StarTech.com SATSASBAY425 User manual
SATA Hard Drive Backplane
4-Drive Removable 2.5” SAS/
SATA Mobile Rack Backplane
SATSASBAY425
Instruction Manual
FCC Compliance Statement
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the following
measures:
Reorient or relocate the receiving antenna.•
Increase the separation between the equipment and receiver.•
Connect the equipment into an outlet on a circuit different from that to which the receiver•
is connected.
Consult the dealer or an experienced radio/TV technician for help.•
Use of Trademarks, Registered Trademarks, and other Protected Names and Symbols
This manual may make reference to trademarks, registered trademarks, and other
protected names and/or symbols of third-party companies not related in any way to
StarTech.com. Where they occur these references are for illustrative purposes only
and do not represent an endorsement of a product or service by StarTech.com, or an
endorsement of the product(s) to which this manual applies by the third-party company
in question. Regardless of any direct acknowledgement elsewhere in the body of
this document, StarTech.com hereby acknowledges that all trademarks, registered
trademarks, service marks, and other protected names and/or symbols contained in this
manual and related documents are the property of their respective holders.
i
Table of Contents
Introduction..................................................................... 1
Packaging Contents.....................................................................1
System Requirements .................................................................1
Front View....................................................................................2
Rear View ....................................................................................2
Installation....................................................................... 3
Hardware Installation...................................................................3
Driver Installation.........................................................................5
Specifications.................................................................. 6
Technical Support........................................................... 7
Warranty Information...................................................... 7
1
Introduction
This StarTech.com SATSASBAY425 4-Drive Removable SAS/SATA
Backplane/Mobile Rack offers a convenient and efficient way to
maximize the storage density of your PC or Server. The backplane can
hold up to four 2.5” SAS and/or SATA hard drives (9.5mm, 12.5mm, or
14.8mm thick) in a single 5.25in drive bay.
Packaging Contents
1 x SATSASBAY425 backplane•
4 x Hard Drive Caddy•
4 x SATA cable•
1 x Screw kit•
1 x Instruction Manual•
System Requirements
Available 5.25” external bay•
Existing SAS/SATA controller•
2
Front View
Rear View
7-pin SAS/SATA
connectors
Cooling Fans
LP4 Power
connector
Power/Activity
LED
Tray Release
Latch
LED On/Off switch
3
Installation
WARNING: Hard drives require careful handling, especially when
being transported. If you are not careful with your hard disk, lost data
may result. Always handle your hard drive and storage device with
caution.
Hardware Installation
Turn your computer off and any peripherals connected to the1.
computer (i.e. Printers, external hard drives, etc.). Unplug the power
cable from the rear of the power supply on the back of the computer.
Remove the cover from the computer case. Refer to documentation2.
for your computer system for details.
Open an unused 5.25” external bay in the computer case.3.
Slide the SATSASBAY425 into the 5.25” bay, per the installation4.
instructions for the computer system/case and secure to the frame.
Connect an LP4 molex power connector from the computer power5.
supply to the power connector on the rear of the backplane.
Connect 7-pin SAS/SATA cables from the host SATA or SAS6.
controller to each connector on the rear of the backplane.
NOTE: SAS controller can operate both SAS and SATA drives,
however SATA controllers can only operate SATA drives.
Place the cover back onto the computer case.7.
Insert the power cable into the socket on the power supply and8.
reconnect all other connectors removed in Step 1.
4
Remove the drive trays from the backplane by pressing the colored9.
tray release latch to the left and swing it open. Pull the drive trays
out of the backplane.
If using a 9.5mm height drive, then the top of the drive tray does10.
not need to be removed. Just slide the drive into the tray from the
sides, then fasten the drive to the tray from the bottom side with 4
screws (included).
If using a drive taller than 9.5mm, then the top of the drive tray
needs to be removed. Release the screw located near of the rear
of the tray, then pull the top of the tray off. Place the drive onto the
tray and fasten from the bottom using 4 screws (included).
5
Slide the drive trays back into the backplane and lock the trays in11.
place by closing the swing handle and making sure the latch locks
properly.
Driver Installation
No driver installation is required for any operating system, as a
backplane is a pass-through device, so will not visible to the computer
system.
6
Specications
Bus Interface SATA
SAS
Maximum Number of Hard
Drives 4
Connectors 4 x 7-pin SATA/SAS
1 x LP4 Power
LEDs 4 x Power/Activity
Fan 2 x 40mm
Insertion Rating 25,000 cycles
Compatible Hard Drives 2.5” SATA, 9.5/12.5mm height
2.5” SAS, 14.8mm height
Operating Temperature -10°C to 70°C (14°F to 158°F)
Storage Temperature -20°C to 75°C (-4°F to 167°F)
Humidity 5~90% RH
Dimensions 175.0mm x 146.0mm x 42.0mm
Weight 790g
7
Technical Support
StarTech.com’s lifetime technical support is an integral part of our
commitment to provide industry-leading solutions. If you ever need
help with your product, visit www.startech.com/support and access
our comprehensive selection of online tools, documentation, and
downloads.
Warranty Information
This product is backed by a one year warranty.
In addition, StarTech.com warrants its products against defects in
materials and workmanship for the periods noted, following the initial
date of purchase. During this period, the products may be returned
for repair, or replacement with equivalent products at our discretion.
The warranty covers parts and labor costs only. StarTech.com does
not warrant its products from defects or damages arising from misuse,
abuse, alteration, or normal wear and tear.
Limitation of Liability
In no event shall the liability of StarTech.com Ltd. and StarTech.com USA
LLP (or their officers, directors, employees or agents) for any damages
(whether direct or indirect, special, punitive, incidental, consequential, or
otherwise), loss of profits, loss of business, or any pecuniary loss, arising
out of or related to the use of the product exceed the actual price paid
for the product. Some states do not allow the exclusion or limitation of
incidental or consequential damages. If such laws apply, the limitations
or exclusions contained in this statement may not apply to you.
