Thermo Scientific 8920 User manual

Thermo Scientific

Revco®ExF -86C ULT Upright Freezer

Operating Manual 7048920 Rev. 2

Visit us online to register your warranty

www.thermoscientific.com/labwarranty

Thermo Scientific

Preface

Revco ExF i

Part

Number Description Quantity

122005 Key 2 (4 DD)

380520 Neoprene Cap 2

510016 ¼-20 x 5½” Bolt 2

195763 Retaining Clip 1

370563 Remote Alarm

Connector 1

Packing List

Models Covered

MANUAL NUMBER 7048920

2 31013/FR-2673 6/18/14 RoHS compliant washer on oil separator (expl base dwg, refrig schematics) ccs

1 30948 4/25/14 Updated 902 elec schematic to show correct compressors ccs

0 30814/FR-2603 3/24/14 Release 10 - hinges and mullion (pg 7-6, 7-7) ccs

REV ECR/ECN DATE DESCRIPTION By

Important installer and user information:

A redundant temperature sensing device has been included in this ULT freezer.

This device is a type “T” thermocouple. For convenient access, the thermocou-

ple (Figure 1-3) terminates in an interconnect jack (Figure 1-5) behind the base

front cover. (May be located differently in chests. See Section 1.) It is strongly

recommended that this thermocouple be attached to a redundant 24 hour 7

day monitoring system with alarm capabilities. Connecting the sensor to a

monitoring and alarm system separate from the freezer provides the utmost in

product safety, should the integral system fail. s

* DD = Double Doors

Catalog

Number Model Capacity

(cu ft)

Voltage/

ExF24086V 8920 13 230/50

ExF24086D 8921 13 230/60

ExF24086A 8922 13 120/60

ExF32086A 8923 17 120/60

ExF32086D 8924 17 230/60

ExF32086V 8925 17 230/50

ExF40086V 8926 23 230/50

ExF40086D 8927 23 230/60

ExF40086A 8928 23 120/60

ExF60086D 8929 28 230/60

ExF60086V 8930 28 230/50

ExF21686D 968 DD 13 230/60

ExF28886V 969 DD 17 230/60

ExF36086V 970 DD 23 230/60

Catalog

Number Model Capacity

(cu ft)

Voltage/

ExF24086SSV 6420 13 230/50

ExF24086SSD 6421 13 230/60

ExF24086SSA 6422 13 120/60

ExF32086SSA 6423 17 120/60

ExF32086SSD 6424 17 230/60

ExF32086SSV 6425 17 230/50

ExF40086SSV 6426 23 230/50

ExF40086SSD 6427 23 230/60

ExF40086SSA 6428 23 120/60

ExF60086SSD 6429 28 230/60

ExF60086SSV 6430 28 230/50

ExF21686SSD 5968DD 13 230/60

ExF28886SSD 5969DD 17 230/60

ExF36086SSD 5970DD 23 230/60

Thermo Scientificii Revco ExF

PrefacePreface

Important Read this instruction manual. Failure to read, understand and follow the instructions in this manual

may result in damage to the unit, injury to operating personnel, and poor equipment performance. s

Caution All internal adjustments and maintenance must be performed by qualified service personnel. s

Material in this manual is for information purposes only. The contents and the product it describes are subject

to change without notice. Thermo Fisher Scientific makes no representations or warranties with respect to this

manual. In no event shall Thermo be held liable for any damages, direct or incidental, arising out of or related to

the use of this manual.

The -86C Freezers (see page i for specific list of models) described in this manual are high performance units

which can be used for research and in situations that directly support medical applications. When these products

are used to support a medical application, it is an accessory to a medical device and is therefore considered as a

medical device in its own right by the regulatory body (e.g. FDA).

This product is intended for use:

• As cold storage in research use.

• As a medical device for diagnostic use (storage of samples not intended to be re-introduced to human body).

Registration: This medical application is considered a Class I medical device by the FDA. This product is

classified as product code – JRM, regulation number 862.2050 and is considered a Class 1 device, 510(K)

exempt.

Contains Parts and Assemblies

Susceptible to Damage by

Electrostatic Discharge (ESD)

CAUTION

Thermo Scientific Revco ExF iii

Preface

Important operating and/or maintenance instructions. Read the accompanying text carefully.

Potential electrical hazards. Only qualified persons should perform procedures associated with this

symbol.

Extreme temperature hazards, hot or cold. Use special handling equipment or wear special, protective

clothing.

Hot surface(s) present which may cause burns to unprotected skin, or to materials which may be

damaged by elevated temperatures.

Marking of electrical and electronic equipment, which applies to electrical and electronic equipment

falling under the Directive 2002/96/EC (WEEE) and the equipment that has been put on the market

after 13 August 2005.

This product is required to comply with the European Union’s Waste Electrical & Electronic

Equipment (WEEE) Directive 2002/96/EC. It is marked with the WEEE symbol. Thermo Fisher

Scientific has contracted with one or more recycling/disposal companies in each EU Member State

European Country, and this product should be disposed of or recycled through them. Further

information on Thermo’s compliance with this directive, the recyclers in your country and

information on Thermo Scientific products will be available at www.thermofisher.com.

4Always use the proper protective equipment (clothing, gloves, goggles, etc.)

4Always dissipate extreme cold or heat and wear protective clothing.

4Always follow good hygiene practices.

4Each individual is responsible for his or her own safety.

Thermo Scientificiv Revco ExF

Preface

Do You Need Information or Assistance on

Thermo Scientific Products?

If you do, please contact us 8:00 a.m. to 6:00 p.m. (Eastern Time) at:

1-740-373-4763 Direct

1-800-438-4851 Toll Free, U.S. and Canada

1-877-213-8051 FAX

http://www.thermoscientific.com Internet Worldwide Web Home Page

service.led.marietta@thermofisher.com Tech Support Email Address

Certified Service Web Page

Thermo Fisher Scientific

401 Millcreek Road, Box 649

Marietta, OH 45750

Our staff can provide information on pricing and give you quotations. We can

take your order and provide delivery information on major equipment items or make

arrangements to have your local sales representative contact you. Our products are listed on the

Internet and we can be contacted through our Internet home page.

Our staff can supply technical information about proper setup, operation or

troubleshooting of your equipment. We can fill your needs for spare or replacement parts or

provide you with on-site service. We can also provide you with a quotation on our Extended

Warranty for your Thermo Scientific products.

Whatever Thermo Scientific products you need or use, we will be happy to discuss your

applications. If you are experiencing technical problems, working together, we will help you

locate the problem and, chances are, correct it yourself...over the telephone without a service

call.

When more extensive service is necessary, we will assist you with direct factory trained

technicians or a qualified service organization for on-the-spot repair. If your service need is

covered by the warranty, we will arrange for the unit to be repaired at our expense and to your

satisfaction.

Regardless of your needs, our professional telephone technicians are available to assist you

Monday through Friday from 8:00 a.m. to 6:00 p.m. Eastern Time. Please contact us by

telephone or fax. If you wish to write, our mailing address is:

International customers, please contact your local Thermo Scientific distributor.

Sales Support

Service Support

www.unitylabservices.com

Revco ExF vThermo Scientific

Table of Contents

Installation and Start-up . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-1

Control Panel Keys, Displays, Indicators . . . . . . . . . . . . . . . . . . . . . .1-4

Operation of the Keypad . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-5

Install Freezer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-5

Choose Location . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-5

Install Wall Bumpers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-6

Remote Alarm Contacts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-6

Install Shelves . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-6

Connect Unit to Electrical Power . . . . . . . . . . . . . . . . . . . . . . . . . .1-7

Attach Power Cord . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-7

Freezer Start-Up . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-8

Set Operating Temperature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-8

Set Low Temperature Alarm . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-9

Set High Temperature Alarm . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-9

Run Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-10

Calibrate . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-1

Calibrate Control Probe . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-1

Temperature Stabilization Periods . . . . . . . . . . . . . . . . . . . . . . . . . .2-1

Alarms . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-1

Probe Failure Alarm . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-2

High Stage System Failure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-2

Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-1

Clean Air Filter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-1

Clean Condenser . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-1

Clean Water-cooled Condenser . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-2

Defrost Chamber . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-3

Prepare Unit for Storage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-3

Clean Door Gasket . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-3

Vacuum Relief Port . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-4

Replace Battery(s) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-5

Check Battery(s) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-5

PREVENTIVE MAINTENANCE . . . . . . . . . . . . . . . . . . . . . . . . .4-6

Section 1

Section 2

Section 3

Section 4

vi Revco ExF Thermo Scientific

Factory Installed Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-1

BUS - Back Up System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-1

Install Vent Stack, Solenoid and Injection Assembly . . . . . . . . . . . .5-1

Install Temperature Probe . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-3

Connect Probe/Solenoid Harness . . . . . . . . . . . . . . . . . . . . . . . . . .5-4

BUS Control Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-5

Set Optional BUS Set Point . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-6

Configure Optional BUS (Back-Up System) . . . . . . . . . . . . . . . . . .5-6

Test BUS Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-7

Clean Vent Stack . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-7

Disconnect Fitting Asm. and Transfer Hose . . . . . . . . . . . . . . . . . . .5-7

Chart Recorder . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-7

Recorder Calibration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-8

Change Recorder Temperature Range . . . . . . . . . . . . . . . . . . . . . . .5-8

Installing the Chart Paper . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-8

Water-cooled Condenser . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-9

Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-1

Single Door Units . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-1

Double Door Units . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-3

Spare Parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7 - 1

Refrigeration Schematics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8 - 1

Electrical Schematics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9 - 1

Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10 - 1

Handling Liquid Nitrogen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .A - 1

Handling Liquid CO2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .B - 1

First Aid . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .C - 1

Table of Contents

Section 5

Section 6

Section 8

Section 7

Section 9

Section 10

Appendix

Revco ExF 1-1Thermo Scientific

Section 1 Installation and Start-up

• Control panel - keypad, displays and indicators

• BUS (Optional Back Up System) control panel

• Optional temperature recorder or datalogger

Optional Back Up

System Controls

Temperature

Recorder

(Optional)

Control Panel

Figure 1-1. Freezer Front View Components

1-2 Revco ExF Thermo Scientific

Section 1

Installation and Start-Up

Optional Back-up

System Connections

Power Switch

(mains

disconnect)

Power Inlet

Remote Alarm

Contacts

Wall Bumper

(pre-tapped holes)

Figure 1-2. Freezer Rear View Components

Shelf

Bracket

Sealant

(Caution: This is a critical seal.

Seal must be maintained.)

Optional - Recorder Probe/Datalogger Probe

Control RTD/Redundant Type T

Thermocouple Probe

Optional Miscellaneous Accessories Probe

Figure 1-3. Chamber Probe(s)

• Remote alarm contacts

• Power inlet for power cord connection

• Optional BUS connections for probe and solenoid

• Power switch (mains disconnect)

Revco ExF 1-3Thermo Scientific

Section 1

Installation and Start-Up

• Vacuum relief port - pressure equalization port

• Probe cover - houses control, optional recorder, datalogger, or

miscellaneous accessory probes

• Battery mounting bracket(s)

• Battery power switch (freezer and BUS)

• Freezer battery

• Optional BUS battery

• Freezer filter location

Vacuum

Relief Port

Chamber

Probe Cover

Figure 1-4. Vacuum Relief and Probe Cover Location

Battery power

switch To

remove filter

Thermocouple

interconnect jack

Battery mounting

bracket

Freezer battery

and optional BUS battery

Figure 1-5. Battery(s) location and switch

This manual suits for next models

Table of contents

Other Thermo Scientific Laboratory Equipment manuals

Thermo Scientific

Thermo Scientific Jewett JBB1204 User manual

Thermo Scientific

Thermo Scientific Dionex ICS-1100 User manual

Thermo Scientific

Thermo Scientific Cryostat Microm Cryo-Star HM 560 User manual

Thermo Scientific

Thermo Scientific NESLAB EX Series General instructions

Thermo Scientific

Thermo Scientific Haematocrit-Rotor 7500 3473 User manual

Thermo Scientific

Thermo Scientific Orion 2001FC User manual

Thermo Scientific

Thermo Scientific FIBERLite F15-8x50c User manual

Thermo Scientific

Thermo Scientific Dionex UltiMate 3000 Series User manual

Thermo Scientific

Thermo Scientific GenPure Standard User manual

Thermo Scientific

Thermo Scientific Wellwash Versa User manual

Thermo Scientific

Thermo Scientific iCAP 6000 Series User manual

Thermo Scientific

Thermo Scientific Heraeus Fresco 21 User manual

Thermo Scientific

Thermo Scientific VARIOMAG MINI 07 User manual

Thermo Scientific

Thermo Scientific thermoscientific Vanquish UHPLC System User manual

Thermo Scientific

Thermo Scientific Shake n Stack 6240 Operating instructions

Thermo Scientific

Thermo Scientific Multidrop Combi+ User manual

Thermo Scientific

Thermo Scientific Dionex AutoTrace 280 User manual

Thermo Scientific

Thermo Scientific RIIDEye X-G User manual

Thermo Scientific

Thermo Scientific TriPlus RSH User manual

Thermo Scientific

Thermo Scientific iCAP 7000 Series User manual

Thermo Scientific

Thermo Scientific Sorvall MTX 150 User manual

Thermo Scientific

Thermo Scientific Nicolet Summit User manual

Thermo Scientific

Thermo Scientific KingFisher Presto User manual

Thermo Scientific

Thermo Scientific Cryo 740 Series User manual

Popular Laboratory Equipment manuals by other brands

Qiagen

Qiagen DML 3000 user manual

Queensgate

Queensgate NANOSCAN OP400 Quick start instructions

Conviron

Conviron GEN1000-GE Operator's manual

Parr Instrument

Parr Instrument 4560 Operating instructions manual

IKA

IKA IC control operating instructions

Integra

Integra DOSE IT operating instructions

Agilent Technologies

Agilent Technologies 5800 ICP-OES user guide

Endress+Hauser

Endress+Hauser Cleanfit CPA875 operating instructions

NI PXI-5422 CALIBRATION PROCEDURE

Collomix

Collomix Aqix operating instructions

SPEX SamplePrep

SPEX SamplePrep 6875 Freezer/Mill Series operating manual

Ocean Insight

Ocean Insight FLAME-NIR+ Installation and operation manual

Parker

Parker ALIGN-MG-NA Installation, operation and maintenance manual

BD 644787 user guide

DENTAURUM

DENTAURUM Compact Megaplus Instructions for use

Biuged Laboratory Instruments

Biuged Laboratory Instruments BGD 626 instruction manual

VWR

VWR SAS Super IAQ instruction manual

illumina

illumina MiSeqDx reference guide
