Tennant M17 Series Training manual

IB 9015109 (10- 2016) 1

INSTRUCTION BULLETIN

No. 9015109

Machine: M17

Published: 10- 2016

Rev. 00

NOTE: DO NOT DISCARD the Parts List from the Instruction Bulletin. Place the

Parts List in the appropriate place in the machine manual for future

reference. Retaining the Parts List will make it easier to reorder

individual parts and will save the cost of ordering an entire kit.

NOTE: Numbers in parenthesis ( ) are reference numbers for parts listed in Bill of Materials.

Installation instructions for kit number 9015047

SYNOPSIS:

This kit contains the parts needed to replace the sweeping circuit board on M17 sweeper- scrubbers.

Please follow step-by-step instructions.

SPECIAL TOOLS / CONSIDERATIONS: NONE

(Estimated time to complete: 1 hour)

PROTECT THE ENVIRONMENT

Please dispose of packaging materials, used machine components

such as batteries and fluids in an environmentally safe way according

to local waste disposal regulations.

Always remember to recycle.

PREPARATION:

FOR SAFETY: Before leaving or servicing

machine, stop on level surface, turn off

machine, set parking brake, and remove key.

1. Disconnect the battery cable from the

machine.

WARNING: Always disconnect battery

cables from machine before working on

electrical components.

IB 9015109 (10- 2016)2

INSTALLATION:

FRONT

Remove and set

SEMS M8 hex screw

and left cover aside

Sweeping

electrical box

location

FIG. 1

1. Remove the left cover from the machine to

access the sweeping electrical box. Set the

cover and the SEMS M8 hex screw aside.

(Fig. 1)

NOTE:To avoid damaging electronic

components, the static ground strap (3) must be

worn at all times when handling / installing the

new sweeping circuit board (1) onto the machine.

Attach the other end of the static ground strap to

the machine chassis.

IB 9015109 (10- 2016) 3

Support plate / side

sweep circuit board

Set SEMS

M6 hex

screw aside

Set M6 hex nut /

flat washer

aside

Set M4 pan

screws (Qty. 2)/

nylon washers

(Qty. 2) aside

Replace sweep

circuit board with

new sweep circuit

board (1)

Electrical

enclosure

If necessary,

replacestandoffs

with new

standoffs (2)

Loosen SEMS

M6 hex screws

(Qty. 2)

NOTE:To avoid damaging electronic components, static ground strap (3) must be worn at all times

when handling / installing new sweep circuit board (1) onto machine. Attach other end of static

ground strap to machine chassis.

FIG. 2

2. Remove the SEMS M6 hex screw, M6 hex

nut, and flat washer securing the support

plate / side sweep circuit board to the

electrical enclosure. Set removed hardware

aside. (Fig. 2)

3. Carefully remove the support plate / side

sweep circuit board from the electrical

enclosure and place support plate / side

sweep circuit board out of the way. Do Not

break electrical connections when removing

the support plate / side sweep circuit board

from the electrical enclosure. (Fig. 2)

4. Disconnect all harness connections from the

sweep circuit board. (Fig. 2)

5. Remove both M4 pan screws and nylon

washers securing the sweep circuit board to

the electrical enclosure. Set removed

hardware aside. (Fig. 2)

6. Remove the sweep circuit board from the

electrical enclosure. Discard the sweep circuit

board. (Fig. 2)

7. If necessary, replace the broken standoffs in

the electrical enclosure with new standoffs (2).

Loosen both SEMS M6 hex screws securing

the electrical enclosure to the machine to

access the standoffs. (Fig. 2)

IB 9015109 (10- 2016)4

8. If the electrical enclosure was loosened to

replace standoffs, reposition the electrical

enclosure onto the SEMS M6 hex screws and

tighten the SEMS M6 hex screws to secure

the electrical enclosure to the machine.

(Fig. 2)

9. Connect the main wire harness connectors

to the sweep circuit board (1)

10. Place the sweep circuit board (1) onto the

plastic standoffs (2) and use the two M4 pan

screws and nylon washers to secure the

sweep circuit board to the electrical enclosure.

To prevent damaging the sweep circuit board,

Do Not over tighten the M4 pan screws.

(Fig. 2)

11. Reinstall the support plate / side sweep circuit

board onto the electrical enclosure. (Fig. 2)

12. Reinstall the left cover onto the machine.

(Fig. 1)

13. Reconnect the battery cable to the machine.

14. Start and test the machine. Place the machine

into the sweep mode and operate the

machine to ensure the sweeping system is

functional.

Bill Of Materials For Circuit Board Kit, Swp, Main, Afmkt [M17] - 9015047

Ref.

Tennant

Part No. Description Qty.

11218382 )Circuit Board Assy [M17, Main Sweep] 1

2 1210399 Stand- Off, Circuit Board [0.25”] 5

327964 Strap, Ground, Static, Disposable 1

TENNANT COMPANY

P. O. Box 1452

Minneapolis, MN 55440-1452

Other manuals for M17 Series

Other Tennant Floor Machine manuals
