522HS, 522SA

Ballina™Hand Shower/Shower Arm

Operation & Maintenance Manual

Model Numbers Speciﬁcations

522HS Hand Shower Assembly

522SA Shower Arm

Hand shower assembly includes 3 mode hand shower

with standard 2.5 gpm (9.5 L/min) ow restrictor. Hand

shower assembly and shower arm components are made

from metal and nonmetallic materials plated in standard

polished chrome nish.

Modiﬁcations Compliance

-1.5 1.5 gpm (5.7 L/min) ﬂow restrictor

-2.0 2.0 gpm (7.6 L/min) ﬂow restrictor

-BBZ Brushed bronze ﬁnish

-STN Satin nickel ﬁnish

Note: Append appropriate -sufx to model number.

-ASME A112.18.1; CSA B125.1

Warranty

Limited Lifetime - to the original end purchaser in

consumer installations.

5 Years - for commercial installations.

Refer to www.symmons.com/warranty for complete

warranty information.

Modiﬁcations

522HS

522SA

Note: Dimensions are subject to change without notice.

Measurements

A Ø 2 1/2", 64 mm

B1/2" IPS thread must protrude

1/2" from nished wall

C 2 1/4", 57 mm

D 7 1/2", 191 mm

2Symmons Industries, Inc. ■31 Brooks Drive ■Braintree, MA 02184 ■(800)796-6667 ■ Fax: (800)961-9621

■

www.symmons.com

■

[email protected]

■

ZV-3088 REV 0 09/18/14

Replacement Parts

Item Description Part Number

A Hand Shower 412W

B Cradle T-635

Vacuum Breaker

60" Hose EF-104

E Shower Arm 522SA

Notes:

1) Append -BBZ to part number for brushed bronze

nish; -STN for satin nickel.

2) Append -1.5 or -2.0 to hand shower for low ow.

Required for Installation

Adjustable wrench

Plumber tape

522HS

522SA

Care and Cleaning

1) Clean nished trim area with a soft cloth using mild soap and water or a non-abrasive cleaner and then quickly rinse

with water.

Troubleshooting Chart

Problem Cause Solution

Finish is spotting. Elements in water supply may cause

water staining on nish.

Clean nished trim area with a soft

cloth using mild soap and water or a

non-abrasive cleaner and then

quickly rinse with water.

Installation Operation

Symmons Industries, Inc. ■31 Brooks Drive ■Braintree, MA 02184 ■(800)796-6667 ■ Fax: (800)961-9621

■

www.symmons.com

■

[email protected]

■

ZV-3088 REV 0 09/18/14

1) Install wall elbow (B) to pipe

tting. Turn clockwise to tighten.

2) Attach large end of hand shower

hose (D) to hand shower (A).

3) Attach small end of hand shower

hose (D) and gasket to in-line

vacuum breaker (C). Connect in-line

vacuum breaker to wall elbow (B).

Turn clockwise to tighten.

4) Attach shower arm (E) to vertical

shower pipe. Turn clockwise to

tighten.
