Timago TGR-R KP-O 5021 User manual

INSTRUCTIONS FOR USE

Round shower chair, rotating seat, tool free

Product code: TGR-R KP-O 5021

1. Characteristics

Shower chair consists of aluminium frame, rotating seat made of

durable PVC, and legs with anti-sliding rubber tips. Owing to push

button height adjustment, the chair can be adjusted to the height of

the user. Additionally, the chair is equipped with Tool-Free (TF) system

facilitating the assembly.

The set includes:

•Seat – 1 pc

•Base tubes – 2 pcs

•Height adjustable legs – 4 pcs

•mounting screws (wing screws) – 5 pcs

Elements of the shower chair:

a. Seat

b. Base tubes

c. Height adjustment – locking pin

d. Anti-sliding tips

2. Application

The shower chair is ancillary equipment which helps the user to

perform hygienic activities. The chair is recommended to people with

reduced mobility which prevents or hinders the unassisted

performance of daily living activities. The chair can be used in the

shower, in the bath, in bathrooms and other humid rooms at home and

in hospitals.

3. Assembly and general recommendations for use

Step 1. Place seat upside down on a flat surface.

Step 2. Fix crossed base tubes with seat using four wing screws with

plastic and metal washers. Screw paler wing screw with washers in the

middle.

Step 3. Join base tubes with legs.

HEIGHT ADJUSTMENT

•To adjust the height of the shower chair, press metal pin, select

appropriate height of leg, and lock the position of the tubes

relative to each other with the use of pin. The legs are adjustable

in 2.5 cm increments.

Note! The pins must be set on the same level in each leg.

4. Technical data

Width 33 cm

Height 34.5-52 cm

Seat diameter 32 cm

Weight 1.95 kg

Maximum capacity 110 kg

5. Notes

Timago International Group does not bear responsibility of improper

use of the shower chair, failure to comply safety regulations and

misuse.

6. Maintenance

•Clean the shower chair regularly using only water, sponge and

mild detergents for plastic materials such as soap. Dry thoroughly.

•Do not use for cleaning: strong detergents, abrasive agents,

bleach, petrol or solvents (it may cause frame damage, visible

defects and in consequence - loss of warranty rights).

•Systematically check:

-tightening of wing screws

-condition of locking pins

-condition of tubes (if cracks)

It is recommended to check the rubber tips regularly. In case of

worn-out, replace the tips with the new ones.

7. Storage and transport conditions

Device should not be exposed to direct sunlight, water or moisture.

8. Warranty information

All products distributed by our company are covered by a warranty, the

terms of which are described in the warranty card available on our

website. Please contact the retailer from whom you purchased the

product. Please, keep in mind that for warranty purposes, the proof of

purchase (receipt or invoice) should be retained

9. Labels

Reference

number

Manufacturer

LOT number

Manufacture date

Serial number

Medical device

Note

Please read the

instruction

The manufacturer checked for compliance with

essential medical devices requirements.

Our complete line of products is available from our distributors.

Learn more at: www.timago.com. Thank you for choosing Timago!

Timago International Group

Spółka z o.o. i Spółka – Spółka komandytowa

ul. Karpacka 24/12

43-316 Bielsko-Biała, Polska

T.: +48 33 499 50 00

F.: +48 33 499 50 11

E.: info@timago.com

Rev. II, date 20.05.2021
