StarTech.com ICUSBAUDIO System manual

USB to Stereo Audio Adapter Converter

StarTech ID: ICUSBAUDIO

This USB to Stereo Audio Adapter Converter lets you add headsets and microphones to your computer without the

need to unplug other devices!

Compliant with USB 2.0 and USB audio device specification 1.0, this USB to audio adapter couldn't be any simpler

to install.

Compatible with Windows 98SE and up, as well as Mac OS 9.x and later, the USB Audio Adapter integrates into

any computer environment, providing superb sound quality and convenience that can't be matched.

Applications

Add audio support to any USB capable computer system

Replace a failed onboard audio port for desktops or laptops

Connect 3.5mm mini-jack headset to a Playstation 3 console

Features

3.5mm mini-jack connectors for headphone and MIC

Compact, palm sized form factor

Headphone and microphone support on PlayStation 3

Compliant with USB audio device class specification 1.0

Plug-and-Play compliant

uk.startech.com

0800 169 0408

Technical Specifications

Warranty 2 Years

Chipset ID C-Media - CM108AH

Connector Type(s) 1 - USB A (4 pin) Male

Connector Type(s) 2 - 3.5 mm Mini-Jack (3 Position) Female

OS Compatibility Windows 2000/ XP(32/64-bit)/ Vista(32/64-bit)/ 7(32/64-bit)/ 8 (32/64-bit)

Mac OS X (tested up to 10.8)

Linux

Color White

Enclosure Type Plastic

Product Length 80 mm [3.1 in]

Product Width 4 cm [1.6 in]

Product Height 15 mm [0.6 in]

Product Weight 53.5 g [1.9 oz]

Shipping (Package) Weight 0.1 kg [0.3 lb]

Included in Package 1 - USB to Audio Adapter

Included in Package 1 - 9in USB Extension Cable

Included in Package 1 - Driver CD

Included in Package 1 - Instruction Manual

uk.startech.com

0800 169 0408

Certifications, Reports and Compatibility

uk.startech.com

0800 169 0408
