Thule 126 Guide
Thule System Kit 126
6,5 Kg
6,5 Kg
4,5 Kg
350•4DF/501-0126-03
Screw the load carrier into
position alternating between
the feet, and maintaining
constant pressure on the
bracket.
ACURA Legend 4-dr, 91– (US)
HONDA Legend 4-dr, 91–
ACURA Legend Coupé 2-dr, 91– (US)
HONDA Legend Coupé 2-dr, 91–
700 mm / 27
5
/
8
inch
18
18
152 152
18 18
152 152
710 mm / 28 inch
210 mm
8
3
/
8
inch
Screw the load carrier into
position alternating between
the feet, and maintaining
constant pressure on the
bracket.
MAX
75 K
g
LOAD
MAX
75 K
g
LOAD
After the fitting
During the fitting.
Front Rear
970 mm / 38 1/4 inch1014 mm / 43 7/8 inch
mm/inch
After the fitting
During the fitting.
Front Rear
965 mm / 38 inch970 mm / 38 1/4 inch
mm/inch
