T-Mobile 768 User manual

user guide

welcome

T-MOBILE®768TM1830

CJB32J2ALAAB

IP4508_Tmobile 768_QG_USA_03_130123.indd Sec1:1-Sec1:2IP4508_Tmobile 768_QG_USA_03_130123.indd Sec1:1-Sec1:2 2013-1-23 15:31:262013-1-23 15:31:26

TABLE OF CONTENTS

Support.................................................. 1

Service Activation.................................. 2

Phone Overview .................................... 3

SIM Card ............................................... 4

Memory Card ........................................ 6

Battery ................................................... 7

Power..................................................... 7

Home Screen ........................................ 8

Calls....................................................... 9

Volume & Ringtone ............................. 10

Contacts.............................................. 11

Text Entry ............................................. 12

Text Messaging ................................... 13

Web Browsing ..................................... 15

Bluetooth®.......................................... 15

TTY ...................................................... 16

Accessories......................................... 18

Caring For Your Phone ........................ 19

Safety Tips........................................... 20

Emergency Dialing.............................. 21

Additional Information ......................... 22

IP4508_Tmobile 768_QG_USA_03_130123.indd Sec1:3-Sec1:4IP4508_Tmobile 768_QG_USA_03_130123.indd Sec1:3-Sec1:4 2013-1-23 15:31:402013-1-23 15:31:40

SUPPORT

This guide provides you with the information

you need to get started.

For more information and additional

support, please visit www.t-mobile.com/

support where you can:

QRegister at my.t-mobile.com to check

your minutes, pay your bill, upgrade

your phone, and change your rate plan.

QReview your phone’s User Manual

and troubleshooting FAQs.

QView the latest troubleshooting

solutions in the Support Forums

or ask a question of your own.

SERVICE ACTIVATION

If you are a new T-Mobile®customer

and your service has not yet been

activated, simply call Customer Care at

1-800-937-8997 and a T-Mobile Activations

representative will assist you.

You will need the following information

when activating service:

QYour Service Agreement and the

agent code on your Agreement

QYour name, home address, home

phone number, and billing address

Note: For business and government accounts,

please provide the organization’s name,

address, and tax ID.

QYour Social Security number, current

driver’s license number, and date

of birth for credit check purposes

QYour choice of T-Mobile rate plan and

services (see www.t-mobile.com

for latest plan information)

QYour SIM serial number and

IMEI number (located on

the box barcode label)

By activating service, you acknowledge that you have read,

understand, and agree to be bound by each of T-Mobile’s

Terms and Conditions, and by your Service Agreement.

IP4508_Tmobile 768_QG_USA_03_130123.indd Sec2:1-Sec2:2IP4508_Tmobile 768_QG_USA_03_130123.indd Sec2:1-Sec2:2 2013-1-23 15:31:402013-1-23 15:31:40

PHONE OVERVIEW SIM CARD

The SIM (Subscriber Identity Module)

card identiﬁes your phone to the wireless

network. You cannot make or receive

phone calls or browse the Internet without a

properly installed SIM card.

Install the SIM card

1. Detach the

SIM card

from its

packaging.

2. Pull the back cover up and

away from the phone.

3. Lift the battery and remove it

from the battery compartment.

Headset Jack

Left Soft key

Camera key

Right Soft key

End key

Micro-USB/

Charging Port

Send key

Status bar

Widget bar

Status bar

Push SIM from

back to detach

IP4508_Tmobile 768_QG_USA_03_130123.indd Sec2:3-Sec2:4IP4508_Tmobile 768_QG_USA_03_130123.indd Sec2:3-Sec2:4 2013-1-23 15:31:402013-1-23 15:31:40

MEMORY CARD

Install a memory card to add extra storage

space for your music, pictures, videos,

and more. Memory card sold seperately.

Install a memory card

1. Pull the back cover up and

away from the phone.

2. Lift the battery and remove it

from the battery compartment.

3. Slide the memory card into place

with the gold contacts facing down

until the card clicks into place.

4. To insert the SIM card, push the

metal SIM card door in the direction

shown below until it clicks and

then raise the door to open.

5. Insert the battery by lining up the

contacts on the battery with the

ones in the battery compartment

and lower the battery into place.

6. Replace the back cover.

IP4508_Tmobile 768_QG_USA_03_130123.indd Sec2:5-Sec2:6IP4508_Tmobile 768_QG_USA_03_130123.indd Sec2:5-Sec2:6 2013-1-23 15:31:502013-1-23 15:31:50

BATTERY

To optimize battery performance, be sure to

fully charge your phone before using it for

the ﬁrst time.

Charge the battery

1. Insert the small end of the

charging cable into the charging

port on the phone, as shown.

2. Plug the other end of the charging

cable into a power outlet.

POWER

To turn the power on or off, press and hold

the red End key.

HOME SCREEN

Your Home screen displays important

information about your phone.

Status bar

The Status bar appears at the top of your

Home screen. Icons indicating your phone’s

status appear on the Status bar.

Shortcuts bar

The Shortcuts bar gives you quick access to

the applications you use the most.

Press the Navigation key left or right to

access shortcuts on the Shortcuts bar.

Edit the Shortcuts bar

1. From the Home screen, select Menu.

2. Select Settings.

3. Select Phone settings.

4. Select Shortcut bar.

5. Select Display to hide the

schortcuts bar, if desired.

6. Select Edit shortcuts.

7. Select the desired shortcuts.

8. Select Save.

IP4508_Tmobile 768_QG_USA_03_130123.indd Sec2:7-Sec2:8IP4508_Tmobile 768_QG_USA_03_130123.indd Sec2:7-Sec2:8 2013-1-23 15:31:572013-1-23 15:31:57

109

CALLS

Make and end calls

Enter the phone number you want to call

and press the green Send key.

To end a call, press the red End key.

Answer calls

To answer a call, press the green

Send key.

VOICEMAIL

Set up voicemail

1. Touch and hold 1 to call voicemail.

2. Follow the prompts to set up

your voicemail account.

Reset voicemail password

You can reset your voicemail password to

the last four digits of your phone number.

1. Enter #793#.

2. Press the green Send key.

3. Select OK.

VOLUME & RINGTONE

Adjust in-call volume

While on a call, press the Navigation

key up or down.

Set call ringtone and volume

1. From the Home screen, select Menu.

2. Select Settings, then Proﬁles.

3. Select the Proﬁle you want to use.

4. Select Options.

5. Select Customize.

6. Select Ringtone.

7. Select the desired ringtone.

8. Select Save.

Set volume level

1. From the Home screen, select Menu.

2. Select Settings, then Proﬁles.

3. Select the Proﬁle you want to use.

4. Select Options.

5. Select Customize.

6. Select Volume.

7. Press the Navigation key up or

down to the desired volume level.

8. Select Save.

IP4508_Tmobile 768_QG_USA_03_130123.indd Sec2:9-Sec2:10IP4508_Tmobile 768_QG_USA_03_130123.indd Sec2:9-Sec2:10 2013-1-23 15:31:592013-1-23 15:31:59

1211

Set notiﬁcation sound

1. From the Home screen, select Menu.

2. Select Settings, then Proﬁles.

3. Select the Proﬁle you want to use.

4. Select Options.

5. Select Customize.

6. Select Message beep.

7. Select the desired notiﬁcation sound.

8. Select Save.

CONTACTS

Add a new contact

1. From the Home screen,

select Contacts.

2. Select Add New Contact.

3. Enter the ﬁrst name of the contact.

4. Enter the last name of the contact.

5. Enter the contact’s phone number.

6. Select Options.

7. Select Save.

8. Select Yes to conﬁrm.

Call a contact from the call log

1. Press the green Send key.

2. Scroll to the contact you want to call.

3. Press the green Send key.

Call a contact from the contacts list

1. From the Home screen,

select Contacts.

2. Scroll to the contact you want to call.

3. Press the green Send key.

TEXT ENTRY

The alphanumeric keyboard allows you to

enter text using these methods:

QABC

Use this mode to enter words by

pressing the number keys until

the desired letters displays. For

example, to type RUN, press

the 7key three times, the 8key

twice, and the 6key twice.

QSmart mode

This mode predicts words

as you type. For example, to

enter RUN, press 7, 8, 6.

QNumbers

Use this mode to enter

numbers by pressing a single

key for each number.

IP4508_Tmobile 768_QG_USA_03_130123.indd Sec2:11-Sec2:12IP4508_Tmobile 768_QG_USA_03_130123.indd Sec2:11-Sec2:12 2013-1-23 15:31:592013-1-23 15:31:59

1413

QSymbols

Use this mode to enter symbols

and special characters.

Switch between text entry modes

1. While in a text entry screen,

select Options.

2. Select Input mode.

3. Scroll to and select the

desired text entry mode.

TEXT MESSAGING

Use the messaging feature to send and

receive text (SMS) and multimedia (MMS)

messages.

Send text messages to new contacts

1. From the Home screen, select Menu.

2. Select Messaging.

3. Select SMS/MMS.

4. Select New message.

5. Enter the phone number.

6. Scroll down to the message ﬁeld.

7. Enter your message.

8. Select Options.

9. Select Send.

Send text messages to saved contacts

1. From the Home screen,

select Contacts.

2. Scroll to the contact you

want to message.

3. Select Options.

4. Select Send message.

5. Scroll down to the message ﬁeld

and enter your message.

6. Select Options.

7. Select Send.

Read text messages

1. From the Home screen, select Menu.

2. Select Messaging.

3. Scroll to and select the

message thread containing the

message you want to read.

4. Scroll to the message you want to read.

Delete text messages

1. From the Home screen, select Menu.

2. Select Messaging.

3. Scroll to and select the message

thread containing the message

you want to delete.

4. Scroll to the message

you want to delete.

IP4508_Tmobile 768_QG_USA_03_130123.indd Sec2:13-Sec2:14IP4508_Tmobile 768_QG_USA_03_130123.indd Sec2:13-Sec2:14 2013-1-23 15:32:002013-1-23 15:32:00

1615

5. Select Options.

6. Select Delete or Delete all.

7. Select Yes.

WEB BROWSING

Visit a Web site

1. From the Home screen, select Menu.

2. Select MobileLife®.

3. Select Options.

4. Select Go to URL.

5. Enter the Web address for

the site you want to visit.

6. Select Options.

7. Select Go to.

BLUETOOTH®

Your phone comes with Bluetooth

connectivity, a wireless technology that

enables a data connection between your

phone and a Bluetooth headset or other

Bluetooth device (sold separately).

Prepare Bluetooth headset

Make sure your Bluetooth headset is fully

charged and in pairing mode. Refer to the

headset’s user manual for more information.

Turn on Bluetooth and pair with a

headset

1. From the Home screen, select Menu.

2. Select Tools, then Bluetooth.

3. Select Power. A Bluetooth icon

will appear on the Status bar

when the feature is active.

4. Select Device list.

5. Select Search.

6. Scroll to the desired headset.

7. Select Pair.

8. Select Yes.

9. Select Yes to always accept pairing

with this device, if desired.

TTY

Your phone is compatible with select TTY

(Text Teletype) devices that allow people

who are deaf, hard of hearing, or who

have speech or language disabilities to

communicate by telephone.

Notice

You’ll need a cable/adapter to connect the

TTY device to your phone’s headset jack.

Please check with the manufacturer of the

TTY device to ensure that it is compatible

with digital cell phones.

IP4508_Tmobile 768_QG_USA_03_130123.indd Sec2:15-Sec2:16IP4508_Tmobile 768_QG_USA_03_130123.indd Sec2:15-Sec2:16 2013-1-23 15:32:002013-1-23 15:32:00

Other manuals for 768

Table of contents

Other T-Mobile Cell Phone manuals

T-Mobile

T-Mobile Sparq II User manual

T-Mobile

T-Mobile 27-00 16-02 User manual

T-Mobile

T-Mobile SIDEKICK II Guide

T-Mobile

T-Mobile REVVL 5G User manual

T-Mobile

T-Mobile Revvlry+ User manual

T-Mobile

T-Mobile Sidekick User manual

T-Mobile

T-Mobile SDA User manual

T-Mobile

T-Mobile SDA User manual

T-Mobile

T-Mobile Samsung Garda Guide

T-Mobile

T-Mobile myTouch myTouch 3G User manual

T-Mobile

T-Mobile MDA Specification sheet

T-Mobile

T-Mobile REVVL XT1952-T Guide

T-Mobile

T-Mobile REVVL 2 PLUS User manual

T-Mobile

T-Mobile myTouch U8680 User manual

T-Mobile

T-Mobile 99HEE006-00 - T-Mobile ShadowTM - Copper User manual

T-Mobile

T-Mobile Vibe E200 User manual

T-Mobile

T-Mobile vairy touch II User manual

T-Mobile

T-Mobile SDA User manual

T-Mobile

T-Mobile G1 User manual

T-Mobile

T-Mobile Sidekick 3 User manual

T-Mobile

T-Mobile Dream User manual

T-Mobile

T-Mobile Sidekick 3 Guide

T-Mobile

T-Mobile myTouch 3G User manual

T-Mobile

T-Mobile SideKick II Guide

Popular Cell Phone manuals by other brands

Zte

Zte BLADE A520 quick start guide

Nokia

Nokia Lumia 620 user guide

Blackbe;rry

Blackbe;rry KEYone Safety and product information

Bea-fon

Bea-fon X5 Premium quick guide

Blackbe;rry

Blackbe;rry 8707 Series user guide

Blackbe;rry

Blackbe;rry Storm Troubleshooting

LG LM-X420QN user guide

LifeWatch

LifeWatch V user guide

Bea-fon

Bea-fon SILVER LINE SL860 user guide

IKI Mobile

IKI Mobile KF4.5i user manual

Hitech

Hitech HT-850 user guide

Yezz

Yezz Fashion F10 user manual

Point Mobile

Point Mobile PM60 user manual

Blackbe;rry

Blackbe;rry Q10 user guide

Blackbe;rry

Blackbe;rry Bold 9900 user guide

Blackbe;rry

Blackbe;rry STORM 9500 - VERSION 5.0 user guide

LG LM-K420EMW user guide

ISAFE MOBILE

ISAFE MOBILE IS655.2 operating manual
