Tatung TLM-1903 User manual

OPERATING INSTRUCTIONS

TLM-1903

MAIN MENU

VGA IN : 1024x768

H.SYNC: -48.3KHz

V.SYNC: -60.8Hz

BRIGHTNESS

CONTRAST

DISPLAY ADJUST

COLOR TEMPERATURE

LANGUAGE

OSD ADJUST

AUDIO CONTROL

INPUT SELECTION

RESET

EXIT

DISPLAY ADJUST

V-POSITION

H-POSITION

PITCH

PHASE

SHARPNESS

AUTO BRIGHTNESS

AUTO TUNING

RECALL

RETURN

VIDEO ADJUST

CONTRAST

BRIGHTNESS

COLOR

SHARPNESS

HUE

ASPECT RATIO

COLOR TEMPERATURE

AUDIO CONTROL

INPUT SELECT

RECALL

EXIT

053

050

000

050

080

050

058

000

OFF

ENG

SPA

GER

ITA

FRE

RET

MUTE

VOLUME

RECALL

RETURN

VGA IN

VIDEO 1 IN

VIDEO 2 IN

S-VIDEO

DIGITAL

RETURN

OFF

STANDARD/4:3

OSD CONTROL

HOT KEY CONTROL

UP KEY <---> VOLUME INCREASE

DOWN KEY <---> VOLUME DECREASE

BRIGHTNESS Adjusts background black level of the screen


CONTRAST: Adjusts foreground white level of the screen


H. POSITION: Moves the screen image left or right

V. POSITION: Moves the screen image up or down

PITCH: Adjusts image distortion appearing as vertical

bars or noise on the screen

PHASE: Adjusts image distortion appearing as

horizontal bars or noise on the screen

SHARPNESS: Adjusts the clarity and focus of the screen


COLOR METER: Adjusts color temperature

LANGUAGE: Allows you to choose from English, French,

German, Italian, or Spanish

AUDIO CONTROL: Switches muting ON/OFF and controls

volume

INPUT SELECTION: Selects VGA, VIDEO, S-VIDEO signal inputs

RECALL: Returns all controls back to default settings
