Symbol LS 9208 Manual

Setup Instructions for

Gilbarco Passport

LS 9208

LS 9208 Setup Instructions

2

Introduction

This document provides instructions on programming the Symbol LS 9208 scanner for use with a Gilbarco Passport system.

Required Hardware

•Cable

• 25-32465-20 (RS232 Cable, DB9 Female, TxD on 2, 6 ft. Straight), or

• 25-32465-21 (RS232 Cable, DB9 Female, TxD on 2, 8 1/2 ft. Coiled), or

• 25-60262-20 (RS232 Cable, True TTL, DB9 Female, TxD on 2, 6 ft. Straight), or

• 25-60262-21 (RS232 Cable, True TTL, DB9 Female, TxD on 2, 8 1/2 ft. Coiled).

• Power Supply

• 50-14000-008 (110VAC for N. America), or

• 50-14000-009 (220VAC for Europe and Asia), or

• 50-14000-010 (100VAC for Japan).

Scanner Setup

The following parameters need to be set:

•SetDefaults

• Fujitsu RS-232

• Baud Rate 9600*

• Parity Even

• 1 Stop Bit*

•7-Bit

• Convert UPC-E to UPC-A

• Transmit UPC-A Check Digit*

• Transmit UPC-E Check Digit*

• None (No code ID character)

* Already set by default

Scan the following bar codes to configure the LS 9208 Scanner.

1

Set Defaults

3

2

Fujitsu RS-232

3

Even

4

7-Bit

5

Convert UPC-E To UPC-A

(Enable)

6

None

LS 9208 Setup Instructions

4

73-60833-SI02

Revision A - September 2004

Symbol Technologies, Inc.

One Symbol Plaza

Holtsville, N.Y. 11742-1300

http://www.symbol.com
