Super Vac 716-EXP User manual

READ THIS FIRST

VENTILATOR USER GUIDE MODEL 716-EXP

POSITIVE PRESSURE VENTILATOR

1716-EXP PPV User Guide Revised 11-2015

USER GUIDE

This manual covers the description, cautions, operation, and maintenance of the Super Vac 716-EXP.

Please take the time to read this manual before operating the ventilator.

Save this guide for future reference.

CONTENTS

1. BREAKAGE OR DAMAGE DURING SHIPMENT...........................................................................................................

2. GENERAL DESCRIPTION AND SPECIFICATIONS.......................................................................................................

3. PRODUCT SAFETY PRECAUTIONS........................................................................................................................

4. BEFORE OPERATING VENTILATOR.........................................................................................................................

5. OPERATION.........................................................................................................................................................

6. MAINTENANCE AND REPAIR..................................................................................................................................

7. EXTENSION CORDS..............................................................................................................................................

8. WARRANTY..........................................................................................................................................................

9. CONTACT INFORMATION.......................................................................................................................................

10. PARTS LIST........................................................................................................................................................

11. EXPLODED VIEW................................................................................................................................................

POSITIVE PRESSURE VENTILATOR

2716-EXP PPV User Guide Revised 11-2015

1. Breakage or Damage During Shipment

The transportation company is fully responsible for all shipping damage and will resolve problems promptly if you handle it

correctly. Please read these instructions carefully.

Examine the contents of all shipping cases. If you nd any damage, call your transportation agent at once and have them make a

description on the freight or express bill describing the damage and the number of pieces. Then write us and we will send you the

original bill of lading. Get a claim blank from the express or truck company. Fill the claim form out. Attach the claim blank to the

original bill of lading together with a copy of our invoice. Attach a memo on which you show the value of the damaged goods. Mail

or hand these papers to your local transportation agent. They will process your claim with reasonable promptness.

Please note, we cannot and will not enter claims for damages. If we led claim here, it would be sent to your local freight agent for

verication and investigation. This time can be saved by your ling the claim directly. Every consignee is on the ground oor and

in contact with the local agent who inspects the damaged goods, and thus, each claim can be given individual attention.

Since our goods are packed to comply with the regulations of all railroad, truck, and express companies, we cannot allow

deduction from any invoice because of any damage, however, be sure to le your claim promptly. Our goods are sold F.O.B.

factory. We take receipt from the transportation company certifying that the goods were delivered to them in good order, and our

responsibility ceases.

It is seldom that any breakage or damage occurs in any of our shipments, and in no case will the customer be out any expense if

they follow the above instructions.

Be sure to keep all damaged goods subject to examination of the truck or express company inspector, who may call on you some

time later. These damaged goods, of course, will belong to them, and they will inform you what to do with them. If you dispose of

these damaged goods, your claim may not be paid.

POSITIVE PRESSURE VENTILATOR

3716-EXP PPV User Guide Revised 11-2015

2. General Description and Specications

Super Vac ventilators are specically designed to provide a convenient and portable source of air. Super Vac positive pressure

ventilators are tested to AMCA PPV Standard 240-95, for use in extreme conditions.

Model # RPM Voltage Motor HxWxD Weight

716-EXP 1750 115V AC 1 Hp Single Speed, Hazardous

Location, Class 1 Group D 20” x 20.5” x 16” 70 lbs

Specications are subject to change without notication. Refer to model decal afxed to ventilator to determine actual specications.

This ventilator is designed for high powered air movement. Super Vac’s propeller produces a greater intake of air and eliminates

turbulence at the tips. Each blade is dynamically balanced for high efciency and long life.

3. Product Safety Precautions

• Do not use the ventilator for purposes other than its’ intended use.

• Wear eye and ear protection when operating the ventilator.

• Never operate ventilator while fatigued.

• Do not disassemble or modify the ventilator in any way. Doing so may lead to mechanical failure or personal injury.

• Do not wear loose clothing that could become entangled in the operating ventilator.

• Never permit anyone to operate ventilator without proper instruction.

• Do not operate ventilator without proper inlet or outlet guards in place. If guards are missing or damaged, contact factory for

replacements.

• Do not place ngers or other foreign objects through inlet or outlet guards. Should a foreign object enter the ventilator,

immediately stop motor. Be certain all mechanical motion has stopped. Do not use with any power voltage other than the

indicated voltage.

• Never handle energized power cords with wet hands.

• Do not place or operate ventilator on unsteady tables, slanted surfaces or other unstable surfaces.

• Never let extension cords or plug connection lay in water. Locate the ventilator so that it cannot fall into water inadverntly.

POSITIVE PRESSURE VENTILATOR

4716-EXP PPV User Guide Revised 11-2015

4. Before Operating Ventilator

• Always operate this ventilator from a proper AC power source supplied through a ground fault interrupter receptacle. Test

receptacle for ground fault before plugging in the ventilator power cord.

• Never use power cords with frayed, cut, or brittle insulation.

• A complete inspection of the ventilator should be made prior to operation.

• Inspect power cord plug for sound connections to the ground fault interrupter circuit.

• Check all threaded fasteners for proper tightness.

• Inspect inlet and outlet guards for damage or missing pieces. Replace damaged or missing guards before operating ventilator.

5. Operation

Check ventilator inlet and outlet guards for obstructions. Check and remove from immediate surrounding area any objects that

could be drawn into the ventilator intake.

Place ventilator in desired location before connecting battery pack. Use caution not to direct toxic fumes into conned spaces

with the ventilator. Please refer to the Super Vac Training Manual for Smoke Ventilation for comprehensive instruction on effective

ventilation practices.

Insert power cord plug into 115V AC power receptacle to begin ventilation.

To stop ventilation remove power cord plug from AC power receptacle.

CAUTION: Motors are equipped with thermal overload protection. When internal motor temperature exceeds design limits, the

motor will automatically shut off. Motor will automatically restart when it cools sufciently after overheating. Remove power

cord plug from AC receptacle before examining or working on a motor which has stopped because of overheating. Thermal

overload protection sensitivity increases with frequency. Take preventative steps to correct cause of overheating to assure long

motor life. Most overheating problems are associated with the use of portable power generators as the ventilator power supply.

POSITIVE PRESSURE VENTILATOR

5716-EXP PPV User Guide Revised 11-2015

6. Maintenance and Repair

Maintenance should only be performed by experienced and trained personnel.

Be sure the ventilator is disconnected from the power source before performing any maintenance or repair. The motor is of heavy

duty ball bearing construction. The unit is completely sealed and requires no lubrication for the life of the motor.

The ventilator blade should be specially checked for build-up of material or dirt which may cause an imbalance. Excessive

imbalance can lead to accelerated wear on motor bearings and vibration. Remove ventilator guards. Clean blade and inside housing

with mild detergent and water. Do not use abrasives, sharp instruments or caustic solvents that may scratch or damage the

aluminum alloy blade.

Intake and exhaust guards are not interchangeable. When replacing guards after cleaning, position them with the rings

to the outside with the row of spot welds holding the rings on the bottom.

7. Extension Cords

Do not use reeled or coiled cable. Reeled or coiled cable can produce a counter EMF (electromotive force). The counter EMF can

reduce the current carrying capability of an extension cord. This counter EMF will result in a voltage drop within the motor

instigating a thermal overload condition. Power supply must handle wattage requirements. When conditions require the use of

reeled cable, unreel all cable and place on the ground in very loose overlapping non-uniform coils.

Units* Watts ** Minimum Wire Gauge Maximum Cable Length

1 2000 14 150 ft

2 4000 12 250 ft

3 6000 10 350 ft

* Multiple units powered by one extension cord

** Minimum running wattage for multiple units. Startup amerage draw is much higher.

POSITIVE PRESSURE VENTILATOR

6716-EXP PPV User Guide Revised 11-2015

8. Warranty

Super Vacuum Manufacturing Company warrants that the equipment is free from defects in materials and workmanship when

used and operated for a period of ve years. The responsibility of Super Vacuum Manufacturing Company under this limited

warranty is limited to the repair and replacement of any parts which are found defective and which are returned to Super Vacuum

Manufacturing Company at 3842 Redman Dr, Fort Collins, CO 80524 with transportation charges prepaid (C.O.D. shipments will

not be accepted).

Prior to returning defective parts to SUPER VACUUM MANUFACTURING COMPANY, the original purchaser shall make a claim in

writing to SUPER VACUUM MANUFACTURING COMPANY at the above address indicating the model number and type of defect. No

parts or equipment will be received by SUPER VACUUM MANUFACTURING COMPANY for repair or replacement under this warranty

without specic written authority from it in advance.

Any parts damaged by improper installation, overloading, abuse or accident of any type or cause are not covered by this warranty.

All equipment manufactured by us is pre-run and tested before leaving our plant, and is shipped in good working order and

condition. We therefore extend to the original purchasers the following Limited Warranty for the period of ve years from the

original date of purchase:

1. This warranty does not apply to defects caused by accident, misuse, neglect, or wear and tear, nor can we be held responsible

for incidental and consequential expense and loss, nor does this warranty apply to equipment where alterations have been

executed without our knowledge or consent. These conditions are readily discernible when the equipment is returned to us for

inspection.

2. On all component parts not manufactured by SUPER VACUUM MANUFACTURING COMPANY, their warranty is to the extent that

the manufacturer of such component warrants them to SUPER VACUUM MANUFACTURING COMPANY, if at all. Look in your

local business phone directory for the nearest repair station for the brand of parts you have or write to us for the address.

3. If equipment received is found to have been damaged in transit, a claim should be made against the carrier within three days,

as we assume no responsibility for such damage.

4. Any service other than our Authorized Service voids this warranty.

5. This warranty is in lieu of and is intended to exclude all other warranties, express or implied, oral or written, including any

warranties of MERCHANTABILITY or FITNESS for a particular purpose.

POSITIVE PRESSURE VENTILATOR

7716-EXP PPV User Guide Revised 11-2015

9. Contact Information

For parts or service information, contact:

Super Vacuum Manufacturing Company, Inc.

3842 Redman Dr.

Fort Collins, CO 80524

Phone: 800-525-5224

970-297-7100

Fax: 970-297-7099

Email : [email protected]

Internet: www.supervac.com

POSITIVE PRESSURE VENTILATOR

8716-EXP PPV User Guide Revised 11-2015

10. Parts List

1 012-10285 1 GUARD 716 16” FRONT-PAINTED

2 032-15540 8 10-24 X 1/2” PHIL PH MS BLACK

3 032-10754 2 1/4” LOCK WASHER ZINC

4 032-10745 2 1/4 - 20 X 1” HEX CS ZINC

5 008-10193 1 KEYSTOCK 3/16” X 1 3/8” SQUARE

6 008-10187 1 BUSHING BLADE MAUREY HQ 3/4”

7 003-10055 1 BLADE 16” 7 BLADE GAS FINISHED

8 032-10787 4 5/16” LOCK WASHER ZINC

9 032-10779 4 5/16 - 24 X 1 1/4” HEX CS ZINC

10 018-14030 1 SHROUD 16” W/GUARD-PAINTED

11 032-10750 3 1/4-20 NYLOK HEX NUT ZINC”

12 032-10752 3 1/4” FLAT WASHER USS ZINC

13 018-15035 1 MOTOR MOUNT, 716, GAS, PAINTED

14 032-10725 3 1/4-20 X 5/8” PHIL RH MS ZINC

15 032-14565 2 BOLT, 3/8-16 X 4 1/2, SKTHD BUTTON, ZINC

16 005-10136 4 BUSHING, REDUCER, 3/4 X 1/2

17 008-13375 2 WHEEL PNEUMATIC DW414 3” HUB CENTER

18 032-11129 2 3/8” FLAT WASHER USS ZINC

19 032-11133 2 3/8-16 NYLOK HEX NUT ZINC

20 008-10189 4 PLUG, FINISHING, 1”, SQ RIBBED, BLACK

21 018-10431 1 TUBE FRAME 16” PAINTED

22 032-14564 2 3/8-16 X 2 1/2” SOCKET BUTTON HEAD CS ZN

23 008-10212 2 WASHER FLAT #17W14930 MICRO-PLASTIC

24 032-11129 2 3/8” FLAT WASHER USS ZINC

25 032-11133 2 3/8-16 NYLOK HEX NUT ZINC

26 008-10192 1 SPRING A-180-S VALCO 40 PCS. PER LB

27 032-14564 2 3/8-16 X 2 1/2” SOCKET BUTTON HEAD CS ZN

28 032-11129 2 3/8” FLAT WASHER USS ZINC

29 032-14559 2 NUT, HEX CAP, 3/8-16, NICKEL PLATED

30 019-17014 1 716 HANDLE PAINTED

31 008-14586 2 STOCK CAP COVER FOR 716 HANDLE TAB

32 032-11133 2 3/8-16 NYLOK HEX NUT ZINC

33 024-13284 1 SPRING SADDLE ISC #0198 W.DBL GRIND

34 008-10219 1 KNOB, 716, TILT LEVER

35 019-15084 1 716 TILT LEVER

36 024-13284 1 SPRING, COMPRESSION, TILT LEVER

37 021-14927 1 MOTOR, BLUFFTON, 1HP, HZ LOCATION

38 032-10777 1 BOLT, 5/16-24 X 3/4, HEX HEAD, ZINC

39 032-10791 1 5/16” FENDER WASHER ZINC

40 032-10787 1 5/16” LOCK WASHER USS ZINC

41 025-13429 1 DECAL 716EXP YELLOW SAFETY

42 025-13430 1 DECAL 716EXP SER# GREY

43 025-13426 1 DECAL, SUPER VAC, VERT LTRS, BLACK REFLT

44 005-10120 1 CORD, POWER, 14-3, SO 10FT MOLDED PLUG

45 032-10790 4 5/16-18 NYLOK HEX NUT ZINC

46 032-10786 4 5/16” FLAT WASHER ZINC

47 032-10770 4 5/16-18 X 1 1/2” HEX CS ZINC

This manual suits for next models

Table of contents

Other Super Vac Fan manuals

Super Vac

Super Vac V20-BK Instruction sheet

Super Vac

Super Vac 720-EXP User manual

Super Vac

Super Vac SVU-50 User manual

Super Vac

Super Vac V18-EX User manual

Super Vac

Super Vac V18-BK User manual

Super Vac

Super Vac V20-BD User manual

Super Vac

Super Vac V18-BD User manual

Super Vac

Super Vac F124E User manual

Super Vac

Super Vac 718-EXP User manual

Super Vac

Super Vac P200S User manual

Super Vac

Super Vac 716WT User manual

Super Vac

Super Vac V20-GB User manual

Super Vac

Super Vac P124S User manual

Super Vac

Super Vac 720GG User manual

Super Vac

Super Vac 724WT User manual

Super Vac

Super Vac V20-BH-SP User manual

Super Vac

Super Vac V20-EX User manual

Super Vac

Super Vac V16-BK User manual

Super Vac

Super Vac V18-BL User manual

Super Vac

Super Vac 716-EVS User manual

Super Vac

Super Vac 724EXP User manual

Super Vac

Super Vac 724-EVS User manual

Super Vac

Super Vac V20-ES User manual

Super Vac

Super Vac 718G4T User manual

Popular Fan manuals by other brands

ELTA FANS

ELTA FANS H03VV-F installation guide

Hunter

Hunter 20714 Owner's guide and installation manual

Emerson

Emerson CARRERA VERANDA CF542ORB00 owner's manual

Hunter

Hunter Caraway Owner's guide and installation manual

Panasonic

Panasonic FV-15NLFS1 Service manual

Kompernass

Kompernass KH 1150 operating instructions

VES

VES FALA100/12V/TR Original instructions

Vertiv

Vertiv Liebert DCD user manual

Westinghouse

Westinghouse GFP Series owner's manual

Venmar

Venmar KUBIX HRV PLUS Series user guide

Maico

Maico ECR 31 installation instructions

Sonnenkonig

Sonnenkonig Dinky instruction manual

S&P

S&P ECOWATT HXBR manual

Wider

Wider IMP03369BH instruction manual

Panasonic

Panasonic F-60DHN Operating and installation instructions

Hinkley

Hinkley HIGHLAND instruction manual

Broan

Broan 766BN installation guide

Premium

Premium PFS16022 Use manual
