Targus WIRELESS COMFORT LASER MOUSE User manual
User Guide
Manuel de l’utilisateur
SOURIS LASER CONFORT
SANS FIL
WIRELESS
COMFORT LASER MOUSE
Targus Wireless Comfort Laser Mouse
2
Introduction
Thank you for your purchase of the Targus Wireless Comfort Laser Mouse.
The accompanying micro USB receiver is small enough to leave plugged
into your computer or simply store it inside the mouse when travelling.
This is a plug and play device so no additional software is required. The
advance scroll wheel feature program can be downloaded from the Targus
website.
System Requirements
Hardware
• USB port
Operating System
• Microsoft Windows®2000
• Microsoft Windows®XP
• Microsoft Windows Vista®
• Microsoft Windows®7
• Mac OS®X 10.4 or later
Contents
• Targus Wireless Comfort Laser Mouse
• 2 x AA Batteries
• Micro USB Receiver
• User Guide
Targus Wireless Comfort Laser Mouse
3
1. Remove the battery cover from the top of the mouse by using the notch
on the back. Carefully lift the cover up as shown in the diagram.
Installing the Batteries
2. Remove the battery safety clip by squeezing the center of the clip and
sliding it back, towards the rear of the mouse. Lift up and rotate the
clip out of the way.
NOTE: THE BATTERY SAFETY CLIP WILL NEED TO BE IN THE SECURE, LOCKED POSITION
BEFORE THE BATTERY COVER CAN BE PUT BACK IN PLACE.
Targus Wireless Comfort Laser Mouse
4
3. Remove the micro USB receiver stored inside the center compartment .
Micro USB
receiver
4. Insert the two AA batteries, making sure that the positive (+) and
negative (-) ends of each battery match the polarity indicators inside
the battery compartment.
Targus Wireless Comfort Laser Mouse
5
5. Replace the battery safety clip by sliding it forward until it clicks into
place and then replace the battery cover.
Targus Wireless Comfort Laser Mouse
6
(B) Turn on the mouse pressing the power button, located on the bottom
of the mouse, for 3 seconds and then release.
This mouse is a plug and play device. It will automatically operate when
the USB receiver is connected to the computer.
(A) Plug the USB receiver into an available USB port on your computer.
Establishing the Connection
Power button
Targus Wireless Comfort Laser Mouse
7
Power On:
Press and hold the power button for 3 seconds and then release.
The battery life indicator will briefly light up showing the current power
level of the batteries.
Power Off:
Press and hold the power button for 3 seconds and then release.
The battery life indicator will briefly light up and then fade out.
Battery Check:
After the mouse is turned on, quickly press and release the power button.
The battery life indicator will light up showing the current power level of
the batteries.
Power Saving mode:
After an extended period of time, if the mouse is not used, it will automati-
cally enter power saving mode to conserve power and increase battery
life. Click on any mouse button to resume the normal operation. The
mouse may take a few seconds to reconnect with your computer.
Targus Wireless Comfort Laser Mouse
8
Battery Life Indicator
NOTE: WHEN THE FIRST LIGHT IS BLINKING, PLEASE REPLACE THE BATTERIES
3 LEDs lit Full power
2 LEDs lit Half power
1 LED lit Low power
Power Management
• To extend the life of your battery, turn off the mouse while travelling or
when you’re not using it.
Targus Wireless Comfort Laser Mouse
9
Programming Your Mouse
(Windows Only)
Once installation is complete, open the driver software and select the
desired setting for the scroll-wheel button. Close the driver software
application and you’re ready to go. Activate your selected feature by
pressing down on the scroll wheel.
To access the advanced scroll wheel features you will need to download
and install the software driver. This can be downloaded from the following
location:
Visit www.targus.com to download and install the driver.
Targus Wireless Comfort Laser Mouse
10
Regulatory Compliance
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference, and (2)
This device must accept any interference received, including interference that may
cause undesired operation.
Technical Support
Product Registration
Targus recommends that you register yourTargus accessory shortly after purchasing
it. Go to:
http://www.targus.com/registration.asp
You will need to provide your full name, email address, country of residence and
product information.
Warranty
Targus warrants this product to be free from defects in materials and workmanship
for one year. If your Targus accessory is found to be defective within that time, we will
promptly repair or replace it. This warranty does not cover accidental damage, wear
and tear, or consequential or incidental loss. Under no conditions is Targus liable for
loss of, or damage to devices; nor loss of, or damage to, programs, records, or data;
nor any consequential or incidental damages, even if Targus has been informed of
their possibility. This warranty does not affect your statutory rights.
For technical questions, please visit:
Internet: www.targus.com/support.asp
Email: info[email protected]
This Class B digital apparatus complies with Industrial Canada RSS-210
