Thule 1338 User manual

ISO 11154-E

Instructions

km/h

Mph

80 km/h

50 Mph

40 km/h

25 Mph

130 km/h

80 Mph

ThuleRapidSystemKitXXXX

Instructions

ThuleRapidSystem754

Instructions

Thule Rapid System Kit xxxx

Instructions

Security

Thule Rapid System Kit xxxx

Instructions

ThuleRapidSystemKit XXXX

Instructions

ThuleRapidSystem 754

Instructions

Thule Rapid System 754

Instructions

.............

Thule Rapid System 754

Instructions

xx kg

xx Ibs

7 kg

15,4 Ibs

Max.

30 kg

66 Ibs

Max.

40 kg

88 Ibs

BUICK Excelle,

4-dr Sedan, 03-11

CHEVROLET Lacetti,

4-dr Sedan, 03-11

CHEVROLET Nubira,

4-dr Sedan, 03-11

CHEVROLET Optra,

4-dr Sedan, 03-11

DAEWOO Lacetti,

4-dr Sedan, 03-11

DAEWOO Nubira,

4-dr Sedan, 03-11

HOLDEN Viva,

4-dr Sedan, 03-11

BUICK Excelle,

5-dr Hatchback, 04-11

CHEVROLET Lacetti,

5-dr Hatchback, 04-11

CHEVROLET Nubira,

5-dr Hatchback, 04-11

CHEVROLET Optra,

5-dr Hatchback, 04-11

DAEWOO Lacetti,

5-dr Hatchback, 04-11

DAEWOO Nubira,

5-dr Hatchback, 04-11

HOLDEN Viva,

5-dr Hatchback, 04-11

Thule Rapid System

Kit 1338

141338

C.20160330

519-1338-03

BUICK Excelle, 5-dr Hatchback, 04-11

BUICK Excelle, 4-dr Sedan, 03-11

CHEVROLET Lacetti, 5-dr Hatchback, 04-11

CHEVROLET Lacetti, 4-dr Sedan, 03-11

CHEVROLET Nubira, 5-dr Hatchback, 04-11

CHEVROLET Nubira, 4-dr Sedan, 03-11

CHEVROLET Optra, 5-dr Hatchback, 04-11

CHEVROLET Optra, 4-dr Sedan, 03-11

DAEWOO Lacetti, 5-dr Hatchback, 04-11

DAEWOO Lacetti, 4-dr Sedan, 03-11

DAEWOO Nubira, 5-dr Hatchback, 04-11

DAEWOO Nubira, 4-dr Sedan, 03-11

HOLDEN Viva, 5-dr Hatchback, 04-11

HOLDEN Viva, 4-dr Sedan, 03-11

X/Y

Thule Rapid System 754

Instructions

519-1338-03

X (scale) X (mm) X (inch)

BUICK Excelle 30 951 37 1/2

CHEVROLET Lacetti 30 951 37 1/2

CHEVROLET Nubira 30 951 37 1/2

CHEVROLET Optra 30 951 37 1/2

DAEWOO Lacetti 30 951 37 1/2

DAEWOO Nubira 30 951 37 1/2

HOLDEN Viva 30 951 37 1/2

Y (scale) Y (mm) Y (inch)

BUICK Excelle, 5-dr Hatchback 27 921 36 1/

BUICK Excelle, 4-dr Sedan 28 931 36 5/8

CHEVROLET Lacetti, 5-dr Hatchback 27 921 36 1/

CHEVROLET Lacetti, 4-dr Sedan 28 931 36 5/8

CHEVROLET Nubira, 5-dr Hatchback 27 921 36 1/

CHEVROLET Nubira, 4-dr Sedan 28 931 36 5/8

CHEVROLET Optra, 5-dr Hatchback 27 921 36 1/

CHEVROLET Optra, 4-dr Sedan 28 931 36 5/8

DAEWOO Lacetti, 5-dr Hatchback 27 921 36 1/

DAEWOO Lacetti, 4-dr Sedan 28 931 36 5/8

DAEWOO Nubira, 5-dr Hatchback 27 921 36 1/

DAEWOO Nubira, 4-dr Sedan 28 931 36 5/8

HOLDEN Viva, 5-dr Hatchback 27 921 36 1/

HOLDEN Viva, 4-dr Sedan 28 931 36 5/8

639 x1

615 x1

638 x1

137 x4

XXX

ThuleRapidSystemKitXXXX

Instructions

ThuleRapidSystem754

Instructions

Thule Rapid System Kit xxxx

Instructions

614 x1

XXX

xxx

Thule Rapid System 754

Instructions

519-1338-03

615 137 639137

614 137 638137

BUICK Excelle

CHEVROLET Lacetti

CHEVROLET Nubira

CHEVROLET Optra

DAEWOO Lacetti

DAEWOO Nubira

HOLDEN Viva

Thule Sweden AB, Box 69, 330 33 Hillerstorp, SWEDEN

Thule Inc., 42 Silvermine Road, Seymour, Connecticut 06483, USA www.thule.com

info@thule.com

Phone: 800-238-2388

W/Z

Thule Rapid System 754

Instructions

519-1338-03

W (mm) Z (mm) W (inch) Z (inch)

BUICK Excelle 250 650 9 7

/825 5/8

CHEVROLET Lacetti 250 650 9 7

/825 5/8

CHEVROLET Nubira 250 650 9 7

/825 5/8

CHEVROLET Optra 250 650 9 7

/825 5/8

DAEWOO Lacetti 250 650 9 7

/825 5/8

DAEWOO Nubira 250 650 9 7

/825 5/8

HOLDEN Viva 250 650 9 7

/825 5/8

W Z
