StarTech.com SV211 User manual

Manual Revision: 06/06/2012

For the most up-to-date information, please visit: www.startech.com

DE: Bedienungsanleitung - de.startech.com

FR: Guide de l'utilisateur - fr.startech.com

ES: Guía del usuario - es.startech.com

IT: Guida per l'uso - it.startech.com

NL: Gebruiksaanwijzing - nl.startech.com

PT: Guia do usuário - pt.startech.com

SV211

SV211K

SV411

SV411K

2 or 4 Port Black PS/2 KVM Switch Kit with Cables

*actual product may vary from photos

Instruction Manual

FCC Compliance Statement

This equipment has been tested and found to comply with the limits for a Class B digital

device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable

protection against harmful interference in a residential installation. This equipment generates,

uses and can radiate radio frequency energy and, if not installed and used in accordance with

the instructions, may cause harmful interference to radio communications. However, there

is no guarantee that interference will not occur in a particular installation. If this equipment

does cause harmful interference to radio or television reception, which can be determined by

turning the equipment o and on, the user is encouraged to try to correct the interference by

one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit dierent from that to which the receiver

is connected.

• Consult the dealer or an experienced radio/TV technician for help.

Use ofTrademarks, Registered Trademarks, and other Protected Names and Symbols

This manual may make reference to trademarks, registered trademarks, and other

protected names and/or symbols of third-party companies not related in any way to

StarTech.com. Where they occur these references are for illustrative purposes only and do not

represent an endorsement of a product or service by StarTech.com, or an endorsement of the

product(s) to which this manual applies by the third-party company in question. Regardless

of any direct acknowledgement elsewhere in the body of this document, StarTech.com hereby

acknowledges that all trademarks, registered trademarks, service marks, and other protected

names and/or symbols contained in this manual and related documents are the property of

their respective holders.

Instruction Manual

Table of Contents

Introduction............................................................................................1

Features ........................................................................................................................................................ 1

Packaging Contents ................................................................................................................................. 1

System Requirements.............................................................................................................................. 1

Installation ..............................................................................................2

Connecting Your Computers................................................................................................................. 2

Using Your KVM Switch........................................................................................................................... 3

Troubleshooting........................................................................................................................................ 4

Specications..........................................................................................5

Technical Support ..................................................................................6

Warranty Information............................................................................6

Instruction Manual

Introduction

This 2 or 4 Port KVM Switch Kit lets you control two or four computers using a single

keyboard, mouse and VGA monitor and oers both hotkey and top panel push-button

operation for simple switching between connected computers.

Designed to integrate seamlessly into any environment, the KVM switch oers a small

footprint design (roughly the size of a deck of playing cards) and draws power from the

connected computers, so it doesn’t require an external power supply.

A suitable solution for virtually any application, the KVM switch supports video

resolutions of up to 2048 x 1536 and includes 3-in-1 (PS/2 and Video) cables to provide

a complete, out-of-the-box KVM solution.

Delivering dependable and convenient control of multiple computers from a single

peripheral station, this high quality KVM switch is backed by StarTech.com’s 2-year

warranty and free lifetime technical support.

Features

• Allows you to control two (SV211, SV211K) or four (SV411, SV411K) PCs from one

PS/2 mouse, PS/2 keyboard, and VGA monitor

• Provides keyboard and mouse emulation to prevent boot-up errors

• Supports hot-plugging

• Capable of up to 1920 x 1440 VGA resolution

• DDC2B compatible

• SV211K/SV411K only: Includes high-quality StarTech.com 3-in-1 cables

• Backed by StarTech.com’s two year warranty

Packaging Contents

• 1x 2 or 4 Port PS/2 KVM Switch Kit with Cables

• 2x Cables

• 4x Rubber Feet

• 1x Instruction Manual

System Requirements

• Two (SV211, SV211K) or four (SV411, SV411K) IBM-compatible computers

• A PS/2 mouse, PS/2 keyboard, and VGA monitor

• SV211, SV411 only: Each computer requires a 3-in-1 KVM cable (not included)

NOTE: StarTech.com carries a wide range of 3-in-1 cables, KVM converters, and other

KVM accessories. Visit www.startech.com for details.

Instruction Manual

Installation

This section will guide you through the installation of your KVM switch. Please read

through this section carefully and complete each step in the order listed. Connecting

Your Console

1. Make sure that all devices are turned o and unplugged.

2. Plug your PS/2 keyboard into the purple mini-DIN-6 port on the switch. On the

SV211 and SV211K, the keyboard port is located on the back of the switch. On the

SV411 and SV411K, the keyboard port is located on the right side of the switch.

3. Plug your PS/2 mouse into the green mini-DIN-6 port on the switch. On the SV211

and SV211K, the mouse port is located on the back of the switch. On the SV411

and SV411K, the mouse port is located on the right side of the switch.

4. Plug your monitor into the HD-DB-15 monitor port located on the right side of the

back of the switch.

NOTE: The KVM switch uses negligible power and is designed to run without an

external power source. You can, however, plug a DC9V power adapter (not included)

into the device’s optional power port.

Connecting Your Computers

The KVM switch requires the use of StarTech.com 3-in-1 KVM cables (included with the

SV211K and SV411K). The “single” end of the cable connects to the KVM switch, the

“triple”end connects to your computer.

1. Make sure all computers are turned o.

2. Plug the single HD-DB-15 connector into one of the PC ports on the back of the switch.

3. Plug the blue HD-DB-15 connector into your PC’s monitor port.

4. Plug the purple keyboard connector into your PC’s keyboard port.

5. Plug the green mouse connector into your PC’s mouse port.

6. Repeat steps 2 to 5 for each computer you want to connect to the switch.

7. Turn on all computers.

NOTE: You can hot-plug additional computers to the KVM switch any time after the

initial power up.

Instruction Manual

Using Your KVM Switch

The LEDs on the switch indicate which PC is active. You can scroll between PCs

by either pressing the push-button on the top of the switch or by using a hotkey

command. A hotkey command is a short sequence of keystrokes beginning with two

left Ctrl keystrokes followed by another keystroke. Use only the left Ctrl key and do not

use the keypad at the right of the keyboard.

Selecting a Computer

Command Hotkey Sequence

Select Computer 1 Left Ctrl + Left Ctrl + 1

Select Computer 2 Left Ctrl + Left Ctrl + 2

Select Computer 3 Left Ctrl + Left Ctrl + 3 (SV411, SV411K only)

Select Computer 4 Left Ctrl + Left Ctrl + 4 (Sv411, SV411K only)

Scroll between powered-

on computers Left Ctrl + Left Ctrl + F2 + Up/Down Arrow

Auto-Scan Mode

Command Hotkey Sequence

Start auto-scan Left Ctrl + Left Ctrl + F1

End auto-scan Left Ctrl + Left Ctrl

Select auto-scan interval Left Ctrl + Left Ctrl + F3

Auto-scan mode will be suspended if the switch detects any keyboard or mouse

activity. When the activity ceases, auto-scan mode will resume. The auto-scan interval

can be set to 3 seconds (default setting, represented by one beep), 8 second (two

beeps), 15 seconds (three beeps), and 30 seconds (four beeps).

Instruction Manual

Keyboard Typematic Rate:

Command Hotkey Sequence

Adjust Typematic Rate Left Ctrl + Left Ctrl + F4

The keyboard typematic rate set on the KVM will over-ride any typematic rate set by

the PC’s BIOS or operating system. The typematic rate can be set to 10 characters/

second (represented by one beep), 15 characters/second (two beeps), 20 characters/

second (three beeps), or 30 characters/second (four beeps).

Troubleshooting

If you are experiencing any diculties, rst make sure that all your cables are

connected to their proper ports and are rmly seated.

My keyboard or mouse does not work.

The keyboard or mouse may not have initialized properly. Press and hold the push

button for three seconds to re-initialize the keyboard and mouse. If problems persist,

unplug the mouse or keyboard, wait a few seconds, then plug them back in.

My keyboard strokes are shifted.

The computer was left inn a shifted state when last switched. Press both Shift keys.

The Up and Down arrow keys do not work in manual scan mode.

You may only have one computer turned on. Manual scan will only scroll through

powered-on computers.

My KVM switch occasionaly fails to function.

Your computers might not be providing enough power for the switch to function correctly.

Plug a DC9V 500mA (minimum) power adapter into the power port on the switch.

My auto-scan interval keeps returning to the default.

If all computers connected to the KVM switch are turned o, the KVM will return to its

default settings. If you want to keep your auto-scan interval, make sure that at least

one of your computers is on at all times.

The LED on my SV411K keeps ashing.

The LED on the SV411K will ash while in Auto-Scan or Manual-Scan modes. There is

nothing wrong with the switch

Instruction Manual

Specications

Number of computers

supported

SV211K: Two

SV211: Two

SV411K: Four

SV411: Four

Front panel control button One

Auto-scan interval 3, 8, 15, 30 seconds

Typematic Rate 10,15,20, 30 characters/second

Cable Length (max) 5.9ft (1.8m)

VGA 1920 x 1440, DDC2B

Computer connector HD-DB-15 female

Console keyboard

connector PS/2 female

Console mouse connector PS/2 female

Console monitor connector HD-DB-15 female

Dimensions (L x W x H) SV211, SV211K: 2.76 x 6.30 x 0.83in. (70x160x21mm)

SV411, SV411K: 3.39 x 7.28 x 0.87in. (86x185x22mm)

Certications FCC, CE, VCCI

Instruction Manual

Technical Support

StarTech.com’s lifetime technical support is an integral part of our commitment to

provide industry-leading solutions. If you ever need help with your product, visit

www.startech.com/support and access our comprehensive selection of online tools,

documentation, and downloads.

For the latest drivers/software, please visit www.startech.com/downloads

Warranty Information

This product is backed by a two year warranty.

In addition, StarTech.com warrants its products against defects in materials

and workmanship for the periods noted, following the initial date of purchase.

During this period, the products may be returned for repair, or replacement with

equivalent products at our discretion. The warranty covers parts and labor costs only.

StarTech.com does not warrant its products from defects or damages arising from

misuse, abuse, alteration, or normal wear and tear.

Limitation of Liability

In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their

ocers, directors, employees or agents) for any damages (whether direct or indirect,

special, punitive, incidental, consequential, or otherwise), loss of prots, loss of business,

or any pecuniary loss, arising out of or related to the use of the product exceed the

actual price paid for the product. Some states do not allow the exclusion or limitation

of incidental or consequential damages. If such laws apply, the limitations or exclusions

contained in this statement may not apply to you.

Hard-to-nd made easy. At StarTech.com, that isn’t a slogan. It’s a promise.

StarTech.com is your one-stop source for every connectivity part you need. From

the latest technology to legacy products — and all the parts that bridge the old and

new — we can help you nd the parts that connect your solutions.

We make it easy to locate the parts, and we quickly deliver them wherever they need

to go. Just talk to one of our tech advisors or visit our website. You’ll be connected to

the products you need in no time.

Visit www.startech.com for complete information on all StarTech.com products and

to access exclusive resources and time-saving tools.

StarTech.com is an ISO 9001 Registered manufacturer of connectivity and technology

parts. StarTech.com was founded in 1985 and has operations in the United States,

Canada, the United Kingdom and Taiwan servicing a worldwide market.

Other manuals for SV211

This manual suits for next models

Table of contents

Other StarTech.com Switch manuals

StarTech.com

StarTech.com SV431DD2DU3A User manual

StarTech.com

StarTech.com IES101002SFP User manual

StarTech.com

StarTech.com SV201 User manual

StarTech.com

StarTech.com SV231UADVI User manual

StarTech.com

StarTech.com ST3504USB User manual

StarTech.com

StarTech.com USB421HS User manual

StarTech.com

StarTech.com StarView SV231USB User manual

StarTech.com

StarTech.com V231DVIUDDM User manual

StarTech.com

StarTech.com 5G7AIBS-USB-HUB-NA User manual

StarTech.com

StarTech.com SV431HDU3A User manual

StarTech.com

StarTech.com SV431DPDDUA2 User manual

StarTech.com

StarTech.com SV231HDMIUA User manual

StarTech.com

StarTech.com ST3300G3UA User manual

StarTech.com

StarTech.com KVM SWITCHBOX VGA DS15H954 User manual

StarTech.com

StarTech.com SV441HDIE User manual

StarTech.com

StarTech.com DisplayPort MSTDP124DP User manual

StarTech.com

StarTech.com C2-DD46-UA2-CBL-KVM User manual

StarTech.com

StarTech.com IES51000POE System manual

StarTech.com

StarTech.com ST7202USB User manual

StarTech.com

StarTech.com SV831DUSBGB User manual

StarTech.com

StarTech.com ST12MHDDCRP User manual

StarTech.com

StarTech.com SV1110IPEXT Manual

StarTech.com

StarTech.com 5G4AINDNP-USB-A-HUB User manual

StarTech.com

StarTech.com 5G4AIBS-USB-HUB-EU User manual

Popular Switch manuals by other brands

URC

URC Total Control MFS-8 installation manual

Azbil

Azbil HPQ-D11 user manual

Sony

Sony DFS-900M operating instructions

SICK

SICK i17S operating instructions

F&F

F&F SZR-277 quick start guide

Shure

Shure UAMS/BK user guide

Dräger

Dräger X-zone Switch Off Instructions for use

Asco

Asco Joucomatic 349 Series manual

BT Mini Hub user guide

D-Link

D-Link DES-1226G manual

Johnson Controls

Johnson Controls FS80-C installation instructions

Alcatel-Lucent

Alcatel-Lucent 7450 ESS-12 Configuration guide

MicroNet

MicroNet SP1200A user manual

Ruijie

Ruijie RG-PF2920 Series Hardware installation and reference guide

Altinex

Altinex DA1914SX user guide

MiLAN

MiLAN MIL-SM2401M user guide

RJM

RJM MASTERMIND PBC/6X user manual

Atlas

Atlas MMK-KVM8 owner's manual
