StarTech.com IPUSB2VGAUE System manual

Ethernet to VGA over IP Converter

StarTech ID: IPUSB2VGAUE

The IPUSB2VGAUE Ethernet to VGA over IP Converter offers versatile VGA video distribution, extending a VGA

signal over Ethernet cable for transmission between a PC and VGA projector or display.

Functioning as an Ethernet VGA over IP converter, this innovative device can be used to extend a VGA video

signal over Ethernet cable for long distance video connections straight from the computer LAN/Ethernet port - an

ideal solution for boardroom presentations or simple digital signage over IP applications. The VGA/IP converter

can be used through a router, and supports a transmission distance of up to 100-meters (300-feet) at Gigabit

transfer speeds.

For shorter distance connections, the VGA adapter can be connected to the video source computer through USB,

and connected to a monitor through the adapter VGA output.

This versatile VGA adapter can also function as a network docking station with support for audio from the PC and

USB devices (e.g. keyboard and mouse on the projector or display side).

Backed by a StarTech.com 2-year warranty and free lifetime technical support.

Applications

Install the software on office PC's for a LAN / IP docking station and quickly swap computers on the

network - Ideal for boardroom presentations

Digital Signage or POS marketing - with the VGA over IP distance no longer being an issue for delivering

HD content to your target audience

Home theater and media center applications for streaming movies, photos, and online browsing

Features

Extend or mirror your primary desktop/display

Easy to use software and IP configuration utility

Two USB ports allow for connection of devices (i.e. keyboard, mouse) on the display side.

Supports resolutions up to 1920x1080

Audio supported when using USB to VGA or Ethernet to VGA conversion

Supports Windows Aero themes

Technical Specifications

Ports 1

Audio Yes

Chipset ID Displaylink

Daisy-Chain No

Local Unit Connectors 1 - RJ-45 Female

Local Unit Connectors 1 - USB Mini-B (5 pin) Female

Local Unit Connectors 1 - VGA (15 pin; High Density D-Sub) Female

Local Unit Connectors 2 - 3.5 mm Mini-Jack (3 Position) Female

Local Unit Connectors 2 - USB A (4 pin) Female

Maximum Data Transfer Rate USB - 480Mbps

Ethernet - 1000Mbps

Max Distance 100 m / 330 ft

Maximum Analog Resolutions 1920x1080

Wide Screen Supported Yes

Audio Specifications Two channel stereo audio supported

Note VGA over Ethernet (LAN, TCP/IP) is not supported by the Mac OS

OS Compatibility Windows XP(32/64bit)/ Vista(32/64bit)/ 7(32/64bit) Aero themes supported

USB to VGA only - Mac OS X 10.4.11/ 10.5.8/ 10.6.2

Microsoft WHQL Certified Yes

Color Black

Enclosure Type Plastic

Product Length 133 mm [5.2 in]

Product Width 71 mm [2.8 in]

Product Height 27 mm [1.1 in]

Product Weight 142 g [5 oz]

LED Indicators 1 - Power indicator

Power Adapter Included Yes

Input Voltage 110 ~ 240 AC

Input Current 0.4A

Output Voltage 5 DC

Output Current 2A

Center Tip Polarity Positive

Plug Type M

Operating Temperature 0°C ~ 40°C (32°F ~ 104°F)

Storage Temperature -20°C ~ 60°C (-4°F ~ 140°F)

Humidity 20~90% RH (no condensation)

Shipping (Package) Weight 460 g [16.2 oz]

Included in Package 1 - IP or USB to VGA Video Converter

Included in Package 1 - Mini USB to USB Cable

Included in Package 1 - Universal Power Adapter

Included in Package 1 - Driver and Software CD

Included in Package 1 - Instruction Manual
