StarTech.com ET1110PSE System manual

Gigabit Ethernet PoE Open SFP Fiber Media Converter – PSE

StarTech ID: ET1110PSE

The ET1110PSE PSE/PoE Media Converter, which features an open SFP slot, enables you to create an Ethernet-

Fiber link by transparently converting from 1000Base-SX/LX fiber to 10/100/1000Base-T, while acting as a Power

Sourcing Equipment (PSE) device.

With the added flexibility of an open SFP slot, the media converter enables you to choose the Gigabit SFP that best

suits your network fiber connection and distance requirements (see our full line of Gigabit transceivers for

compatible solutions).

Capable of delivering up to 48V DC power to IEEE 802.3af devices (such as wireless access points (WAP) or IP

cameras), using standard Cat 5 (or better) cabling, this PoE media converter offers the ideal solution for providing

data and power to areas where electrical wall outlets may not be available - a versatile solution that saves the hassle

and expense of running new electrical wiring.

Backed by a StarTech.com 2-year warranty and free lifetime technical support.

Applications

Works well in industrial applications, where standard power outlets are not available or are too costly to install

Perfect for powering a Wireless Access Point (WAP) in a business environment

Power a security camera/ network webcam situated in a remote area where power connection is not

possible, over an Ethernet connection

Enable remote installation of touchscreens or information kiosks

Connecting PoE device data and power to Gigabit fiber backbone

www.startech.com

1 800 265 1844

Features

10/100/1000Base-T to 1000Base-SX/LX Media Converter with open SFP slot

IEEE 802.3af Compliant PSE (power sourcing equipment)

Supplies 48V DC (up to 15.4W) to PoE compliant devices

Supports Link Fault Pass-Through (LFPT) function

10/100/1000 Mbps Ethernet Auto-negotiation or Forced Mode

Supports 1632 bytes (max.) packets

Auto MDI/MDI-X

www.startech.com

1 800 265 1844

Technical Specifications

Warranty 2 Years

PoE Yes

WDM No

Industry Standards IEEE 802.3 10BASE-T

Industry Standards IEEE 802.3ab 1000BASE-T

Industry Standards IEEE 802.3af Power over Ethernet

Industry Standards IEEE 802.3u 100BASE-TX

Industry Standards IEEE 802.3x

Industry Standards IEEE 802.3z 1000BASE-SX

Chipset ID Marvell - 88E6131

Local Unit Connectors 1 - RJ-45 Female

Fiber Operating Mode Half/Full-Duplex

Auto MDIX Yes

Switching Architecture Store and Forward

MTBF 75,000 Hours @ 25°C

Power Output 48V DC at 15.4W Supported

Color Black

Enclosure Type Plastic

Product Length 5.7 in [145 mm]

Product Width 2.6 in [65 mm]

Product Height 1.4 in [35 mm]

Product Weight 21.2 oz [600 g]

LED Indicators 1 - Power

LED Indicators 1 - TX Speed

LED Indicators 2 - Duplex (TX/FX)

LED Indicators 2 - Link (TX/FX)

Input Voltage 110 ~ 240 AC

Power Adapter Included Yes

Power Consumption < 5W (with PSE Output Power)

Operating Temperature 0°C to 50°C (32°F to 122°F)

Storage Temperature -10°C to 70°C (14°F to 158°F)

Humidity 10~90% RH (non-condensing)

Note Fiber data transfer speeds and distances are dependent on the SFP used (sold

separately)

www.startech.com

1 800 265 1844

Shipping (Package)

Weight

1.6 lb [0.7 kg]

Included in Package 1 - PSE/PoE Fiber Media Converter

Included in Package 1 - Universal Power Adapter (NA/EU/UK)

Included in Package 1 - Instruction Manual

Certifications, Reports and Compatibility

www.startech.com

1 800 265 1844
