StarTech.com ET91000SFP2 System manual

Gigabit Ethernet Fiber Media Converter with Open SFP Slot

StarTech ID: ET91000SFP2

The ET91000SFP2 Open SFP Fiber Media Converter converts and extends a Gigabit Ethernet connection over

fiber, using the Gigabit SFP of your choice.

A versatile solution for connecting an Ethernet (1000Base-T) network to remote network segments over a fiber

backbone, the media converter features an open SFP slot that lets you choose the MSA-Compliant Gigabit SFP

that best suits your fiber connection mode (single / multi-mode) and distance requirements (see our full line of

Gigabit transceivers for compatible solutions).

The fiber to Ethernet converter has a durable all-steel chassis and offers simple plug-and-play installation, while

support for full-duplex operation and Jumbo Frame support provides efficient network operation.

For added versatility, this Gigabit media converter supports standalone operation, or installation into the 20 Slot, 2U

Rackmount Chassis (ETCHS2U). For applications where multiple chassis-mounted media converters are required,

this Gigabit media converter can be purchased as a Card Module only (ET91000SFP2C).

Backed by a StarTech.com 2-year warranty and free lifetime technical support.

Applications

Cost-effective way to extend/bridge networks using fiber cabling

Provides connectivity to a user or network segment that is in an isolated area of a large complex or in another

building altogether

Perfect for secure connections required by government agencies where EMI is not acceptable

Connect traffic control/monitoring systems at extreme distances to the main office

Extend network connectivity to remote areas of stadiums, auditoriums or other venues

Features

Supports standalone operation, or installation into the ETCHS2U Rackmount Chassis

Open SFP slot supports MSA-Compliant Single / Multi-Mode Gigabit SFPs at varying distances

Advanced features include Link-loss forwarding, remote monitor status, two frame lengths

Supports full or half-duplex operation

Easy to use and install

Jumbo Frame support

Technical Specifications

Warranty 2 Years

Chipset ID Marvell - 88E1111

Industry Standards IEEE 802.3ab 1000BASE-T

Industry Standards IEEE 802.3u 100BASE-LX

Industry Standards IEEE 802.3z 1000BASE-SX

PoE No

WDM No

Local Unit Connectors 1 - RJ-45 Female

Local Unit Connectors 1 - SFP Slot Female

Auto MDIX Yes

Fiber Operating Mode Half/Full-Duplex

Maximum Data Transfer

Rate

1.25 Gbps

MTBF 65, 000 Hours

Color Black

Enclosure Type Steel

Product Height 0.8 in [20 mm]

Product Length 6.3 in [160 mm]

Product Weight 14.1 oz [400 g]

Product Width 3.7 in [95 mm]

Center Tip Polarity Positive

Input Current 0.36 A

Input Voltage 100~240V

Output Current 1 A

Output Voltage 12 DC

Plug Type M

Power Adapter Included Yes

Power Consumption < 8W

Humidity 10~90% RH (Non-Condensing)

Operating Temperature 0°C to 60°C (32°F to 140°F)

Storage Temperature -10°C to 70°C (14°F to 158°F)

Note Fiber data transfer speeds and distances are dependent on the SFP used (sold

separately)

Shipping (Package)

Weight

21.2 oz [600 g]

Included in Package 1 - Fiber Media Converter

Included in Package 1 - Universal Power Adapter (NA/UK/EU)

Included in Package 1 - Instruction Manual

Certifications, Reports and Compatibility
