Teltonika GH3000 User manual

Quick-Start user manual

http://www.teltonika.eu

version 1.00

1. Preface

2. General information

3. Getting started

4. Getting to know the device

5. Quick configuration

6. Device monitoring

7. For your safety

7.9 Use only the batteries supplied by the manufacturer

7.10 Use the battery safely

7.11 Safely disconnect the device

8. Installing software

9. Connecting to a PC

10. Alarm function

1.1 Introduction

1.2 Protection of copyrights

1.3 Contacts

2.1. Package contents

2.2. Defaults

3.1 Insert SIM card, battery and neck strap

3.2 Charging the battery

4.1 Turning device on

4.2 Turning device off

5.1 Change configuration password

5.2 Change time and time zone

5.3 Change periodical data logging

5.4 Change Alarm settings

5.5 Change keyboard settings

5.6 Change Man-down settings

5.7 Changeparking settings

5.8 Change GPRS settings

5.9 Battery notification

5.10 Restore to factory default

6.1 Review device location on the map

7.1 Switch on safely

7.2 Safe traffic is the most important

7.3 Disturbances

7.4 Switch off in hospitals

7.5 Switch off in the means of transport

7.6 Switch off when fueling

7.7 Switch off when being in the vicinity of places of explosions

7.8 Prepare your computer

Quick-Start user manual version 1.00

Table of contents

10.1 Alarm function activation

10.2 Alarm configuration

11. Call function

11.1 Call function configuration

11.2 Call function activation

11.3 Answer incoming call

12. Modem emulation function

12.1 Modem emulation function configuration

12.2 Modem emulation function activation

13. Geofence function

Geofence function configuration

14. Configuration security

15. Man-down function

16. Authorized incoming call

16.1 Authorized call number list configuration

17. Authorized SMS number list

17.1 Authorized SMS number list configuration

18. SMS tracking

18.1 Function activation

19. A-GPS function

19.1 A-GPS function configuration

20. Low battery level notification messages

20.1 Function configuration

21. SIM PIN code

22. Sound indication

Sound indication configuration

23. Vibration

Vibration configuration

24. Minute minder

25. List of supported maps

26. Parking function

Parking configuration

Parking activation/deactivation

27. Autoanswer function

Auto answer configuration

28. Silent call function

call configuration

29. Special SMS requests

13.1

15.1 Man-down function settings

22.1

23.1

26.1

26.2

27.1

28.1 Silent

Quick-Start user manual version 1.00

30. NMEA function

31. Indicating the status

32. Device characteristics

33. Maintance and repair

30.1 NMEA function configuration

30.2. NMEA function activation/deactivation

32.1 Specifications of the device

32.2. Battery life time

32.3. Electronic specification

Quick-Start user manual version 1.00

Product introduction

Quick start guide

This chapter introduce the

device and helps to start it use

quickly. Also you will find out

how to configure device using

SMS messages.

Quick-Start user manual version 1.00

GH3000 is a device with built-in functions characteristic of a

mobile phone and an integrated A-GPS receiver. This device is

intended for the surveillance and protection of people, cargo

and objects. The A-GPS receiver may define the current location

of the device and sends this data to a person in charge or the

operation center.

All rights are owned by the author. You may not copy, compile or

transfer the present information to third parties or distribute it

without a prior written consent by UAB Teltonika.

Other products and company names mentioned in this Manual

may be trademarks or names of products of such companies.

In case you have problems with the use of the product beyond

your possibilities to solve it, please address them to the

Technical Assistance Center (TAC) by e-Mail [email protected]

or contact your local seller. We would be pleased to be of any

assistance to you.

1. Preface

1.1 Introduction

1.2 Protection of copyrights

1.3 Contacts

Welcome!

Thank you for purchasing our device!

We hope it will satisfy your expectations and you will enjoy its

particular features.

Please, find several minutes to read this document before

beginning to work with GH3000.

Notice!

Teltonika recommends to read User Manual carefully. Teltonika does not take any

responsibility for problems that occur due to an unpropriate usage of a device, incorrect

configuration or usage of software that was issued by a third party.

Teltonika reserves a right to modify the functionality of the device without any prior notice.

Quick-Start user manual version 1.00

2. General information

1 x Handheld A-GPS/GSM Tracker GH3000

1 x Li-Ion 1050mAh battery 3.7V

1 x USB – micro USB cable

1 x 230V to 5V USB charger

1 x SETUP CD with User's Manual and software

1 x Printed User's Quick-Start Manual

1 x Mini screw driver

1 x Neck strap

Notice!

The manufacturer's set does not include any SIM card which is necessary to connect to the GSM

network. A SIM card can be acquired from your local supplier of GSM services.

If any part is missing in the set, please contact the

r e p r e s e n t a t i v e o f t h e m a n u f a c t u r e r o r d e a l e r

(www.teltonika.eu).

The device automatically logging its position into the memory

and has other default configuration.

Periodical logging interval - every 600 sec. (10 min.)

Alarm duration time - 300 sec. (5 min.)

Alarm SMS sending interval - every 60 sec. (1 min)

Track logging Interval then Alarm is active - 5 sec.

SMS tracking Interval - every 600 sec. (10min)

Time in the SMS messages - GMT (+0:00)

Ringing melody - Pink Pantera

Low battery alarm messages - then 30%

2.2. Defaults

2.1. Package contents

Quick-Start user manual version 1.00

All SIM cards must be kept in a save place. You may request your

SIM card supplier to provide SIM cards and information about the

use of SIM card-related services. The supplier may be a service

supplier, a network operator or another seller. The SIM card must

be inserted in the way as set below.

3.1 Insert SIM card, battery and neck strap

Notice!

Before removing the cover, switch off the device and disconnect it from the charger or PC.

The device must be always kept and used with a cover and the screw screwed tightly.

3. Getting started

If an unsuitable SIM card has been inserted or the device fails to

detect it, the device will reload automatically and tries to start

the connection anew (if SIM card is not inserted the device will

reloads three times). If the reconnection fails, the device will

show it by its indicator.If the card has been inserted later, the

device must be switched off and switched on again or has to be

reloaded.

Quick-Start user manual version 1.00

Notice!

Only approved batteries, chargers and supplements supplied by Teltonika should be used with

this device. By using other sorts of batteries, chargers and supplements you risk to be deprived

of all guaranties and it may also be dangerous for you and your environment.

Hausehold

socket Protct. grounding

Phase-wire

Zero-wire

Automatic switch off

device

Charger

USB

Cable

Device

PCs

Electricity

distributing

board

3.2 Charging the battery

Just connect the charger and the device by using an USB cable

and plug the charger in the alternating current wall socket.

After the device is connected to the PC or alternating current

wall socket, the battery charging will start. Charging is indicated

by the indicator.

By connecting the device to one of the USB connectors of a PC or

by using the 230V – 5V charger available in the set, it is possible

to charge the internal battery of the device. For the first time it

is advisable to charge the battery using the 230-5V charger (not

via PC). The common charge time for the battery is less than

3,5h.

Quick-Start user manual version 1.00

4. Getting to know the device

4.1 Turning device on

4.2 Turning device off

If you wish to turn on the device, push the (5) button shortly and

wait few seconds. If device will not turn on, check lock/unlock

(10) swich,it should be unlocked or charge the device battery.

If you wish to turn off the device, push the (5) button and hold

until battery LED (1) indicator starts light red and green at the

same time, release the button and device will swich off.

1. LED indicators

Indicates the status of device.

2. Earpiece

3. LED indicators Icons

4. Alarm button

Activates the alarm function.

5. End call button

Turn device on and off, cancel call.

6. Volume up button

Increasing speaker volume.

7. Microphone

8. Micro USB connector

Connector for connection to PC for programing

and flashing.

9. Volume down button

Decreasing speaker volume.

10. Lock/unlock keyboars swich

Saves keyboard from unvonted pressing and

functions activation.

11. Battery compartment

Saving battery from damages and falling down.

12. Talk button

Dials, answers a call, mute.

13. Reset button

14. Neck strap hanging place
