Stuart Turner Supersub 460A User manual

Submersible Pumps

OPERATING INSTRUCTIONS

Please leave this instruction booklet with the pump as it

contains maintenance and safety information.

- 2 -

SUBMERSIBLE MODELS

INDEX . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Page No

Application . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

Product Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Limits of Application . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Technical Specification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Siting of the Pump . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Pipework . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Electrical Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Noise . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Commissioning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Trouble Shooting Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Environment Protection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

IMPORTANT NOTES

Please read these instructions fully before starting the

installation:

The installation must comply with the relevant water supply,

electrical and building regulations and be installed by a

competent person.

If in doubt, consult Stuart Turner Ltd.

APPLICATION

This pump set must not be used for any other application without the

written consent of Stuart Turner Limited and in particular, must not be

connected directly to the mains water supply or used outside the

conditions specified in the limits of application.

This appliance is not intended for use by persons (including children)

with reduced physical, sensory or mental capabilities, or lack of

experience and knowledge, unless they have been given supervision

or instruction concerning use of the appliance by a person responsible

for their safety.

Children should be supervised to ensure that they do not play with the

appliance.

Waste Water Models Dirty Water Models Clean Water Models

Supersub 460A Supervort 550A

Supervort 560A

Diver 3

Diver 4

- 3 -

General

The submersible pump range is designed for re-circulation, drainage and transfer of

fresh water in outdoor or indoor applications.

Model types within the range which have the suffix ‘A’ incorporate an adjustable float

switch assembly which provides automatic pump control.

An optional foam pre-filter is available for the Supersub model - contact Stuart Turner

Ltd for further details.

Supersub Range

This model is suitable for clean water, rain water or waste water applications.

Note: Waste water is water that has been used in the home except water from toilets

eg. dish, shower and laundry water.

Supervort Range

These models are suitable for dirty water applications and are capable of handling

semi-solids in suspension of up to 20 mm in diameter. They are also suitable for all

applications specified in the Supersub range.

Diver range

This model range has high head (pressure) capabilities and is suitable for clean water

applications only.

PRODUCT DESCRIPTION

Electric motor driven submersible pump with float switch control on selected models.

Motor

All motors are induction type, permanent capacitor, fitted with integral auto-resetting

thermal overload protection, IP68 enclosure, class ‘B’ insulation and continuously rated.

The motor is encapsulated in a casing and protected from water ingress by three

separate lip seals running on a shaft sleeve, lubricated with a biodegradable vegetable oil.

Pump

All models are close coupled to the motor and are of centrifugal design and are

supplied as standard with a stepped hose connector.

Both Supersub and Supervort are single stage units and are supplied pre-fitted with a

10 metre mains supply cord.

Diver 3 and 4 are three and four stage units respectively and are supplied as standard

with a non-return valve and are pre-fitted with a 15 metre mains supply cord.

Standard pump materials of construction of major wetted parts are as follows.

Model Body Impeller Shaft Motor

Encapsulent

Shaft

Sleeve

Seal

(Lip)

Supersub Polypropylene Noryl Stainless Steel Stainless Steel Ceramic Nitrile

Supervort Polypropylene Noryl Stainless Steel Stainless Steel Ceramic Nitrile

Diver Polypropylene Noryl Stainless Steel Stainless Steel Ceramic Nitrile

Cont....

- 4 -

TECHNICAL SPECIFICATION

Float Switch

Factory fitted assembly for automatic pump control, provided as standard on Supersub

and Supervort range. The wetted materials of construction are polypropylene. The float

switch is not available on the Diver range.

LIMITS OF APPLICATION

Stuart Turner reserve the right to amend the specification in line with its policy of

continuous development of its products.

Fig. 1 (Dimension Key)

Model Supply Max. Watts

consumed

Nominal

Watts

Output

(Motor)

Full

Load

Current

(Amps)

Enc.

Rating

Duty

Rating

Dims (mm) Gross

Weight

(packed)

No of

Pump

Stages

L W H

Supersub 460A 230/1/50 730 510 3.3 IP68 Continuous 155 140 325 7.2 1

Supervort 550A 230/1/50 320 225 1.4 IP68 Continuous 155 140 320 5.3 1

Supervort 560A 230/1/50 565 395 2.6 IP68 Continuous 155 140 355 7.1 1

Diver 3 230/1/50 810 565 3.7 IP68 Continuous 148 148 376 9.3 3

Diver 4 230/1/50 960 670 4.2 IP68 Continuous 148 148 400 9.5 4

Model Max.

Liquid

Temp.

°C

Min.

Liquid

Temp.

°C

Max.

Immersion

Depth

(m)

Min.

Immersion

Depth

(mm)

Max.

No.

Starts/h

Max.

Head (pump

closed valve)

(m)

Supersub 460A 35 4 7 90 30 10.2

Supervort 550A 35 4 7 120 30 5.1

Supervort 560A 35 4 7 120 30 7.8

Diver 3 35 4 10 150 30 35

Diver 4 35 4 10 150 20 42

- 5 -

CONNECTIONS

Supersub and Supervort pumps are supplied with a stepped hose connector which can

be screwed into the pump outlet port.

Diver pumps are supplied with a stepped hose connector and a non-return valve which

should be screwed into the pump outlet port (Fig. 6).

Fig. 2 Supersub

Fig. 3 Supervort

Fig. 4 Diver Fig. 5 Diver

Outlet

Hose

Connector

Non-

Return

Valve

Outlet Outlet

Pump Type Outlet Hose Connector Non-Return Valve

Thread Hose Bore

Supersub G1¼F G1¼M 38/32/25 N/A

Supervort G1¼F G1¼M 38/32/25 N/A

Diver G1F G1M/G¾M 25/19 G1M/G1F

- 6 -

SITING OF THE PUMP

WARNINGS:

Do not run against a closed valve for periods longer than 5 minutes.

The water in and around the pump must not be allowed to freeze. This

will result in pump damage.

Do not under any circumstances use the supply cord fitted, as a

means to carry or lower the pump into position on installation. Attach

a rope sling to handle.

Do not allow plastic pump parts to come into contact with solder flux,

oil or cellulose based paints, paint thinners or strippers, acid based

descalents or aggressive cleaning agents.

Never run pump whilst sucking air/water as the motor will overheat.

To prevent this happening always install pump in the vertical position

and ensure fully submerged.

When siting the pump ensure its base is raised slightly from the

bottom of the sump reducing the possibility of blocking the filter with

debris or drawing in small stones.

General

The pump must be installed in the vertical position and must be fully submerged at all

times to avoid overheating of the motor. Float switch controlled pumps may be operated

partially submerged for short periods (see float switch operation section for further details).

The pumps should be positioned away from pond plants (if applicable) to maximise flow

and prevent entanglement.

Diver

When siting these pumps in a location where organic or general debris is likely, ensure

the base is raised slightly from the bottom of the sump (eg. on a flat paving slab) to

prevent the integral inlet filter grille being frequently blocked with debris.

If the pump is not to sit on the bottom of the sump, or it is too deep, then it should be

suspended by a rope attached to the lifting eye or handle located on top of the pump.

Supersub

When siting this pump in a location where organic or general debris is likely, ensure the

pump is placed on its base on a flat horizontal surface (eg. on a paving slab) to enable

full functionality of the primary inlet filter grille, which in turn will prevent the secondary

inlet filter grille from being frequently blocked.

Supervort

When siting these pumps in a location where organic or general debris is likely, ensure

the base is raised slightly from the bottom of the sump (eg. on a flat paving slab) to

prevent the force of the pump from drawing in small stones. This will result in pump

damage.

Float Switch Operation

Selected models which include the suffix ‘A’ after the model number, are fitted with float

switches for automatic operation.

The following guide will help you get the most out of your pump.

START

STOP

START

STOP

470

450

- 7 -

The pump must never run dry, needing a minimum water depth of 90 mm on the

Supersub model and 100 mm on the Supervort models, at all times.

Adjustment of the float switch is achieved by lengthening or shortening the cable

through the moulded cable retention slot, which is located in the pump handle (Figs 6 and

7).

Note: When inserting cable into slot ensure it is fully engaged.

If modification of the level setting is required refer to Figures 8 and 9 and the following

chart.

Use of a Stuart non-return valve, Part No 26702 is recommended on the discharge side

to limit back flow and pump surging when draining small areas.

If the pump is required to drain, for instance, a cellar, then it must be installed in a

sump, having sufficient dimensions for the float switch to operate freely (Fig. 10), retaining

a minimum water depth as previously stated. The pump is continuously rated when fully

submerged but should only be run for short periods (10 mins) when the water drops to the

minimum level. The number of starts should not exceed 30 per hour.

Note: It is not possible to empty the sump completely, a minimum depth must remain

(Figs. 8 & 9).

Fig. 8 Min. Float

Switch Movement

Fig. 9 Max. Float

Switch Movement

Fig. 10 Min. Size Of Sump

Chart shows min. and max. float switch adjustment

Pump handle

Moulded

cable

retention slot

Float switch

cable shown

slotted into

position

Fig. 6 Fig. 7

A B C D E F

PUMP TYPE START

(MIN.ADJ)

STOP

(MIN.ADJ)

CABLE

(MIN.ADJ)

START

(MAX.ADJ)

STOP

(MAX.ADJ)

CABLE

(MAX.ADJ)

SUB 460A

VORT 550A

VORT 560A

400

410

440

200

190

230

220

480

460

490

100

350

320

330

- 8 -

PIPEWORK

WARNING

Ensure pipework from pump is independently supported to prevent forces

being transferred to outlet branch.

General

All models are supplied with a stepped hose connector (see pump connection section

for details) which can be screwed directly into the pump discharge connection.

The hose connector is suitable for a range of flexible hose sizes and can be cut to suit

the selected size. For best flow use the largest bore pipe possible minimising 90° bends.

Small pipe sizes will reduce the pump performance.

The discharge pipework must be independently supported to prevent forces being

transferred to the pump outlet branch.

Diver

These models are supplied with a non-return valve which should be screwed directly

into the pump outlet port (see pump connection section for details). The purpose of the

valve is to limit back flow and pressure on the pump and ensure discharge pipework is

always primed with water.

ELECTRICAL INSTALLATION

WARNINGS:

The electrical installation must be carried out in accordance with the

current national electrical regulations and installed by a competent

person.

A residual current device having a rated current not exceeding 30 mA

MUST be installed in the supply circuit. This may be part of a

consumer unit or a separate unit.

Before starting work on the electrical installation, ensure the power

supply is isolated.

This appliance must be earthed.

Isolate all appliances in the water from the electrical supply before

putting your hands in the water.

The power supply cord of this pump cannot be replaced. If the cord is

damaged, the pump should be scrapped.

If the pump is used to empty a swimming pool, the pump must not be

used when people are in the water.

The standard pumps are suitable for a supply of 230V, 1 phase, 50Hz. Other

frequencies (60Hz) are available on certain models and it is therefore very important to

ensure the pump rating plate details match the supply.

All motors are thermally protected by an integral auto-resetting thermotrip and are rated

for continuous use.

Earthing

This appliance must be earthed via the supply cord.

Electrical Connection (Supersub & Supervort range)

The motor is provided with a factory fitted supply cord and plug. This must be

connected to the mains supply via a 13 Amp double pole switched, socket outlet in

compliance with BS 1363-2.

The socket outlet should be mounted in an easily accessible position and should be

labelled if confusion is possible, to allow easy identification of the pump isolating switch.

Electrical Connection (Diver range)

The motor is provided with a factory fitted supply cord with bared ends. This must be

permanently connected to the fixed wiring of the mains supply. Means for disconnection

must be incorporated in the fixed wiring in accordance with the wiring rules.

A suitable method of connection would be via a double pole switched, fused connection

unit complying with BS 1363-4, protected with a fuse (see fuse section).

The connection unit should be mounted in an easily accessible position and should be

labelled if confusion is possible, to allow easy identification of the pump isolating switch.

Wiring (Supersub & Supervort range)

The moulded plug fitted to this appliance is not waterproof - keep dry.

The supply cord is factory fitted with a moulded plug incorporating a fuse, the value of

which is indicated on the pin face of the plug. Should the fuse need to be replaced, an

ASTA approved BS 1362 fuse must be used of the same rating, marked thus, . If

the fuse cover is detachable, never use the plug with the cover omitted. If a replacement

fuse cover is required, ensure it is of the same colour as that visible on the pin face of the

plug (i.e. red or orange).

If the plug supplied is not suitable for your socket outlet, it should be cut off and

destroyed.

WARNING: A plug with bared flexible cords is hazardous if engaged in a

live socket outlet.

The end of the flexible cord should be suitably prepared and correct plug fitted, as

follows:

The wires in this mains lead (supply cord) are coloured in accordance with the following

code:

Green & Yellow: Earth Blue: Neutral Brown: Live

As these colours may not correspond with the coloured markings identifying the

terminals in your plug, proceed as follows:

The wire which is coloured green and yellow must be connected to the terminal in the

plug which is marked with the letter 'E' or by the earth symbol or coloured green or

green and yellow.

The wire which is coloured blue must be connected to the terminal which is marked with

the letter 'N' or coloured black or blue.

The wire which is coloured brown must be connected to the terminal which is marked

with the letter 'L' or coloured brown or red.

- 9 -

- 10 -

Wiring (Diver range)

The Wires in the mains lead (supply cord) are coloured in accordance with the following

code:

Green and Yellow: Earth Blue: Neutral Brown: Live

As colours of the core in the new mains lead may not correspond with the coloured

markings identifying the terminals in your connection unit, proceed as follows:

The wire which is coloured green and yellow must be connected to the terminal marked

with the letter 'E' or by the earth symbol or coloured green or green and yellow.

The wire which is coloured blue must be connected to the terminal marked with the

letter 'N' or coloured black.

The wire which is coloured brown must be connected to the terminal marked with the

letter 'L' or coloured red.

Fuses

The following fuse size should be used with the appropriate pump.

Supply Cord Replacement

The power supply cord of this pump cannot be replaced. If the cord is damaged, the

pump should be scrapped.

Float Switch Cord Replacement

The float switch cord cannot be replaced. If the cord is damaged the pump should be

scrapped.

Supply Cord Extension (Pump)

The pumps are fitted with a supply cord suitable for outdoor and underwater use. The

cord specification is as follows:-

Model Fuse Size (Amps)

All Models 13

Pump Type Cord Type Cord Length (m)

Supersub 460A HO5RN-F3 G 0.75 mm² 10

Supervort 550A HO5RN-F3 G 0.75 mm² 10

Supervort 560A HO7RN-F3 G 1 mm² 10

Diver 3 HO7RN-F3 G 1 mm² 15

Diver 4 HO7RN-F3 G 1 mm² 15

This manual suits for next models

Table of contents

Other Stuart Turner Water Pump manuals

Stuart Turner

Stuart Turner MAINSBOOST VariQ Guide

Stuart Turner

Stuart Turner Monsoon U1.5 bar Twin User manual

Stuart Turner

Stuart Turner AQUABOOST iBolt Pump Guide

Stuart Turner

Stuart Turner ST NH PUMP 18TN Guide

Stuart Turner

Stuart Turner PH 45 ES Guide

Stuart Turner

Stuart Turner Monsoon Extra 2.6 bar PS Guide

Stuart Turner

Stuart Turner CH 4-30 PS Guide

Stuart Turner

Stuart Turner Monsoon Extra S1.4 bar Guide

Stuart Turner

Stuart Turner PH 45 TS FL Guide

Stuart Turner

Stuart Turner Monsoon Extra U1.4 bar Guide

Stuart Turner

Stuart Turner PH 35 ES Guide

Stuart Turner

Stuart Turner AQUABOOST iMatic 0304 1S-CMT/8 450 Guide

Stuart Turner

Stuart Turner WASTEFLO BC3 Manual

Stuart Turner

Stuart Turner MAINSBOOST iBOOST F200 Guide

Stuart Turner

Stuart Turner AQUABOOST MAB Guide

Stuart Turner

Stuart Turner PH 35 TS Guide

Stuart Turner

Stuart Turner Stuart Guide

Stuart Turner

Stuart Turner S2.0 bar Twin Guide

Stuart Turner

Stuart Turner techflo qt Guide

Stuart Turner

Stuart Turner ABB V150-45-2V-1 Guide

Stuart Turner

Stuart Turner Showermate Series User manual

Stuart Turner

Stuart Turner Stuart SPU 130 Mini Guide

Stuart Turner

Stuart Turner monsoon extra User manual

Stuart Turner

Stuart Turner BOOSTAMATIC 330 User manual

Popular Water Pump manuals by other brands

Neptun

Neptun NPHW 5500 operating instructions

Sensidyne

Sensidyne Gilian BDX-II Operation & service manual

Draper

Draper 47808 instructions

Trolla

Trolla 12820 manual

Sunfab

Sunfab SVH Series installation guide

WilTec

WilTec 50740 Operation manual

Fieldmann

Fieldmann FVC 5015 EK user manual

Everbilt

Everbilt EFSUB5-122HD Use and care guide

Graco

Graco Husky 3300e manual

esotec

esotec 101018 operating manual

moyno

moyno 2000 CC Service manual

Becker

Becker BASIC VASF 2.80/1-0.AC230 operating instructions

Sykes AmeriPumps

Sykes AmeriPumps GP100M Operation and maintenance instructions

DUROMAX

DUROMAX XP WX Series user manual

BRINKMANN PUMPS

BRINKMANN PUMPS SBF550 operating instructions

Franklin Electric

Franklin Electric IPS Installation & operation manual

Xylem

Xylem e-1532 Series instruction manual

Milton Roy

Milton Roy PRIMEROYAL instruction manual
