated handle for movement.

11. Gas reducer and 60cm hose are enclosed.

12. Internal clamp for a gas cylinder.

www.timberk.com • gas heater

Technical specifications

For more detailed description of technical parameters and specifications

please refer to our website www.timberk.com or ask from the official

dealers of TIMBERK.

IMPORTANT!

The manufacturer reserves the right to change the set-list

of the device (including liquid and powder components)

for different supplies without prior notice. The changes

either in no way influence the basic technical parameters

of the device or may improve them, and also not violate

the legislation or quality standards of the countries of

manufacture, transit and selling.

The changes in the set-list may result in changing of the

weight and dimensions of the device, but not more than

by +\- 5-20% (depending on the product category)

4. GAS-FIRED HEATER DESCRIPTION

1. Heater body

2. Control panel

3. Ceramic gas-fired burner

4. Protective face grate

5. Support wheels

6. Gas valve

7. Gas check valve*

8. Gas hose

9. Gas pressure controller (reducer)

10. Gas cylinder clamp

11. Gas cylinder*

* Not included to set delivery

Fig. 1

Technical specification Unit of measurement TGH 4200 SM1

Heating power of gas-fired W 4200

Gas consumption by heating stages kW 1,4/2,8/4,2

Specific gas consumption g/hour 310

Gas type - Propane/Butane G30

Gas category - I3B/P

Gas pressure mbar 29-30

Gas cylinder type (maximum capacity) kg 5

Heating room area m230-60

Net weight kg 6,32

Dimensions mm 550x380x295

www.timberk.com • gas heater 5

1. Carefully remove the heater from the package.

2. Make sure that the heating elements and other parts of the appliance

have no remaining crumbles of packing foam plastic or other debris.

3. Carefully install the enclosed gas hose not twisting or breaking it. For

that, screw one end of the hose onto the gas valve connector, while the

other end onto the connector of the enclosed gas pressure controller

(reducer). Secure the hose ends on the connectors with jubilee clips.

1. Heater on wheeled base - 1 pc.

2. Gas pressure controller (reducer) - 1 pc.

3. Gas hose (60 cm) - 1 pc.

4. Jubilee clips - 2 pcs.

5. Operating manual and warranty card - 1 pc.

NOTE:

To improve the product quality, the design and

technical specifications of the heater, as well as its

delivery set can be modified by the manufacturer

without preliminary notification.

NOTE:

Heater can be supplied with the connected gas hose

and gear, in this case to produce the above steps are

not necessary.

6. PREPARATION FOR WORK

5. DELIVERY SET

4. Install a paronite/rubber spacer inside the cap nut checking its integrity

beforehand and then carefully screw the nut on the outlet of an already

IMPORTANT!

All gas joints and pipes should be absolutely tight to

exclude even slightest gas leaks. Never use matches,

lighters, and other sources of open flame for leak checks

of joints. Use soapy water.

It is prohibited to use the gas-fired heater in flats of high-

rise buildings, bedrooms, bathrooms, and cellars.

Upon first ignition, it is recommended to preliminarily

switch the heater on outdoors, after which it can be

used indoors.

The room, where the gas-fired heater is used, should be

equipped with natural ventilation.

Do not use the heater during sleep.

Always use only certified, recommended by the

manufacturer, and properly rated hoses/pressure

reducers for connection of the appliance.

Always use only the gas type indicated by the

manufacturer.

prepared gas cylinder having appropriate capacity (a gas cylinder is not

included in the delivery set and purchased separately). Twisting of the hose

is strongly not allowed.

5. Slowly turning the gas pressure controller (cylinder check valve), make

sure that no gas leaks are present. For that:

- Lubricate all joints with soapy water. Gas leaks cause formation of

bubbles in permeable places.

- NEVER USE MATCHES OR LIGHTERS for gas leak checks.

If you find a gas leak, shut gas and contact your dealer or manufacturer’s

service center.

6. Install the gas cylinder to the dedicated place inside the appliance and

secure with the clamp.

7. Carry the heater to the supposed place of operation observing the rules

and precautions described in Section 2 of this Instruction Manual.

8. The appliance is ready for work.

www.timberk.com • gas heater

IMPORTANT!

During operation of the appliance, watch that the gas

cylinder is always strictly vertical. Use of the cylinder

in any other position may result in occurrence of an

emergency situation, breakdown of the appliance, and

infliction of a significant damage to you and/or your

property.

It is prohibited to move or anyhow cover the heater

during operation, as well as after shutdown, if the heater

is still hot.

The heater should be placed for operation so that its

face plate is directed towards the room center. At that,

distances to walls or other objects on sides and behind

the appliance should be at least 1 m.

Ventilation

During operation, the gas-fired heater burns oxygen contained in air and

emits carbon dioxide (CO2).

It is important to remember that operation of the gas-fired ceramic heater is

permitted only in well ventilated rooms. This allows keeping the necessary

concentration of oxygen in air and removing combustion products.

Operation of the heater in closed and poorly ventilated rooms may create

an asphyxiating atmosphere and cause a lack of oxygen. If the oxygen

concentration decreases below 18%, the ODS system (oxygen detector)

activates and switches the heater off. In this case it is necessary to ventilate

the room before restarting the heating mode.

4. Draw up two finger nuts on one side and two finger nuts on the other - in

clamp extensions passed through the wheel plate supports, after making

sure that 2 openings in the wheel plate match together with the clamp

extensions (see Figure 3).

5. Turn the radiator back and tip it up.

7. CONTROL OF CERAMIC GAS-FIRED HEATER

IMPORTANT!

Do not start the gas-fired ceramic heater in rooms

having volume less than 84 m3.

The minimum area of a vent should be at least 105 cm2.

Necessary air exchange 10m3/ hour der 1 kW of thermal

power heater.

1. Handle of gas regulation

This handle uses for gas supply to gas burner, also for power modes

choice: 1-st mode (position), 2-nd mode (position), 3-rd mode (position)

2.Piezo ignition knob

It’s used to ignite the burner(s)

Start

1. Slowly unscrew the check valve of the gas cylinder.

2. Press and slowly turn the gas control knob on the control panel to « »

position (Fig.2). Keep the gas control knob pressed for 20-30 seconds.

At the same time, press the piezo-ignition button several times, until the

pilot lights up. Every time you press the piezo-ignition button, you can

hear a loud click and see a spark on the piezo-ignition electrode. Continue

keeping the gas control knob pressed for 10-15 seconds after ignition of

the pilot flame in order to activate the flame detector.

3. Leave the gas control knob in this position at least for 5 minutes for

stable ignition of the 1st heating stage. The pilot and central element of

the ceramic burner should be alight. This position corresponds to the heat

power of 1.4 kW.

4. To change the heating stage, slightly press the gas control knob and

slowly turn it anticlockwise until locking in « » or « » position, which

corresponds to the heat power of 2.8 kW and 4.2 kW.

Fig. 2

Сontrol panel (fig. 2)

www.timberk.com • gas heater 7

5. Do not leave the gas control knob in an intermediate position between

the fixed positions, and.

Shutdown

1. Press the gas control knob and turn it to « » position. The pilot and

central element of the ceramic burner should be alight.

2. Screw the check valve on the gas cylinder clockwise up to the stop.

3. If you do not plan to use the heater in the nearest time, disconnect

the gas cylinder from the reducer. Remove the gas cylinder to the storage

place according to the recommendations and requirements described in

the Manual.

Gas cylinder replacement

1. Make sure that the heater is switched off.

2. If it is necessary to replace an empty gas cylinder, shut gas screwing the

gas check valve on the cylinder clockwise up to the stop.

3. Remove the cylinder clamp and take the cylinder out of the heater body.

4. Remove the gas pressure reducer from the cylinder unscrewing its cap nut.

5. Connect and install a full gas cylinder as indicated in Section

6. Preparation for work.

ATTENTION!

Do not smoke during replacement of the cylinder.

Do not replace the cylinder, if there is an open flame

source nearby. Keep gas cylinders in a separate well-

ventilated room far from combustible materials. It is

prohibited to store and operate gas cylinders in flats of

high-rise buildings, cellars, garrets.

1. Regularly check the integrity of the gas hose between the gas pressure

reducer and gas valve of the appliance. If any damage of the hose is found,

operation of the appliance is prohibited and the hose should be replaced.

2. Regularly check all gas joints, pipes, and devices for gas leaks (using

soapy water). If any gas leak is found, immediately switch the heater off,

disconnect the gas cylinder, and contact the dealer or manufacturer’s

service center.

3. The appliance should be regularly washed to remove dust and dirt from

outer surfaces, since they affect efficiency of its operation and temperature

parameters of room heating. Before commencing preventive maintenance,

switch the appliance off and let the appliance cool down and then wipe its

surface with slightly wet soft rag.

4. Detergents including those containing abrasives in composition are not

recommended for washing. Exclude damage of the appliance with sharp

objects, since scratches on the painted surface may result in rusting.

5. The rear surface of the gas-fired heater also should be periodically

cleaned to remove dust and dirt. The procedure of preventive cleaning

should be carried out periodically to maintain the technical condition of the

heater and keep its appearance for long years.

8. MAINTENANCE

www.timberk.com • gas heater

If you are not able to remedy a malfunction according to the recommen-

dations or other malfunctions occur, contact the authorized service center

of Timberk.

9. TROUBLESHOOTING

Troubleshooting Probable cause Remedy

Pilot burner does not ignite Defective piezoelectric element Contact an authorized service center Timberk

Not connected electrical wires to

piezoelectric element

Connect the electrical wires piezoelectric element

Damaged electrical wires

piezoelectric element

Contact an authorized service center Timberk

Improper position of the electrode

relative to the piezoelectric

element pilot burner

Adjust the position of the electrode relative to

the pilot burner so that the spark ran along the

flow of gas and did not get on the housing or

outlet of the unit

Pilot light is lit evenly, but

goes out when you release

the gas control knob

Thermocouple wire is

disconnected from the gas valve

Connect the thermocouple to the gas valve

Pilot light is lit evenly, but

goes out when you release

the gas control knob

Incorrect position sensor

thermocouple relative to the

pilot burner

Adjust the position of the thermocouple sensor in

relation to the pilot burner so that he was on fire

Faulty sensor fall Contact an authorized service center Timberk

Pilot burner burns unevenly,

flame detached from the

base and goes off when you

release the gas control knob

Low gas quality is used Use a good quality gas

Faulty gearbox - too high or low

gas pressure

Contact an authorized service center Timberk

Strong ceramic burner flame Faulty gearbox - too high gas

pressure

Contact an authorized service center Timberk

www.timberk.com • газовый обогреватель 9

Уважаемый покупатель!

Благодарим вас за удачный выбор и приобретение кера-

мического газового обогревателя TIMBERK. Он прослужит

вам долго.

Керамический газовый обогреватель TIMBERK предназна-

чен для обогрева рабочих мест и зон в производственных

помещениях и на открытых площадках строек, складов,

теплиц, террас, мастерских, гаражей и т. д., обществен-

ных помещений с временным пребыванием людей. Обо-

греватель может быть установлен только в вертикальном

положении в хорошо проветриваемых помещениях. Дан-

ный нагревательный прибор удобен и прост в установке,

эффективен и экономичен в использовании в связи с ми-

нимальными потерями, повышенной теплоотдачей и мак-

симально комфортным распределением теплового потока.

Просим внимательно ознакомиться с руководством по эксплуатации

перед использованием керамический газовый обогреватель.

В данном руководстве по эксплуатации содержится важная инфор-

мация, касающаяся Вашей безопасности, а также рекомендации по

правильному использованию прибора и уходу за ним.

Сохраните руководство по эксплуатации, вместе с гарантийным та-

лоном, кассовым чеком, и, по возможности, картонной упаковкой и

упаковочным материалом.

Приобретенный Вами керамический газовый обогреватель может не-

сколько отличаться от описанного в руководстве, что не влияет на

способы использования и эксплуатации.

При использовании газового обогревателя, необходимо соблюдать

ряд мер предосторожности. Неправильная эксплуатация в силу иг-

норирования мер предосторожности может привести к причинению

вреда здоровью пользователя и других людей, а также нанесения

ущерба их имуществу.

1. Прочитайте все инструкции перед использованием обогревателя.

2. Обогреватель при работе нагревается до очень высокой темпе-

ратуры. Чтобы избежать ожогов, не прикасайтесь руками и другими

частями тела к горячим поверхностям прибора.

3. Прибор должен располагаться вдали от легковоспламеняющихся и

легкодеформируемых объектов.

4. Удостоверьтесь, что корпус прибора и его нагревательная поверх-

ность остыли, прежде чем прибор будет демонтирован и уложен в

упаковку для длительного хранения.

5. Когда прибор не используется долгое время, храните его в сухом

прохладном месте в заводской картонной упаковке.

6. ВНИМАНИЕ! НЕ НАКРЫВАЙТЕ ПРИБОР, когда он работает. Не су-

шите на нём одежду и любые другие ткани и материалы. Это может

привести к его перегреву, возгоранию, выходу из строя или причине-

нию значительного ущерба Вам и/или Вашему имуществу.

ВНИМАНИЕ!

Эти факторы должен учитывать человек, который

заинтересован в надлежащей эксплуатации устрой-

ства. Изготовитель не несет ответственности в слу-

чае повреждения прибора или его отдельных частей

во время транспортировки, в результате неправиль-

ной установки, в результате колебаний напряжения,

а также в случае, если какая-либо часть прибора

была изменена или модифицирована.

ВНИМАНИЕ!

Важные меры предосторожности и инструкции, со-

держащиеся в данном руководстве, не включают всех

возможных режимов и ситуаций, которые могут встре-

чаться. Необходимо понимать, что здравый смысл,

осторожность и тщательность являются факторами,

которые невозможно «встроить» ни в один продукт.

1. ВАЖНАЯ ИНФОРМАЦИЯ

2. МЕРЫ ПРЕДОСТОРОЖНОСТИ

www.timberk.com • газовый обогреватель

ВНИМАНИЕ!

Производитель рассматривает данный вид полом-

ки, как негарантийный случай.

7. ВНИМАНИЕ! Ткани, одежда и другие лекговоспламеняющиеся ма-

териалы могут загореться, если находятся напротив лицевой панели

работающего прибора.

8. Прибор всегда должен находиться под наблюдением, особенно

если неподалеку от прибора находятся дети. Внимательно следите за

тем, чтобы дети не прикасались к прибору руками.

9. Используйте соответствующий регулятор (редуктор) давления газа,

отрегулированный на 29-30 мбар.

10. Никогда не отсоединяйте редуктор или шланг при открытом вен-

тиле газового баллона.

11. Запрещается хранение, эксплуатация газового нагревателя, а

также замена газового баллона в помещениях, где есть другие от-

крытые источники пламени.

12. Не подвергайте газовый баллон перегреву.

13. Не располагайте обогреватель ближе 1 м к другим источникам

нагрева и теплового излучения.

14. Не храните газовые баллоны (пустые или наполненные) в помеще-

нии, где эксплуатируется газовый обогреватель.

15. При розжиге запальной горелки продолжительность нажатия руч-

ки регулировки газа не должна превышать 40 секунд.

16. Никогда не используйте прибор в ситуации, когда он может со-

прикасаться с водой.

17. Когда прибор включен и работает, не касайтесь его поверхности и по-

верхности панели управления мокрыми руками и любыми частями тела.

18. Запрещено устанавливать и использовать прибор в ванных ком-

натах, душевых или бассейнах, а также в тех местах, где есть вероят-

ность попадания струй и капель воды на его поверхность во время,

когда прибор включен.

19. Никогда не пытайтесь производить ремонт обогревателя само-

стоятельно. Это может причинить вред вашему здоровью и повлиять

на гарантийное обслуживание прибора.

20. Не используйте обогреватель на открытых пространствах вне по-

мещения длительное время.

21. Не просовывайте пальцы и исключите попадание посторонних

предметов в какие-либо вентиляционные, воздухозаборные или вы-

ходные отверстия, так как это может привести к ожогу, другим трав-

мам или повреждению обогревателя .

22. Для предотвращения возможного пожара не загораживайте ни-

чем воздухозаборные и выходные отверстия. Не вешайте и не сушите

вещи на обогревателе! Используйте обогреватель только на ровной

сухой поверхности.

23. Обогреватель работает с открытым пламенем, а также содержит

внутри горячие и искрящие компоненты. Не используйте обогрева-

тель в местах использования или хранения бензина, краски или дру-

гих легковоспламеняющихся жидкостей.

24. Используйте данный обогреватель только так, как описано в дан-

ном руководстве. Любое другое использование, не рекомендуемое

изготовителем, может привести к пожару, поражению электрическим

током или травмированию людей.

25. Ни в коем случае не выполняйте очистку обогревателя, когда он

работает. Не погружайте обогреватель в воду.

26. Характеристики используемого газа должны быть в строгом соот-

ветствии с характеристиками, указанными в таблице 1, технических

характеристики на корпусе прибора.

27. Запрещено устанавливать прибор непосредственно под электри-

ческой розеткой или под проведенным электрическим кабелем, когда

выходящие тепловые потоки попадают на них. Это может привести к

их перегреву, что создаст аварийную ситуацию.

28. Устанавливайте и эксплуатируйте прибор в строго вертикальном

положении. Запрещено эксплуатировать прибор в горизонтальном

или наклонном положениях.

29. Прибор не предназначен для использования лицами (включая де-

тей) с ограниченными физическими, сенсорными или умственными

возможностями, обладающими недостаточным опытом и знаниями,

если они не находятся под наблюдением и не получили инструкций

по использованию устройства от лица, ответственного за их безопас-

ность. Необходимо следить, чтобы дети не играли с обогревателем.

Other manuals for TGH 4200 SM1

Table of contents

Other Timberk Heater manuals

Timberk

Timberk TEC.E1X M 1000 User manual

Timberk

Timberk TEF T12 TN1 User manual

Timberk

Timberk T-FH2-B10S-W User manual

Timberk

Timberk TFH S20SMA User manual

Timberk

Timberk RE8 Series User manual

Timberk

Timberk T-EC1000-X2E-WF User manual

Timberk

Timberk TFH T20MDR User manual

Timberk

Timberk T-FH1.2-B10MC-B User manual

Timberk

Timberk T-IR1500-A12SI User manual

Timberk

Timberk TEC.PF8 LE 1000 IN User manual

Timberk

Timberk AERO I Series User manual

Timberk

Timberk TEF T12 TN1 User manual

Timberk

Timberk TOR 21.1507 DPX User manual

Timberk

Timberk T-HG2-Q10T User manual

Timberk

Timberk TIR HP1 1500 User manual

Timberk

Timberk TOR 21.1005 BCX User manual

Timberk

Timberk TFH S20SMX User manual

Timberk

Timberk TFH T15NTX User manual

Timberk

Timberk TFH T20MDR User manual

Timberk

Timberk TEC.PF3 M 1000 IN User manual

Timberk

Timberk TOR 21.1507 NMN User manual

Timberk

Timberk TCH Q1 800 User manual

Timberk

Timberk TFH T05UFX User manual

Timberk

Timberk TEC.PS1 M 500 IN User manual

Popular Heater manuals by other brands

oventrop

oventrop Regucor Series quick start guide

Blaze King

Blaze King CLARITY CL2118.IPI.1 Operation & installation manual

ELMEKO

ELMEKO ML 150 Installation and operating manual

BN Thermic

BN Thermic 830T instructions

KING

KING K Series Installation, operation & maintenance instructions

Empire Comfort Systems

Empire Comfort Systems RH-50-5 Installation instructions and owner's manual

Well Straler

Well Straler RC-16B user guide

EUROM

EUROM 333299 instruction manual

Heylo

Heylo K 170 operating instructions

Eterna

Eterna TR70W installation instructions

Clarke

Clarke GRH15 Operation & maintenance instructions

IRSAP

IRSAP The Radiator Company Ovali Fitting instructions

Empire Heating Systems

Empire Heating Systems WCC65 Installation and owner's instructions

Wetekom

Wetekom 92 86 43 Original instructions

Desa

Desa SPC170-F owner's manual

Watlow

Watlow Watrod Electric Tubular Heaters Specifications

Haverland

Haverland ECO-DRY GPS Series Instruction & installation manual

Stelpro

Stelpro ASILVC2060 Series user guide
