StarTech.com PEXUSB7LP User manual

PCI Express USB 2.0 Adapter

Card

7-Port PCI Express to High

Speed USB 2.0 Adapter Card

PEXUSB7LP

Instruction Manual

FCC Compliance Statement

This equipment has been tested and found to comply with the limits for a Class B digital

device, pursuant to part 15 of the FCC Rules. These limits are designed to provide

reasonable protection against harmful interference in a residential installation. This

equipment generates, uses and can radiate radio frequency energy and, if not installed

and used in accordance with the instructions, may cause harmful interference to radio

communications. However, there is no guarantee that interference will not occur in a

particular installation. If this equipment does cause harmful interference to radio or

television reception, which can be determined by turning the equipment off and on, the

user is encouraged to try to correct the interference by one or more of the following

measures:

Reorient or relocate the receiving antenna.•

Increase the separation between the equipment and receiver.•

Connect the equipment into an outlet on a circuit different from that to which the receiver•

is connected.

Consult the dealer or an experienced radio/TV technician for help.•

Use of Trademarks, Registered Trademarks, and other Protected Names and Symbols

This manual may make reference to trademarks, registered trademarks, and other

protected names and/or symbols of third-party companies not related in any way to

StarTech.com. Where they occur these references are for illustrative purposes only

and do not represent an endorsement of a product or service by StarTech.com, or an

endorsement of the product(s) to which this manual applies by the third-party company

in question. Regardless of any direct acknowledgement elsewhere in the body of

this document, StarTech.com hereby acknowledges that all trademarks, registered

trademarks, service marks, and other protected names and/or symbols contained in this

manual and related documents are the property of their respective holders.

Table of Contents

Introduction..................................................................... 1

Packaging Contents.....................................................................1

System Requirements .................................................................1

Installation....................................................................... 2

Hardware Installation...................................................................2

Driver Installation.........................................................................3

Verifying Installation.....................................................................3

Speciﬁcations.................................................................. 4

Technical Support........................................................... 5

Warranty Information...................................................... 5

Introduction

The StarTech.com 7-Port PCI Express to USB 2.0 Adapter Card

adds an additional 6 external and 1 internal USB 2.0 ports to any PCI

Express compatible computer system. Designed for versatility and

performance with support for high speed USB 2.0 data transfer rates

of up to 480 Mbps, this low proﬁle USB card also includes a standard

proﬁle (full height) bracket for installation in full form factor cases.

Packaging Contents

1 x PEXUSB7LP card•

1 x Full Height bracket•

1 x Driver Installation CD•

1 x Instruction Manual•

System Requirements

PCI Express enabled computer system with available slot•

Microsoft• ®Windows®XP/Server 2003/Vista/Server 2008 R2/7

(32/64-bit) or Linux®

5-pin IDC USB

header

SP4 power

connector

USB type A

connectors

Installation

WARNING! PCI Express cards, like all computer equipment, can be

severely damaged by static electricity. Be sure that you are properly

grounded before opening your computer case or touching your PCI

Express card. StarTech.com recommends that you wear an anti-static

strap when installing any computer component. If an anti-static strap

is unavailable, discharge yourself of any static electricity build-up by

touching a large grounded metal surface (such as the computer case)

for several seconds. Also be careful to handle the PCI Express card by

its edges and not the gold connectors.

Hardware Installation

Turn your computer off and any peripherals connected to the1.

computer (i.e. Printers, external hard drives, etc.). Unplug the power

cable from the rear of the power supply on the back of the computer

and disconnect all peripheral devices.

Remove the cover from the computer case. See documentation for2.

your computer system for details.

Locate an open PCI Express slot and remove the metal cover plate3.

on the rear of the computer case (Refer to documentation for your

computer system for details.). Note that this card will work in PCI

Express slots of additional lanes (i.e. x4, x8 or x16 slots).

Insert the card into the open PCI Express slot and fasten the bracket4.

to the rear of the case. If using a case that ﬁts full height cards,

remove the low proﬁle bracket (held by small screws) from the card

and replace with the included full height bracket.

To use the internal 5-pin IDC USB header, connect an internal USB5.

peripheral (i.e. front mounted USB ports, internal card readers, etc)

directly to the IDC header, or use an adapter cable to convert it to an

external USB type A connector (StarTech.com ID: USBMBADAPT).

Connect an SP4 ﬂoppy power connector from the computer power6.

supply to the connector on the card.

Place the cover back onto the computer case.7.

Insert the power cable into the socket on the power supply and8.

reconnect all other connectors removed in Step 1.

NOTE: Due to the stacked nature of the external USB ports, using USB

cables with large connectors may interfere with adjacent ports.

Driver Installation

Windows XP/Server 2003/Vista/Server 2008 R2/7

No driver installation is required for these operating systems, as this

USB card is natively supported, so the drivers are already installed.

Verifying Installation

From the main desktop, right-click on “My Computer” (“Computer”

in Vista/7), then select Manage. In the new Computer Management

window, select Device Manager from the left window panel.

Under the “Universal Serial Bus Controllers” category, new “VIA” host

controller devices should now be listed.

Specications

Bus Interface PCI Express rev 1.1

(x1 connector)

Chipset ID VIA VT6212L

Connectors*

6 x USB type A

1 x 5-pin IDC USB header

1 x SP4 ﬂoppy power

Maximum Data Transfer Rate USB 2.0: 480Mbps

Operating Temperature 0°C ~ 60°C (32°F ~ 140°F)

Storage Temperature -20°C ~ 85°C (-4°F ~ 185°F)

Humidity 5 ~ 95% RH

Compatible Operating

Systems

Windows XP/Server 2003/Vista/

Server 2008 R2/7 (32/64-bit),

Linux

* the three external USB ports closest to the bottom of the card (closes PCIe connector) use

independant data channels. The other external USB ports and the internal header all share a

single data channel

Technical Support

StarTech.com’s lifetime technical support is an integral part of our

commitment to provide industry-leading solutions. If you ever need

help with your product, visit www.startech.com/support and access

our comprehensive selection of online tools, documentation, and

downloads.

Warranty Information

This product is backed by a one year warranty.

In addition, StarTech.com warrants its products against defects in

materials and workmanship for the periods noted, following the initial

date of purchase. During this period, the products may be returned

for repair, or replacement with equivalent products at our discretion.

The warranty covers parts and labor costs only. StarTech.com does

not warrant its products from defects or damages arising from misuse,

abuse, alteration, or normal wear and tear.

Limitation of Liability

In no event shall the liability of StarTech.com Ltd. and StarTech.com USA

LLP (or their ofﬁcers, directors, employees or agents) for any damages

(whether direct or indirect, special, punitive, incidental, consequential, or

otherwise), loss of proﬁts, loss of business, or any pecuniary loss, arising

out of or related to the use of the product exceed the actual price paid

for the product. Some states do not allow the exclusion or limitation of

incidental or consequential damages. If such laws apply, the limitations

or exclusions contained in this statement may not apply to you.

StarTech.com has been making “hard-to-ﬁnd easy” since 1985,

providing high quality solutions to a diverse IT and A/V customer

base that spans many channels, including government, education

and industrial facilities to name just a few. We offer an unmatched

selection of computer parts, cables, A/V products, KVM and Server

Management solutions, serving a worldwide market through our

locations in the United States, Canada, the United Kingdom and

Taiwan.

Visit www.startech.com today for complete information about all

our products and to access exclusive interactive tools such as the

Cable Finder, Parts Finder and the KVM Reference Guide.
