StarTech.com USB2HDCAPS User manual

Manual Revision: 04/16/2019

User Manual

For the latest information and specications visit

www.startech.com/USB2HDCAPS

HDMI® or Component Standalone Capture

Device | 1080p

Actual product may vary from photos

SKU#: USB2HDCAPS

To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support

Compliance Statements

FCC Compliance Statement

This equipment has been tested and found to comply with the limits for a Class

B digital device, pursuant to part 15 of the FCC Rules. These limits are designed

to provide reasonable protection against harmful interference in a residential

installation. This equipment generates, uses and can radiate radio frequency

energy and, if not installed and used in accordance with the instructions, may

cause harmful interference to radio communications. However, there is no

guarantee that interference will not occur in a particular installation. If this

equipment does cause harmful interference to radio or television reception,

which can be determined by turning the equipment o and on, the user is

encouraged to try to correct the interference by one or more of the following

measures:

• Reorient or relocate the receiving antenna

• Increase the separation between the equipment and receiver

• Connect the equipment into an outlet on a circuit dierent from that to

which the receiver is connected

• Consult the dealer or an experienced radio/TV technician for help

Industry Canada Statement

This Class B digital apparatus complies with Canadian ICES-003.

Cet appareil numérique de la classe [B] est conforme à la norme NMB-003 du

Canada.

CAN ICES-3 (B)/NMB-3(B)

Use of Trademarks, Registered Trademarks, and other

Protected Names and Symbols

This manual may make reference to trademarks, registered trademarks, and

other protected names and/or symbols of third-party companies not related in

any way to StarTech.com. Where they occur these references are for illustrative

purposes only and do not represent an endorsement of a product or service

by StarTech.com, or an endorsement of the product(s) to which this manual

applies by the third-party company in question. Regardless of any direct

acknowledgement elsewhere in the body of this document, StarTech.com

hereby acknowledges that all trademarks, registered trademarks, service marks,

and other protected names and/or symbols contained in this manual and

related documents are the property of their respective holders.

To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support

Safety Statements

Safety Measures

• Wiring terminations should not be made with the product and/or electric

lines under power.

• Cables (including power and charging cables) should be placed and routed

to avoid creating electric, tripping or safety hazards.

Mesures de sécurité

• Les terminaisons de câblâge ne doivent pas être eectuées lorsque le produit

et/ou les câbles électriques sont sous tension.

• Les câbles (y compris les câbles d’alimentation et de chargement) doivent

être placés et acheminés de façon à éviter tout risque électrique, de chute ou

de sécurité

安全対策

• 電源が入っている状態の製品または電線の終端処理を行わないでくださ

い。

• ケーブル（電源ケーブルと充電ケーブルを含む）は、適切な配置と引き回し

を行い、電気障害やつまづきの危険性など、安全上のリスクを回避するよう

にしてください。

Misure di sicurezza

• I terminiali dei li elettrici non devono essere realizzate con il prodotto e/o le

linee elettriche sotto tensione.

• I cavi (inclusi i cavi di alimentazione e di ricarica) devono essere posizionati

e stesi in modo da evitare pericoli di inciampo, rischi di scosse elettriche o

pericoli per la sicurezza.

Säkerhetsåtgärder

• Montering av kabelavslutningar får inte göras när produkten och/eller

elledningarna är strömförda.

• Kablar (inklusive elkablar och laddningskablar) ska dras och placeras på så

sätt att risk för snubblingsolyckor och andra olyckor kan undvikas.

To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support

Table of Contents

Compliance Statements........................................................................1

Safety Statements..................................................................................2

Product Diagram....................................................................................5

Front View.................................................................................................................................................... 5

Rear View...................................................................................................................................................... 6

Introduction............................................................................................7

Package Contents ..................................................................................................................................... 7

System Requirements.............................................................................................................................. 7

Standalone Operation...........................................................................8

PC Operation...........................................................................................9

Hardware Installation .............................................................................................................................. 9

Software Installation .............................................................................10

Software Operation ...............................................................................11

Launching Application............................................................................................................................ 11

Application Operation............................................................................................................................. 11

Network Streaming Operation.............................................................14

Hardware setup ......................................................................................................................................... 14

ShareView Software installation.......................................................................................................... 15

Congure the ShareView software for streaming operation .................................................... 15

LED Indicators.........................................................................................17

To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support

Product Diagram

Front View

1RCA Audio Input Ports (x 2)

2Component Video Input Ports (x 3)

3HDMI In Port

4USB 2.0 Port

123

To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support

Rear View

1Record Button

2HDMI Out Port

3RJ45 Port

4Mode Switch

5SD Card Slot

3 4 5

To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support

Introduction

Package Contents

• Capture Device x 1

• USB 2.0 Cable x 1

• HDMI Cable x 1

• Driver CD x 1

• User Manual x 1

System Requirements

For Standalone Operation:

• SD Card

For PC Operation:

• Computer system with:

• Available USB 2.0 port

• Microsoft® Windows 10, 8/8.1, 7, Vista

For Streaming:

• Network infrastructure that supports DHCP and a minimum

of 10base T.

Notes: Static IP addresses cannot be set using this device.

The Capture Device will not record digitally encrypted

content.

To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support

Standalone Operation

1. Insert your SD Card into the SD slot.

2. Connect the included USB 2.0 Cable from the USB 2.0 Port

on the Capture Device to any USB power source.

3. Set the Mode Switch to Standalone Operation.

Standalone Operation

4. Connect an Audio/Video Source (DVD, DVR, VCR, etc.)

to either the HDMI In Port using an HDMI Cable or the

Component and RCA Ports using a Component and RCA

Cables depending on the Audio/Video source.

5. (Optional) To view what is being captured, connect an HDMI

Cable (not included) from the HDMI In Port on the Capture

Device to an HDMI Display.

6. Press the Record Button on the Capture Device to begin

the recording process. To stop recording press the Record

Button a second time.

7. Once the recording process has completed, each video clip

will be saved on your SD card in M2TS format.

To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support

PC Operation

Hardware Installation

1. Connect the USB 2.0 Cable to the USB 2.0 Port on the

Capture Device an the other end to a USB port on the Host

Computer.

2. Set the Mode Switch to PC Operation.

PC Operation

3. Connect an Audio/Video Source (DVD, DVR, VCR, etc.)

to either the HDMI In Port using an HDMI Cable or the

Component and RCA Ports using a Component and RCA

Cables depending on the Audio/Video source.

4. (Optional) To view what is being captured, connect an HDMI

Cable (not included) from the HDMI In Port on the Capture

Device to an HDMI Display.

To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support

Software Installation

Note: Please ensure the Hardware Installation steps have

been completed prior to beginning the Software Installation

steps.

1. When you have complete the Hardware Installation, the

Found New Hardware Wizard will open on the connected

Host Computer. Click Cancel to close the window.

2. Download the latest drivers from www.startech.com/

USB2HDCAPS.

3. Locate the Setup(.exe) application. This le will be located in

the Windows directory in the downloaded folder.

4. Click the Setup(.exe) to begin software installation. If a

Windows Security dialog box appears, click the Run or

Install this driver software anyway button to proceed.

5. Select Quick Installation from the menu that appears. The

installation will begin.

6. Select Typical Installation and click Install.

7. You will receive a request to start HiVision HD Capture.

Click the Start button to continue.

8. You will be asked to select a language for installation. Select

your desired language and click the OK button.

9. Follow the prompts to complete the VivaStation installation.

When prompted to, click the Finish button.

Note: You will be required to restart your computer.
