Thule Rapid System 1841 User manual
ISO 11154-E
Instructions
xx kg
xx Ibs 7 kg
15,4 Ibs
km/h
Mph
0
80 km/h
50 Mph
40 km/h
25 Mph
130 km/h
80 Mph
Thule Rapid System Kit 1841
141841
C.20160908
519-1841-01
B
Thule Rapid System Kit xxxx
Instructions
ThuleRapidSystemKitXXXX
Instructions
ThuleRapidSystem754
Instructions
Thule Rapid System 754
Instructions
.............
iA
B
Thule Rapid System 754
Instructions
A
ThuleRapidSystemKitXXXX
Instructions
ThuleRapidSystem754
Instructions
Thule Rapid System Kit xxxx
Instructions
B
www.thule.com
Max.
132 Ibs
Max.
60 kg
CITROËN DS4, 5-dr Hatchback, 11–
CITROËN DS4 Crossback, 5-dr Hatchback, 16–
2519-1841-01
1
X (scale) X (mm) X (inch)
CITROËN DS4, 5-dr Hatchback, 11– 38,5 1036 40 3/4
CITROËN DS4 Crossback, 5-dr Hatchback, 16– 38,5 1036 40 3/4
Y (scale) Y (mm) Y (inch)
CITROËN DS4, 5-dr Hatchback, 11– 34,5 996 39 1/4
CITROËN DS4 Crossback, 5-dr Hatchback, 16– 34,5 996 39 1/4
1197 x1 1191 x1
1190 x2
169 x1
32 x2
167 x1
XXX
XXX
XXX
X
Y
2
X/Y
Thule Rapid System 754
Instructions
A
x1 x1
ThuleRapidSystemKitXXXX
Instructions
ThuleRapidSystem754
Instructions
Thule Rapid System Kit xxxx
Instructions
B
3519-1841-01
2
1190 167 1190169
1191 32 119732
XXX
XXX
XXX
XXX
3
xxx
Thule Rapid System 754
Instructions
A
CITROËN DS4, 5-dr Hatchback, 11–
CITROËN DS4 Crossback, 5-dr Hatchback, 16–
519-1841-01
Thule Sweden AB, Box 69, 330 33 Hillerstorp, SWEDEN
Thule Inc., 42 Silvermine Road, Seymour, Connecticut 06483, USA www.thule.com
Phone: 800-238-2388
© Thule Group 2016. All rights reserved.
W Z
3
5
W/Z
Thule Rapid System 754
Instructions
A
W (mm) Z (mm) W (inch) Z (inch)
CITROËN DS4, 5-dr Hatchback, 11– 60 730 2 3/828 3/4
CITROËN DS4 Crossback, 5-dr Hatchback, 16– 60 730 2 3/828 3/4
CITROËN DS4 CITROËN DS4 Crossback
