User Manual
naviPlay Bluetooth Stereo eadset, NS .P10
naviPlay Bluetooth Stereo Adapter for iPod, NIA.S10-U
Read these instructions before operating.
Follow all instructions.
eed all warnings.
Keep these instructions for future reference.
Bluetooth®Stereo Headset Kit for iPod™
Handsfree Headset +Adapter for iPod
US GB
Contents
2
Important Safety Information
Lithium Battery Safety Precautions
Requirements
Quick Start
naviPlay Stereo eadset Contents
Stereo eadset at a Glance
Setting Up naviPlay
Using naviPlay
naviPlay eadset Controls
Status Indicator Chart
Using the naviPlay Adapter Flip Stand
Using the naviPlay Headset with Other
Bluetooth Devi es
Using the naviPlay eadset with
Bluetooth-Enabled Mobile Phones
Using the naviPlay Adapter with Other
Bluetooth Devices
Using the naviPlay Remote with Other
Bluetooth-Enabled Devices
3
4
6
7
8
9
10
13
13
14
15
16
16
20
21
Updating naviPlay Firmware
Setting Up the naviPlay Device for
Firmware Update
Updating naviPlay Firmware from a
Bluetooth-Enabled PC
Updating naviPlay Firmware from a
Bluetooth-Enabled Macintosh
Firmware Update Tips (Windows + Mac)
Troubleshooting
About the Te hnology Behind the
naviPlay Stereo Headset
Improving Wireless Effe tiveness
Te hni al Spe ifi ations
Model NS .P10
Model NIA.S10-U
Regulatory Information
22
22
22
22
23
24
25
26
27
27
28
29
Contents
Read these instructions before operating.
Follow all instructions.
eed all warnings.
Keep these instructions for future reference
Caution: Risk of electric shock. Do not tamper with, modify, open or disassemble.
Do not use near water or in wet environment.
Do not immerse in water or any liquid.
Clean only with dry cloth.
Use only as directed in this user manual or as instructed by manufacturer.
Do not install or use near any heat sources such as radiators, heat registers, stoves, or other
apparatus (including amplifiers) that produce heat.
Refer all servicing to qualified service personnel.
3
Important Safety Information
I portant Safety Infor ation
Caring for the Environment by Recycling
When you see this symbol on a product, do not dispose the product with household waste.
Recycling Mobile Phones and Accessories
Do not dispose of mobile phones or electrical accessories, such as chargers or headsets, with your
household waste. In some countries or regions, collection systems are set up to handle electrical and
electronic waste items. Contact your regional authorities for more details.
Lithium Battery Safety Precautions
For the safe use of lithium-polymer and lithium-ion batteries, always follow the instructions
provided below. Improper handling of lithium batteries may result in injury or damage from
electrolyte leakage, heating, ignition, or explosion.
Danger:
•Never use the batteries with anything other than specifically designed equipment.
•Always use the battery charging method provided with the device.
•Never impact, pierce, or crush the battery.
•andle a damaged or leaking battery with extreme care. If you come in contact with the
electrolyte, wash the exposed area with soap and water. If it contacts the eye, flush the eye
with water for 15 minutes and seek medical attention.
•When discarding a battery, contact your local waste disposal provider regarding local
restrictions on the disposal or recycling of batteries.
•Never disassemble or modify the battery. The battery contains a circuit designed to enhance
safety. Damaging this circuit may cause overheating, fire, or bursting.
•Never expose or charge a battery under high-temperature conditions, such as near a fire or in
the direct sunlight. If the ambient temperature is too high, the protection circuit may be
actuated, preventing further charging, or damaged.
•Never short-circuit the battery by connecting the positive and negative terminals with a metal
material. Do not store or carry the battery where it could come into contact with metal
objects such as a key chain or necklace.
Important Safety Information
4
•Never allow the battery to get wet or be immersed in water.
•Do not place the battery in a microwave oven or high-pressure container.
•Stop charging if the battery is not charged after the prescribed charge time.
•If leakage of the electrolyte occurs, or if there is an offensive odor, immediately keep the
battery away from any source if fire or spark.
If, during use, charging, or storage, you become aware of any abnormal phenomena, such as
odor, discoloration, or deformation, disconnect the device or from charger and stop using
immediately.
5
Important Safety Information
Requirements
6
The naviPlay Bluetooth Stereo eadset requires the following types of devices for proper function:
For Stereo Music Streaming: a Bluetooth-enabled stereo music source supporting A2DP profile
(Advance Audio Distribution Protocol) – Example: TEN naviPlay Bluetooth Adapter for iPod
For Handsfree/Headset Function: a Bluetooth-enabled mobile phone supporting andsfree or
eadset profiles
For Remote Control: a Bluetooth-enabled stereo music source supporting AVRCP profile (Audio
Video Remote Control Protocol) – Example: TEN naviPlay Bluetooth Adapter for iPod
For updating the software on the naviPlay Bluetooth Stereo eadset, see “Updating naviPlay
Firmware” for additional requirements
The naviPlay Bluetooth Adapter for iPod requires the following devices for proper function:
For Stereo Music Streaming: a Bluetooth-enabled stereo music receiver (e.g. headphones,
audio system) supporting A2DP profile (Advance Audio Distribution Profile) – Example: TEN
naviPlay Bluetooth Stereo eadset or TEN naviPlay Bluetooth Stereo Remote
For Remote Control: a Bluetooth-enabled device supporting the AVRCP profile (Audio Video
Remote Control Protocol)
Apple iPod with Dock Connector: iPod w/Video, iPod nano, U2 iPod, iPod w/Color Display, iPod
photo, iPod mini, iPod w/Dock Connector
Require ents
7
Quick Start
Congratulations and thank you for purchasing the naviPlay Bluetooth Stereo eadset, designed
specifically for enjoying your music free from any wire or cable, and free from worry of missing a
phone call. Using wireless Bluetooth technology, the naviPlay Stereo eadset and a Bluetooth-
enabled music source work together to provide digital audio streaming, giving you untethered use
and control of your music.
The naviPlay Stereo eadset is designed for active listeners, freeing you from the cumbersome
cable connection between your iPod and headphones. The naviPlay Stereo eadset can also be
used as a wireless headset with your Bluetooth-enabled mobile phone.* Effortlessly switch
between listening to music to taking calls without having to remove your headphones or
scramble for your phone. Use it on a treadmill at the gym, take it with you cycling…anytime
being tied to your iPod would limit your range of motion or expose the iPod to risk. The
possibilities are limitless.
The great thing about naviPlay is that it's ready to use right out of the box. There's no software
to load, nothing to configure to enjoy your music wirelessly. Just charge the adapter and headset
and travel with your tunes.
*Setup required to use with mobile phone. Does not work with all Bluetooth-enabled phones.
Quick Start
naviPlay Stereo eadset Contents
Make sure you have received the following items:
Quick Start
8
naviPlay eadset User Manualeadset USB Charging Cable
naviPlay iPod Adapter Clips for iPod Models
naviPlay Stereo eadset at a Glance
Charging Socket
Charging Light
Power;
Play/Pause
Call Button
Status Light
Microphone
9
Quick Start
Battery Pack
iPod Dock Connector
Flip Stand
Adapter Base
Status Light
Charge Light
Clip Attachment
Power
naviPlay Adapter
naviPlay Headset
Setting up naviPlay
To set up and use your naviPlay Stereo eadset, you first need to charge the Adapter and the
eadset for at least one hour.
Step 1: Charge the naviPlay Adapter and Headset
Using the iPod Dock Connector to USB or Firewire cable (included with iPod), connect the
naviPlay Adapter to your computer or iPod Power Adapter (optional) to charge. Use the included
USB Charging cable to charge the naviPlay eadset by connecting to your computer or USB
power adapter (optional). You can also charge the iPod at the same time by docking your iPod in
the naviPlay Adapter, however, note that charging time may increase significantly depending on
the iPod battery level. See "Step 2: Attach iPod to naviPlay Adapter.
Without iPod docked, the internal battery of the naviPlay Adapter will be about 80 percent
charged after 2 hours, and fully charged after about 4 hours. The naviPlay eadset internal
battery will be about 80 percent charged after 2 hours, and fully charged after about 4 hours.
While charging, the charge light will remain constant red. When the eadset is fully charged, its
light will turn green. When the iPod Adapter is fully charged, its light will turn off.
The status light will blink red when the naviPlay iPod Adapter or eadset needs to be recharged.
Quick Start
10
naviPlay Adapter
naviPlay
eadset
Computer
iPod USB Cable
or FireWire
(included w/iPod)
USB Charging
Cable
Note: Firewire
charging will be
significantly faster
than USB charging.
Charging the naviPlay
Adapter alone will be
faster than with iPod
docked in the Adapter.
